Iono Pi User Guide
September 2018
Revision 006
IPBB13X Iono Pi board
IPBB13R Iono Pi RTC board
IPMB13X Iono Pi with Raspberry Pi 3 Model B
IPMB13R Iono Pi RTC with Raspberry Pi 3 Model B
IPMB13XP Iono Pi with Raspberry Pi 3 Model B+
IPMB13RP Iono Pi RTC with Raspberry Pi 3 Model B+

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Iono Pi and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sfera Labs Iono Pi

  • Page 1 IPBB13R Iono Pi RTC board IPMB13X Iono Pi with Raspberry Pi 3 Model B IPMB13R Iono Pi RTC with Raspberry Pi 3 Model B IPMB13XP Iono Pi with Raspberry Pi 3 Model B+ IPMB13RP Iono Pi RTC with Raspberry Pi 3 Model B+...
  • Page 2: Table Of Contents

    TTLx/DIx: TTL input/output or generic digital inputs OCx/DIx: Open collector outputs or generic digital inputs Real Time Clock Software installation and configuration Installing the Iono Pi utility Installing the Real Time Clock software Testing the Real Time Clock Disabling Bluetooth and WiFi...
  • Page 3 Installation and use restrictions Standards and regulations Safety instructions Set-up Conformity Information CANADA AUSTRALIA / NEW ZEALAND Compliance information for Raspberry Pi 3 Model B CANADA Compliance information for Raspberry Pi 3 Model B+ CANADA User Guide...
  • Page 4 Iono Pi. Carefully and fully read this Iono Pi user guide before installation. Iono Pi is not authorised for use in safety-critical applications where a failure of the product would reasonably be expected to cause personal injury or death. Safety-critical applications include, without limitation, life support devices and systems, equipment or systems for the operation of nuclear facilities and weapons systems.
  • Page 5: Safety Information

    Safety information Carefully and fully read this user guide before installation and retain it for future reference. Qualified personnel The product described in this manual must be operated only by personnel qualified for the specific task and installation environment, in accordance with all relevant documentation and safety instructions.
  • Page 6: Safety Instructions

    Use only appropriate tools when installing this product. Using excessive force with tools may damage the product, alter its characteristics or degrade its safety. Battery Iono Pi RTC uses a small lithium non-rechargeable battery to power its internal real time clock (RTC). User Guide...
  • Page 7 WARNING Improper handling of lithium batteries can result in an explosion of the batteries and/or release of harmful substances. Worn-out or defective batteries can compromise the function of this product. Replace the RTC lithium battery before it is completely discharged. The lithium battery must be replaced only with an identical battery.
  • Page 8: Introduction

    PLCs, with the powerful quad-core ARM Cortex-A53 64-bit processor of the Raspberry Pi 3. Iono Pi adds other important features that are essential to use the Raspberry Pi 3 for professional applications, like a robust power supply with wide voltage range (9÷28Vdc) capable of up to 2.5A output current at 5V to the Raspberry Pi board, and an optional real...
  • Page 9: Features

    ✓ power supply and I/O connections on a screw terminal block. Iono Pi assembled module: ✓ pre-assembled and tested Raspberry Pi 3 Model B or B+ with Iono Pi board, in a standard 4 modules DIN rail case ✓ side access to HDMI and 3.5mm jack for audio and composite video ✓...
  • Page 10: Hardware Installation

    Raspberry Pi and Iono Pi board. Iono Pi The Iono Pi module comes pre-assembled with a Raspberry Pi 3 Model B or B+ board, in a plastic standard DIN-rail case. There is no need to open the case, unless you have to change the position of the jumpers that select the voltage level of the TTL/DI inputs (see below), or to replace the internal battery.
  • Page 11 The RTC backup battery holder is soldered to a small circuit board next to the GPIO connector. In the Iono Pi server, the battery is not accessible from the outside. You should first remove the case top body to gain access to the Iono Pi circuit board.
  • Page 12: Usage And Connections

    RTC BACKUP BATTERY Usage and connections IONO PI CONNECTION EXAMPLE User Guide...
  • Page 13: Terminal Blocks

    Terminal blocks Iono Pi has two terminal blocks. A 15 positions terminal block, used for power supply and low-power input/output connections. The maximum conductor cross section is 1.5 mm (16 AWG), or 0.5 mm when using ferrules (highly recommended). Recommended stripping length is 5 mm. Screw thread is M2.
  • Page 14: Input/Output Mapping

    Input/Output mapping The following table shows the mapping of the inputs and outputs of the Iono Pi module into the related pins of the Raspberry Pi board. These pins should not be used for other functions. Iono inputs and outputs...
  • Page 15: Power Supply

    Considering the amount of current needed to drive the relays and open collector outputs, it could provide up to 2.5A at 5V to the Raspberry Pi. Because Iono Pi has a 1.1A resettable fuse (polyfuse) on the power supply line, the maximum current that its regulator can deliver is also limited by this fuse, and depends on the input voltage.
  • Page 16: Aix: Analog Inputs

    WARNING The Iono Pi might be damaged if A-GND is not at the same voltage level of VS- and GND and any amount of current is allowed to flow through A-GND. Two additional inputs (AI3 and AI4) are available on an on-board expansion header (CN3) for custom extensions.
  • Page 17: Ox: Relays

