Frigidaire FRTG16X6A Factory Parts Catalog

Frigidaire FRTG16X6A Factory Parts Catalog

Top mount refrigerator 134a system series
Hide thumbs

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FRTG16X6AQ1
FRTG16X6A
FRTG16X6AW1
FRTG16X6A
MARKET
INTERNATIONAL
International
3 Parkway Center
Pittsburg, PA 15220
SERIES
COLOR
134A SYSTEM
bisque
134A SYSTEM
white
Publication No.
5995373692
020606
-EN/SERVICE/DCS
390
VOLTS
115
115

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRTG16X6A and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRTG16X6A

Summary of Contents for Frigidaire FRTG16X6A

  • Page 1 PRODUCT NO. BASE MODEL NO. FRTG16X6AQ1 FRTG16X6A FRTG16X6AW1 FRTG16X6A MARKET INTERNATIONAL International 3 Parkway Center Pittsburg, PA 15220 SERIES COLOR 134A SYSTEM bisque 134A SYSTEM white Publication No. 5995373692 020606 -EN/SERVICE/DCS VOLTS...
  • Page 2 DOOR...
  • Page 3 A = FRTG16X6A (FRTG16X6AQ1) B = FRTG16X6A (FRTG16X6AW1) POS. NO 240514601 240514602 240331410 240331412 240311502 240331502 240311501 240331501 240337707 240331411 240381302 240381301 240415402 240415401 240415203 240415201 240312407 240312403 240312408 240312404 240494002 240494001 240415502 240415501 218397511 218397501 240383401 240521301 218252200 240311201...
  • Page 4 CABINET...
  • Page 5 A = FRTG16X6A (FRTG16X6AQ1) B = FRTG16X6A (FRTG16X6AW1) POS. NO 240355401 240367001 5303001028 240367401 5308000010 5300157666 5303292396 240462004 240532101 10*# 240385401 5303208309 240366801 240374401 13 # 240369701 215474201 218931001 5303292397 240433201 240411901 218252200 215774919 215774901 240335501 240357104 240357102 240311301 240357004...
  • Page 6 SHELVES...
  • Page 7 A = FRTG16X6A (FRTG16X6AQ1) B = FRTG16X6A (FRTG16X6AW1) POS. NO 215667501 240358001 5303299664 240545001 240362601 14 # 240505801 240436702 16 # 241500701 240368001 17*# 240375501 240360801 21 # 5304421256 240468201 23 # 240375801 5303001259 240372401 240372404 240364744 240361203 240361301 240364503...
  • Page 8 SYSTEM...
  • Page 9 A = FRTG16X6A (FRTG16X6AQ1) B = FRTG16X6A (FRTG16X6AW1) POS. NO 240444401 218944001 240375501 240385401 240496101 14 # 5303918203 15 # 5303918257 5308000110 240434001 240362301 240362401 21 # 5303918202 240330005 218513300 240491501 240332603 29 # 5303918264 30 # 218721120 240493301 240405201...

  • Page 10: Wiring Schematic

    WIRING SCHEMATIC...

  • Page 11: Wiring Diagram

    WIRING DIAGRAM...
