PRODUCT NO.
BASE MODEL NO.
GLHS264ZAB0
GLHS264ZA
GLHS264ZAQ0
GLHS264ZA
GLHS264ZAW0
GLHS264ZA
MARKET
North America
WIRING DIAGRAM - # 240443001
OWNER'S GUIDE - # 240389302
SERVICE DATA SHEET - #240389604
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. BOX 212378, Augusta, GA 30917
SERIES
COLOR
R134a Gallery
black
R134a Gallery
bisque
R134a Gallery
white
Publication No.
5995360483
011025
-EN/SERVICE/KHB
357
PARTS CATALO
VOLTS
115
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
GLHS264ZA
©2001 White Consolidated Industries, Inc.
All rights reserved
FACTORY
G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GLHS264ZA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire GLHS264ZA

Summary of Contents for Frigidaire GLHS264ZA

  • Page 1 PRODUCT NO. BASE MODEL NO. GLHS264ZAB0 GLHS264ZA GLHS264ZAQ0 GLHS264ZA GLHS264ZAW0 GLHS264ZA MARKET North America WIRING DIAGRAM - # 240443001 OWNER’S GUIDE - # 240389302 SERVICE DATA SHEET - #240389604 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O. BOX 212378, Augusta, GA 30917...

  • Page 2: Freezer Door

    Publication No. GLHS264ZA 5995360483 FREEZER DOOR 10/01...
  • Page 3 A = GLHS264ZA (GLHS264ZAB0) B = GLHS264ZA (GLHS264ZAQ0) C = GLHS264ZA (GLHS264ZAW0) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts GLHS264ZA FREEZER DOOR PART NO DESCRIPTION 240390606 A - - Gasket-frzr door,black ,magnetic 240390602 - B C Gasket-frzr door,white ,magnetic...

  • Page 4: Refrigerator Door

    Publication No. GLHS264ZA 5995360483 REFRIGERATOR DOOR 10/01...
  • Page 5 A = GLHS264ZA (GLHS264ZAB0) B = GLHS264ZA (GLHS264ZAQ0) C = GLHS264ZA (GLHS264ZAW0) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts GLHS264ZA REFRIGERATOR DOOR PART NO DESCRIPTION 240390605 A - - Gasket-refr door,black ,magnetic 240390601 - B C Gasket-refr door,white ,magnetic...
  • Page 6 Publication No. GLHS264ZA 5995360483 CABINET 10/01...
  • Page 7 A = GLHS264ZA (GLHS264ZAB0) B = GLHS264ZA (GLHS264ZAQ0) C = GLHS264ZA (GLHS264ZAW0) POS. NO 14 # 14A# 66B* 100* # = Fast-moving Parts * = Non-Illustrated Parts GLHS264ZA CABINET PART NO DESCRIPTION 240435902 A B C Cover-air duct 240475902 A B C...
  • Page 8 Publication No. GLHS264ZA 5995360483 SHELVES 10/01...
  • Page 9 A = GLHS264ZA (GLHS264ZAB0) B = GLHS264ZA (GLHS264ZAQ0) C = GLHS264ZA (GLHS264ZAW0) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts GLHS264ZA SHELVES PART NO DESCRIPTION 240434602 A B C Trim-basket 240338802 A B C Shelf-freezer,flip-up 240338704 A B C...
  • Page 10 Publication No. GLHS264ZA 5995360483 CONTROLS 10/01...
  • Page 11 A = GLHS264ZA (GLHS264ZAB0) B = GLHS264ZA (GLHS264ZAQ0) C = GLHS264ZA (GLHS264ZAW0) POS. NO 13 # 21 # 115* 137* 199* # = Fast-moving Parts * = Non-Illustrated Parts GLHS264ZA CONTROLS PART NO DESCRIPTION 5308000010 A B C Fan Blade,red ,evaporator fan...
  • Page 12 Publication No. GLHS264ZA 5995360483 SYSTEM 10/01...
  • Page 13 A = GLHS264ZA (GLHS264ZAB0) B = GLHS264ZA (GLHS264ZAQ0) C = GLHS264ZA (GLHS264ZAW0) POS. NO 14 # 15 # 29 # 30 # 55 # 60 # 61 # # = Fast-moving Parts * = Non-Illustrated Parts GLHS264ZA SYSTEM PART NO...
  • Page 14 Publication No. GLHS264ZA 5995360483 DISPENSER 10/01...
  • Page 15 A = GLHS264ZA (GLHS264ZAB0) B = GLHS264ZA (GLHS264ZAQ0) C = GLHS264ZA (GLHS264ZAW0) POS. NO 38A# # = Fast-moving Parts * = Non-Illustrated Parts GLHS264ZA DISPENSER PART NO DESCRIPTION 218976405 A B C Tube-water inlet 218976901 A B C Tube-water inlet, inlet valve to ice maker...

  • Page 16: Ice Container

    Publication No. GLHS264ZA 5995360483 ICE CONTAINER 10/01...
  • Page 17 A = GLHS264ZA (GLHS264ZAB0) B = GLHS264ZA (GLHS264ZAQ0) C = GLHS264ZA (GLHS264ZAW0) POS. NO 18 # 45 # # = Fast-moving Parts * = Non-Illustrated Parts GLHS264ZA ICE CONTAINER PART NO DESCRIPTION 5304404344 A B C Auger-ice 5304404343 A B C...

  • Page 18: Ice Maker

    Publication No. GLHS264ZA 5995360483 ICE MAKER 10/01...
  • Page 19 A = GLHS264ZA (GLHS264ZAB0) B = GLHS264ZA (GLHS264ZAQ0) C = GLHS264ZA (GLHS264ZAW0) POS. NO 11 # 12 # 13 # 15 # 17 # 55 # 55*# 55*# # = Fast-moving Parts * = Non-Illustrated Parts GLHS264ZA ICE MAKER PART NO...

  • Page 20: Wiring Schematic

    Publication No. GLHS264ZA 5995360483 WIRING SCHEMATIC 10/01...

  • Page 21: Wiring Diagram

    GLHS264ZA Publication No. 5995360483 WIRING DIAGRAM # = Fast-moving Parts 10/01 * = Non-Illustrated Parts...
