- Page 1 Pi Touch Display Kit User Guide November 2019 Revision 011 SPTM20XP Strato Pi Mini Touch Display Kit SPTB30XP Strato Pi Base Touch Display Kit SPTU30XP Strato Pi UPS Touch Display Kit IPTB20RP Iono Pi Touch Display Kit ...
-
Page 2: Table Of Contents
Safety information Qualified personnel Hazard levels Safety instructions General safety instructions Battery and external rechargeable battery Introduction Kit Components Features Usage and connections Hardware installation microSD installation Power supply Wiring and GPIO operations Replacing the RTC backup battery Software installation Technical specifications Dimensions Disposal... - Page 3 Please download and read the Terms and Conditions document available at: http://www.sferalabs.cc Strato, Iono and Sfera Labs are trademarks of Sfera Labs S.r.l. Other brands and names may be claimed as the property of others. Copyright © 2019 Sfera Labs S.r.l. All rights reserved.
-
Page 4: Safety Information
Safety information Carefully and fully read this user guide before installation and retain it for future reference. Qualified personnel The product described in this manual must be operated only by personnel qualified for the specific task and installation environment, in accordance with all relevant documentation and safety instructions. -
Page 5: Safety Instructions
Safety instructions General safety instructions Protect the unit against moisture, dirt and any kind of damage during transport, storage and operation. Do not operate the unit outside the specified technical data. Never open the housing. If not otherwise specified, install in closed housing (e.g. distribution cabinet). - Page 6 WARNING Improper handling of lithium and lead-acid batteries can result in an explosion of the batteries and/or release of harmful substances. Worn-out or defective batteries can compromise the function of this product. Replace the RTC lithium battery before it is completely discharged. The lithium battery must be replaced only with an identical battery.
-
Page 7: Introduction
Introduction The Pi Touch Display Kit is a factory-assembled touch panel computer kit based on the Raspberry Pi computer board, the Raspberry Pi 7” Touch Display and the Strato Pi board (Mini, Base or UPS version) or the Iono Pi board, enclosed in a rugged, high-quality aluminium and steel chassis, that can be installed in-wall with its optional back-box mount. -
Page 8: Kit Components
Kit Components The kit is composed of: • Pi Touch Display Mechanical Kit (XPTM10X) • Raspberry Pi version 3 model B+ • Raspberry Pi Touch Display • Strato Pi board (SPBM20X, SPBB30X, or SPBU30X) or Iono Pi board (IPBB20R) • Optional Wall Mount Back Box (XPTB10X). User Guide... -
Page 9: Features
Features With Strato Pi Mini board: ✓ 9-28Vdc power supply, with surge and reverse polarity protection, and 1.1A resettable fuse ✓ real time clock with replaceable CR1025 back-up battery (not included) ✓ embedded Microchip ATECC608A secure element chip ✓ on-board buzzer, connected to an I/O pin of the Raspberry Pi board, for acoustic feedback ✓... - Page 10 ✓ integrated boot loader for the Strato Pi micro-controller, allowing in-field firmware upgrades directly from the Raspberry Pi ✓ embedded Microchip ATECC608A secure element chip ✓ on-board LEDs for power supply and serial line activity ✓ power supply and serial connections on a screw terminal block ✓...
-
Page 11: Usage And Connections
Usage and connections Hardware installation The Pi Touch Display Kit is shipped fully assembled. You will only have to access the Raspberry Pi board to install your microSD card, and connect the power and other optional cables. Two M4 threaded holes in the back of the display panel are available to screw the display directly to a panel board. -
Page 12: Power Supply
1. Remove power and disconnect all other connections to the Pi Touch Display Kit 2. Lay the Pi Touch Display Kit face down on a soft surface to avoid scratching 3. Unscrew the two lock nuts to free the back cradle from the aluminium display frame 4. -
Page 13: Software Installation
WARNING Improper handling of lithium batteries can result in an explosion of the batteries and/or release of harmful substances. Worn-out or defective batteries can compromise the function of this product. KEEP OUT OF REACH OF CHILDREN. Swallowing may lead to serious injury or death in as little as 2 hours due to chemical burns and potential perforation of the esophagus. -
Page 14: Technical Specifications
Technical specifications Power supply 12...28V⎓ (VDC) Reverse polarity protection with auto resetting fuse. Surge protection up to ±500V/2ohms 1.2/50μs 5Vcc maximum output current (Ta 22 °C) 1.8 A @ 12V PS 2.0 A @ 24V PS 530mA w/o Ethernet and battery Typical current consumption at VS+=12V⎓... -
Page 15: Dimensions
Dimensions User Guide... -
Page 16: Disposal
Disposal Waste Electrical & Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems). This marking on the product, accessories or literature indicates that the product should not be disposed of with other household waste at the end of their working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources. -
Page 17: Conformity Information
Conformity Information The Pi Touch Display Mechanical Kit (XPTM10X) and the Wall Mount Back Box (XPTB10X) comply with the essential requirements of the 2011/65/EU and 2015/863/EU (RoHS) directives and harmonised standard. The declaration of conformity is available on the Internet at the following address: https://dev.sferalabs.cc/pi-touch-display Refer to the documentation of the additional components for the relative conformity information.
