Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
GLHS66EFSB0
Series
R134a Gallery
Color
stainless/black
Volts
115
Wiring Diagram
241689601
Owner's Guide
241695101
Market
North America
Energy Guide
241649276
Service Data Sheet 240389627
Publication No.
5995465092
06/04/12
(EN/SERVICE/KHB)
357
Copyright
SIDE-BY-SIDE
REFRIGERATOR
Model No.
GLHS66EF
©
2006 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Table of Contents
Related Manuals for Frigidaire GLHS66EF
Summary of Contents for Frigidaire GLHS66EF
- Page 1 R134a Gallery Color stainless/black Volts Wiring Diagram 241689601 Owner's Guide 241695101 Market North America Energy Guide 241649276 Service Data Sheet 240389627 SIDE-BY-SIDE REFRIGERATOR Model No. GLHS66EF Publication No. 5995465092 06/04/12 (EN/SERVICE/KHB) © Copyright 2006 Electrolux Home Products, Inc. All rights reserved.
-
Page 2: Freezer Door
Publication No: 5995465092 GLHS66EFSB0 FREEZER DOOR 04/06... - Page 3 POS. NO PART NO. 241674806 240334201 240351601 241668195 240581906 240359108 218781100 240598401 240521302 240328204 240328404 240359203 241525101 240421701 218396700 215503200 240352102 240552102 5303918256 # Functional Parts * Non-Illustrated Parts GLHS66EFSB0 FREEZER DOOR DESCRIPTION Gasket-frzr door, black, magnetic Bin-door, frzr-upper Bin-door Door-frzr, stainless, complete assy Door Stop, black, frzr Handle-door, black, LH...
-
Page 4: Refrigerator Door
Publication No: 5995465092 GLHS66EFSB0 REFRIGERATOR DOOR 04/06... - Page 5 240328404 240359203 240430305 240421701 218396700 215503200 # Functional Parts * Non-Illustrated Parts GLHS66EFSB0 REFRIGERATOR DOOR DESCRIPTION Gasket-refr door, black, magnetic Bin-door, pseudo, bottom Door-dairy Nameplate Door Stop, black, ref Door-refr, stainless, complete assy Handle-door, black, RH Screw, pan head, 8-18 x 0.625...
- Page 6 Publication No: 5995465092 04/06 GLHS66EFSB0 CABINET N58BAAAAB3...
- Page 7 POS. NO PART NO. 240435906 240475907 5303208309 240505801 241547901 218252200 240457702 240402701 240335501 241603701 241603702 240337603 240327201 240327007 241550801 241550701 240578901 240335003 241500301 240349402 218781100 5304424968 240518802 240324406 5308016566 5304418225 5303316859 241574602 218249808 240380101 216850900 240423701 100* 240350802 240481601 240396801 240479601 5303321321 # Functional Parts...
- Page 8 Publication No: 5995465092 04/06 GLHS66EFSB0 SHELVES N58SKBCBB1...
- Page 9 POS. NO PART NO. 241510604 241657602 241657504 240324101 241555401 241513901 16A* 241537603 240355203 240355205 240350702 240362101 240350902 240351005 240349801 240362201 240351205 240430706 240430702 240356501 240349701 42A* 240349901 42A* 240350001 240350602 240350603 240564401 240530504 240343002 240343102 240342805 5308016566 240545303 240326302 218493100 240351301 240342901 215005100...
- Page 10 Publication No: 5995465092 GLHS66EFSB0 CONTROLS N58TCAAAB4 04/06...
- Page 11 POS. NO PART NO. 5308000010 215474201 241563601 240369702 241517701 241555401 16 # 241513901 241608801 17*# 241663601 241603908 241608401 241608501 5304452072 5303001259 241608901 5308016566 241637201 241600902 240396401 137* 240396701 240397301 240396002 139* 240526901 241563501 149* 241528306 241505101 241505001 240397401 240397501 199* 240398401 240397601 # Functional Parts...
- Page 12 Publication No: 5995465092 GLHS66EFSB0 SYSTEM N58CAAAAA10 04/06...
- Page 13 POS. NO PART NO. 240333603 218679607 218944001 241586801 241651601 241663601 14 # 240316107 15 # 5303918284 5308000110 5303918214 240330008 218252200 218513300 240491501 241637401 5303918314 30 # 241527803 241544101 240405201 240555001 215174700 5308016566 218909915 240542601 218897002 5304430246 240346701 240359401 60 # 240525402 61 # 240524101...
-
Page 14: Ice And Water Dispenser
Publication No: 5995465092 GLHS66EFSB0 ICE & WATER DISPENSER 04/06... - Page 15 POS. NO PART NO. 218976409 218976901 218976903 218976907 240561701 241678703 5304422013 5304426649 240323976 5304421616 240548901 5304421619 241649003 5304422026 5304422025 5304421628 5304421624 5304421625 5304421629 5304421620 5304421824 38 # 241708202 38A# 5304421617 38C# 241708309 38C* 5304430811 5304421627 5304421829 215296300 240363401 5304421830 5304421622 5304421621 5304421615 5304421831...
-
Page 16: Ice Container
Publication No: 5995465092 GLHS66EFSB0 ICE CONTAINER 04/06... - Page 17 POS. NO PART NO. 5304428402 5304404343 218815300 5304404346 5304422805 5304404337 5304404359 241555401 241559801 5304404345 18 # 5304440392 18*# 240352601 18*# 5304404335 5304404332 215285100 5304404347 5304404362 5304420654 5304404351 5304404349 5304404353 5304404352 5304404348 5304404350 5304404356 5304404365 5304404358 218359200 45 # 5304404333 5304406816 5304406817 5304406818 5304406819...
-
Page 18: Ice Maker
Publication No: 5995465092 GLHS66EFSB0 ICE MAKER 04/06... - Page 19 POS. NO PART NO. 218976409 218976901 218976903 218976907 240561701 5304420650 3206299 3206301 3206303 3206305 3206306 3206312 3206313 3206315 11 # 3206319 12 # 240352601 13 # 3206322 5304420652 15 # 3206324 5304420653 17 # 5303320545 3206328 3206330 5304408581 3206332 3206333 5304408582 3206335 3206336...
-
Page 20: Wiring Schematic
Publication No: 5995465092 FF THERMISTOR FRZ THERMISTOR D I S P E N S E R A S S ' Y F R E E Z E R L I G H T / S A F E T Y S W I T C H 04/06 GLHS66EFSB0 WIRING SCHEMATIC... -
Page 21: Wiring Diagram
A U G E R A S S ' Y F A S T I C E / F R E E Z E D E F T H E R M O E V A P F A N F F D O O R S W I T C H F R Z D O O R S W I T C H D E F R O S T P O W E R...
