PROMARKS Promax DC-860 Operation Manual page 43

NO. PART NO.
1 DC80202000
2 2705154
3 2705306
4 2703308
5 D88K263001
6 D88K286000
7 D88K289000
8 VA04277000
9 D80K224000
10 2701164
11 DC80210000
12 2740168
13 DC80211000
14 D88K287000
15 D88K288000
16 D88K284000
17 2703307
18 3114463
19 3200955
20 2824011115
21 3200955
22 D88K268000
23 2703325
24 D80K413001
25 D80K414000
26 D88K222000
27 2909057
A DC862TBG00 Cushion bar assembly
Cover - vacuum suction
Flat washer M4
Split lock washer, M4
Round head screw M4 x 12
Sealing bar- bottom (TB)
Isolated plate-heating
Isolated plate
Spring
Inner plate
Socket set screw M4 x 10
Nut - bottom sealing bar support shaft
O-ring
Nut - bottom sealing bar support shaft
Fitting-heating
Joint plate - fitting
Sealing wire plate
Round head screw M4 x 10
Sealing silicon
Teflon tape
Sealing wire
Teflon tape
Teflon tape clamp
Round head screw M4 x 8
Gas nozzle (FB)
Gas nozzle nut
Flat plate
Pin-copper tube 1/8x5/16
DESCRIPTION
40
6.3.6-DC862TBP0G
QTY NOTE
1
2
2
2
4
8
8
8
4
8
8
8
8
8
8
8
16
4
4
4
4
8
64
28
OPTION
28
OPTION
4
8
4
