PRODUCT NO.
BASE MODEL NO.
FRT21HBBSB0
FRT21HBBS
MARKET
North America
ENERGY GUIDE - 240465041
OWNER'S GUIDE - 240400105
SERVICE DATA SHEET - 240379009
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
stainless/black
Publication No.
5995371597
020507
-EN/SERVICE /KC
357
FACTORY
PARTS CATALO
VOLTS
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT21HBBS
©2002 Electrolux home Products, Inc.
All rights reserved
G
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRT21HBBS
Summary of Contents for Frigidaire FRT21HBBS
- Page 1 PRODUCT NO. BASE MODEL NO. FRT21HBBSB0 FRT21HBBS MARKET North America ENERGY GUIDE - 240465041 OWNER’S GUIDE - 240400105 SERVICE DATA SHEET - 240379009 ELECTROLUX HOME PRODUCTS, INC P.O. Box 212378, Augusta, GA 30917 SERIES COLOR R134a stainless/black TOP MOUNT REFRIGERATOR FRT21HBBS Publication No.
- Page 2 Publication No. FRT21HBBSB0 5995371597 DOOR 05/02...
- Page 3 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRT21HBBSB0 DOOR PART NO DESCRIPTION 240514611 Gasket,frzr door seal ,black ,magnetic 240514612 Gasket,refr door seal ,black ,magnetic 240338303 Door,dairy ,clear 240450331 Door,frzr ,stainless steel 240416304 Nameplate,black 240312405 Door Stop,black ,ref 240312406 Door Stop,black ,frzr 240383603...
- Page 4 Publication No. FRT21HBBSB0 5995371597 CABINET 05/02...
- Page 5 POS. NO 10*# 13 # # = Fast-moving Parts * = Non-Illustrated Parts FRT21HBBSB0 CABINET PART NO DESCRIPTION 240355404 Cover-fan 240433201 Screw,hex washer head ,8-18 x 0.375 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240313606 Cover-evap coil 240371303 Seal,insulation ,53.23 in.
- Page 6 Publication No. FRT21HBBSB0 5995371597 SHELVES 05/02...
- Page 7 POS. NO 14 # 16 # 21 # 23 # 130* # = Fast-moving Parts * = Non-Illustrated Parts FRT21HBBSB0 SHELVES PART NO DESCRIPTION 215667501 Tray,ice cube ,plastic 240358003 Shelf,freezer ,full-width ,wire 5303299664 Spacer,shelf 240417802 Diffuser-air,top 240362601 Diffuser,air ,bottom 240413601 Switch,light/lamp ,rocker 240436702 Light Bulb/Lamp,A-15 ,40 W ,120 V ,miniature...
- Page 8 Publication No. FRT21HBBSB0 5995371597 SYSTEM 05/02...
- Page 9 POS. NO 6* # 6* # 14 # 15 # 21 # 29 # 30 # 55 # 60 # 61 # # = Fast-moving Parts * = Non-Illustrated Parts FRT21HBBSB0 SYSTEM PART NO DESCRIPTION 240444401 Condenser,dynamic 218944001 Drier-filter,R134a System 240496101 Wiring Harness,machine compt ,w/electric cord 240375501...
-
Page 10: Wiring Schematic
Publication No. FRT21HBBSB0 5995371597 WIRING SCHEMATIC 05/02... -
Page 11: Wiring Diagram
FRT21HBBSB0 Publication No. 5995371597 WIRING DIAGRAM # = Fast-moving Parts 05/02 * = Non-Illustrated Parts...
