PRODUCT NO.
BASE MODEL NO.
GLRT214TCB0
GLRT214TC
GLRT214TCQ0
GLRT214TC
GLRT214TCW0
GLRT214TC
MARKET
North America
WIRING DIAGRAM - # 240379010
OWNER'S GUIDE - # 240400109
SERVICE DATA SHEET - # 240379010
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a Gallery
black
R134a Gallery
bisque
R134a Gallery
white
Publication No.
5995388435
030404
-EN/SERVICE/KHB
357
FACTORY
PARTS CATALO
VOLTS
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
GLRT214TC
©2003 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire GLRT214TC
Summary of Contents for Frigidaire GLRT214TC
- Page 1 PRODUCT NO. BASE MODEL NO. GLRT214TCB0 GLRT214TC GLRT214TCQ0 GLRT214TC GLRT214TCW0 GLRT214TC MARKET North America WIRING DIAGRAM - # 240379010 OWNER’S GUIDE - # 240400109 SERVICE DATA SHEET - # 240379010 ELECTROLUX HOME PRODUCTS, INC P.O. Box 212378, Augusta, GA 30917...
- Page 2 Publication No. GLRT214TC 5995388435 DOOR 04/03...
- Page 3 A = GLRT214TC (GLRT214TCB0) B = GLRT214TC (GLRT214TCQ0) C = GLRT214TC (GLRT214TCW0) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts GLRT214TC DOOR PART NO DESCRIPTION 240514611 A - - Gasket,seal ,black ,frzr door ,magnetic 240514607 - B C...
- Page 4 Publication No. GLRT214TC 5995388435 CABINET 04/03...
- Page 5 A = GLRT214TC (GLRT214TCB0) B = GLRT214TC (GLRT214TCQ0) C = GLRT214TC (GLRT214TCW0) POS. NO 10*# 13 # 16 # # = Fast-moving Parts * = Non-Illustrated Parts GLRT214TC CABINET PART NO DESCRIPTION 240355402 A B C Cover-fan 240367001 A B C...
- Page 6 Publication No. GLRT214TC 5995388435 SHELVES 04/03...
- Page 7 A = GLRT214TC (GLRT214TCB0) B = GLRT214TC (GLRT214TCQ0) C = GLRT214TC (GLRT214TCW0) POS. NO 14 # 17*# 21 # 23 # # = Fast-moving Parts * = Non-Illustrated Parts GLRT214TC SHELVES PART NO DESCRIPTION 215667501 A B C Tray,ice cube ,plastic...
- Page 8 Publication No. GLRT214TC 5995388435 SYSTEM 04/03...
- Page 9 A = GLRT214TC (GLRT214TCB0) B = GLRT214TC (GLRT214TCQ0) C = GLRT214TC (GLRT214TCW0) POS. NO 6* # 6* # 14 # 15 # 21 # 29 # 30 # 55 # 60 # 61 # # = Fast-moving Parts * = Non-Illustrated Parts...
-
Page 10: Wiring Schematic
Publication No. GLRT214TC 5995388435 WIRING SCHEMATIC 04/03... -
Page 11: Wiring Diagram
GLRT214TC Publication No. 5995388435 WIRING DIAGRAM # = Fast-moving Parts 04/03 * = Non-Illustrated Parts...
