Frigidaire GLHS239ZC Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. GLHS239ZC
  6. Factory parts catalog
Frigidaire GLHS239ZC Factory Parts Catalog

Frigidaire GLHS239ZC Factory Parts Catalog

R134a gallery series
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
GLHS239ZCB0
GLHS239ZC
GLHS239ZCW0
GLHS239ZC
MARKET
North America
ENERGY GUIDE - 240592213
OWNER'S GUIDE - # 240389311
SERVICE DATA SHEET - #240389610
ELECTROLUX HOME PRODUCTS, INC.
P.O. BOX 212378, Augusta, GA 30917
SERIES
COLOR
R134a Gallery
black
R134a Gallery
white
Publication No.
5995390076
030505
-EN/SERVICE/KHB
357
PARTS CATALO
VOLT
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
GLHS239ZC
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY
G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GLHS239ZC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire GLHS239ZC

Summary of Contents for Frigidaire GLHS239ZC

  • Page 1 PRODUCT NO. BASE MODEL NO. GLHS239ZCB0 GLHS239ZC GLHS239ZCW0 GLHS239ZC MARKET North America ENERGY GUIDE - 240592213 OWNER’S GUIDE - # 240389311 SERVICE DATA SHEET - #240389610 ELECTROLUX HOME PRODUCTS, INC. P.O. BOX 212378, Augusta, GA 30917 SERIES COLOR R134a Gallery...

  • Page 2: Freezer Door

    Publication No. GLHS239ZC 5995390076 FREEZER DOOR 05/03...
  • Page 3 A = GLHS239ZC (GLHS239ZCB0) B = GLHS239ZC (GLHS239ZCW0) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts GLHS239ZC FREEZER DOOR PART NO DESCRIPTION 240390608 Gasket-frzr door, black, magnetic 240390604 Gasket-frzr door, white 240367302 Bin-door, frzr-upper 240359002 Bin-door 240358402 Bin-door, frzr-dispenser...

  • Page 4: Refrigerator Door

    Publication No. GLHS239ZC 5995390076 REFRIGERATOR DOOR 05/03...
  • Page 5 A = GLHS239ZC (GLHS239ZCB0) B = GLHS239ZC (GLHS239ZCW0) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts GLHS239ZC REFRIGERATOR DOOR PART NO DESCRIPTION 240390607 Gasket-refr door, black, magnetic 240390603 Gasket-refr door, white, magnetic 240363702 Bin-door,2-liter 240338303 Door, dairy, clear...
  • Page 6 Publication No. GLHS239ZC 5995390076 CABINET 05/03...
  • Page 7 A = GLHS239ZC (GLHS239ZCB0) B = GLHS239ZC (GLHS239ZCW0) POS. NO 14 # 14A# 66B* 100* # = Fast-moving Parts * = Non-Illustrated Parts GLHS239ZC CABINET PART NO DESCRIPTION 240435901 Cover-air duct 240475901 Cover-evap coil,lower 5303208309 Plug-hole,factory test 240505801 Switch,light/lamp 215486600...
  • Page 8 Publication No. GLHS239ZC 5995390076 SHELVES 05/03...
  • Page 9 A = GLHS239ZC (GLHS239ZCB0) B = GLHS239ZC (GLHS239ZCW0) POS. NO 42A* 42A* 140A # = Fast-moving Parts * = Non-Illustrated Parts GLHS239ZC SHELVES PART NO DESCRIPTION 240434603 Trim-basket 240350648 Shelf-freezer, glass, lower 240350647 Shelf-freezer, glass, upper 240588001 Light Bulb 240436702...
  • Page 10 Publication No. GLHS239ZC 5995390076 CONTROLS 05/03...
  • Page 11 A = GLHS239ZC (GLHS239ZCB0) B = GLHS239ZC (GLHS239ZCW0) POS. NO 13 # 137* 139* 199* # = Fast-moving Parts * = Non-Illustrated Parts GLHS239ZC CONTROLS PART NO DESCRIPTION 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240315802...
  • Page 12 Publication No. GLHS239ZC 5995390076 SYSTEM 05/03...
  • Page 13 A = GLHS239ZC (GLHS239ZCB0) B = GLHS239ZC (GLHS239ZCW0) POS. NO 14 # 15 # 29 # 30 # 55 # 60 # 61 # # = Fast-moving Parts * = Non-Illustrated Parts GLHS239ZC SYSTEM PART NO DESCRIPTION 240333602 Condenser 218679606...
  • Page 14 Publication No. GLHS239ZC 5995390076 DISPENSER 05/03...
  • Page 15 A = GLHS239ZC (GLHS239ZCB0) B = GLHS239ZC (GLHS239ZCW0) POS. NO 38A# 38C* # = Fast-moving Parts * = Non-Illustrated Parts GLHS239ZC DISPENSER PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet, inlet valve to ice maker 218976903 Tube-water inlet, inlet valve to filter...

  • Page 16: Ice Container

    Publication No. GLHS239ZC 5995390076 ICE CONTAINER 05/03...
  • Page 17 A = GLHS239ZC (GLHS239ZCB0) B = GLHS239ZC (GLHS239ZCW0) POS. NO 18 # 45 # # = Fast-moving Parts * = Non-Illustrated Parts GLHS239ZC ICE CONTAINER PART NO DESCRIPTION 5304428402 Auger-ice 5304404343 Cam-drive 218815300 Container-ice,bucket only 5304404346 Drum-ice disp 5304422805 Front-ice container...

  • Page 18: Ice Maker

    Publication No. GLHS239ZC 5995390076 ICE MAKER 05/03...
  • Page 19 A = GLHS239ZC (GLHS239ZCB0) B = GLHS239ZC (GLHS239ZCW0) POS. NO 11 # 12 # 13 # 15 # 17 # 55 # # = Fast-moving Parts * = Non-Illustrated Parts GLHS239ZC ICE MAKER PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet, inlet valve to ice maker...

  • Page 20: Wiring Schematic

    Publication No. GLHS239ZC 5995390076 WIRING SCHEMATIC 05/03...

  • Page 21: Wiring Diagram

    GLHS239ZC Publication No. 5995390076 WIRING DIAGRAM # = Fast-moving Parts 05/03 * = Non-Illustrated Parts...