    TTL I/O or as the DATA0 line of a Wiegand interface. The TTL1 front-end circuit has a 4.7kOhm pull-up resistor. WARNING Never apply voltages outside the 0-5V range to this pin to avoid damage to the Iono Pi board and Raspberry Pi. TTLx/DIx: TTL input/output or generic digital inputs TTL2/DI1, TTL3/DI2 and TTL4/DI3 are dual-purpose pins.
  • Page 18 TTL LEVEL CONVERTER CIRCUIT AND INPUT MODE SELECTION JUMPERS TTL4/DI3, configured as TTL I/O, can be used as the DATA1 line of the second Wiegand interface, in combination with TTL3, or any other generic TTL I/O function. The TTL2-TTL4 front-end circuits have 4.7kOhm pull-up resistors. When these pins are configured as generic digital inputs, they are protected by a resistor network, and pulled to ground when not connected.
  • Page 19: Ocx/Dix: Open Collector Outputs Or Generic Digital Inputs

    TTL4/DI3 WARNING Note that the Iono Pi board and the Raspberry Pi could be damaged if the jumpers are configured for TTL mode and voltages outside the 0÷5V range are applied to the inputs. OCx/DIx: Open collector outputs or generic digital inputs OC1/DI4, OC2/DI5 and OC3/DI6 can be used as open collector (OC) outputs or generic digital inputs.
  • Page 20: Real Time Clock

    (when the Raspberry Pi is off). Depending on operating conditions it should last up to two years if the Iono Pi board is not powered, more if the Iono Pi receives external power. Once the RTC modules and configuration files are properly installed, you will simply use the date and time commands to control the hardware clock.
  • Page 21: Software Installation And Configuration

    Software installation and configuration All features of Iono Pi, except the real time clock and ADC converter, are controlled via dedicated GPIO pins and can be used with any operating system and programming language that supports the GPIO pins control on Raspberry Pi. The real time clock is interfaced via the I C serial bus, while the ADC uses the SPI lines.
  • Page 22: Installing The Real Time Clock Software

    C interface, then reboot your Raspberry Pi. To install the “i2c-tools” package: $ sudo apt-get update $ sudo apt-get install i2c-tools With these prerequisite installs completed, you should download and run Iono Pi’s RTC installation script: $ cd $ wget http://sferalabs.cc/files/strato/rtc-install $ chmod 755 rtc-install $ sudo ./rtc-install...
  • Page 23: Disabling Bluetooth And Wifi

    Disabling Bluetooth and WiFi The Iono Pi board works with Bluetooth and WiFi enabled, but you can disable both interfaces if you need to turn off the Raspberry Pi’s onboard radios. To disable Bluetooth, edit /boot/config.txt and add these lines at the end of the file:...
  • Page 24: Software Development

    A/D converter to the actual voltage values. The Iono Pi library uses a 0.007319 conversion factor for the AI1 and AI2 inputs with a 0÷30V range, and 0.000725 for AI3 and AI4 inputs with a 0÷3V range.
  • Page 25 The SPI clock speed is set to 50kHz. A significant increase in the clock speed will affect the reliability of the A/D conversion. THE IONO PI A/D CIRCUIT User Guide...
  • Page 26: Block Diagram

    Block diagram IONO PI BLOCK DIAGRAM User Guide...
  • Page 27: Technical Specifications

    Technical specifications Power supply (VS) 9÷28V⎓ (VDC) Reverse polarity protection with 1.1A resettable fuse. Surge protection up to ±500V/2ohms 1.2/50μs Low CPU/GPU load: Current consumption at VS+ 12V⎓ • 135mA unconnected inputs, relays OFF including Raspberry Pi 3 current, no USB devices •...
  • Page 28 • Max allowable current: 50mA • Min voltage: 4.5V Real time clock Internal RTCC circuit with backup lithium battery. (Iono Pi RTC version only) Only use CR1025 Lithium / Manganese Dioxide (Li/ MnO2) batteries.
 Expected battery life without main power supply: ~2 years...
  • Page 29: Dimensions

    Dimensions DIMENSIONS (mm) User Guide...
  • Page 30: Disposal

    Iono Pi RTC contains a small non rechargeable manganese dioxide lithium coin battery. In the Iono Pi RTC, the battery is not accessible from the outside. You should first remove the case top body to gain access to the Iono Pi circuit board. Always remove the battery before disposing of this product.
  • Page 31: Conformity Information

    Conformity Information This device complies with the essential requirements of the following directives and harmonised standards: ✓ 2014/35/UE (Low Voltage) ✓ 2014/30/UE (EMC) ✓ EN61000-6-2:2005 (EMC Immunity) ✓ EN60664-1:2007 (Electrical safety) ✓ EN61000-6-3:2007 (Emission for residential, commercial and light-industrial environments) ✓...
  • Page 32: Canada

    Shielded cables must be used with this equipment to maintain compliance with FCC regulations. Compliance information for Raspberry Pi 3 Model B Iono Pi models IPMB13X and IPMB13R contain a standard Raspberry Pi 3 Model B single board computer. This board has WiFi and Bluetooth radios. It is user accessible and replaceable.
  • Page 33: Compliance Information For Raspberry Pi 3 Model B

    Compliance information for Raspberry Pi 3 Model B+ Iono Pi models IPMB13XP and IPMB13RP contain a standard Raspberry Pi 3 Model B+ single board computer. This board has WiFi and Bluetooth radios. It is user accessible and replaceable. Raspberry Pi 3 Model B+ is in conformity with the essential requirements and other relevant requirements of the Radio Equipment Directive 2014/53/EU.
