Introduction
This document explains the functioning of the "smart monitoring system" and also serves as
a quick reference manual to operate the system. The smart monitoring system works on
®
ZigBee
wireless technology and measures temperature, humidity and light intensity of 9
remote and different locations simultaneously. The system also demonstrates the wireless
control of home appliances and can serve as a basis for many new systems.
The objective of this demonstration board is to design a complete system which
demonstrates the effectiveness of low data rate wireless solutions from ST in automating
various measurements for weather parameters. This system can be further interfaced to
take an appropriate action based on the parameters being monitored. The system can very
easily be modified to control various household appliances by suitable additional hardware.
This system uses various devices, the most relevant are the STM32x (microcontroller),
SPZB260 (ZigBee
STLM20 (temperature sensor) and various power supply components along with the battery
charger. The system has been designed taking future expandability into consideration.
The system can be powered up using:
External power supply
3.7 V Li-Ion battery
To summarize, the key features of the system are:
Wireless network
Monitoring of weather parameters (temperature, humidity, light intensity)
Wireless light control application
Node movement and simultaneous node movement detection
Various weather warning configurations and alarm messages
TFT display with touchscreen
Real-time clock along with alarm configurations
Data logging for more than one year
GUI for data reading, saving and analysis using graphs
Power management system
Battery charging capability
Embedded in-circuit programming capability using JTAG
January 2010
www.BDTIC.com/ST
Smart monitoring system STEVAL-IFS014V1
and STEVAL-IFS015V1, based on the STM32x
®
device), LIS331DLH (MEMS), STMPE811 (touchscreen controller),
Doc ID 16752 Rev 1
UM0857
User manual
1/66
www.st.com
