Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FRT8S6ESB6 FRT8S6ESK6
Series
R134a
Color
stainless (RH) stainless (LH)
Volts
115
Wiring Diagram
240398801
Owner's Guide
240400112
Market
North America North America
Energy Guide
241613706
Service Data Sheet
240379015
Installation Instructions 240568300
Publication No.
5995449328
05/09/27
(EN/SERVICE/KHB)
390
R134a
115
240398801
240400112
241613706
240379015
240568300
TOP-MOUNT
REFRIGERATOR
Model No.
FRT8S6ES
©
Copyright
2005 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Related Manuals for Frigidaire FRT8S6ES
Summary of Contents for Frigidaire FRT8S6ES
- Page 1 240400112 240400112 Market North America North America Energy Guide 241613706 241613706 Service Data Sheet 240379015 240379015 Installation Instructions 240568300 240568300 Publication No. 5995449328 05/09/27 (EN/SERVICE/KHB) Copyright TOP-MOUNT REFRIGERATOR Model No. FRT8S6ES © 2005 Electrolux Home Products, Inc. All rights reserved.
- Page 2 Publication No: 5995449328 09/05 FRT8S6ES DOOR N05DCDBCA2...
- Page 3 240338001 240495804 218490901 # Functional Parts * Non-Illustrated Parts FRT8S6ES DOOR A FRT8S6ES (FRT8S6ESB6) B FRT8S6ES (FRT8S6ESK6) DESCRIPTION Gasket-frzr door, black, magnetic Gasket-refr door, black, magnetic Door-dairy, w/o graphics, clear Door, frzr, stainless, RH, complete assy Door-frzr, stainless, LH, complete assy...
- Page 4 Publication No: 5995449328 09/05 FRT8S6ES CABINET N05BBAABA22...
- Page 5 5303316859 241574607 241500302 241624301 240479601 5303321321 # Functional Parts * Non-Illustrated Parts FRT8S6ES CABINET A FRT8S6ES (FRT8S6ESB6) B FRT8S6ES (FRT8S6ESK6) DESCRIPTION Cover-fan Knob-damper control Nut, push-on Damper-fan cover Fan Blade, red, evaporator fan Bushing-motor mtg, (2) Bracket-motor mtg, front Cover-evap coil...
- Page 6 Publication No: 5995449328 09/05 FRT8S6ES SHELVES N05SAAAFI19...
- Page 7 241613501 241613502 240337107 240530810 240350643 5308016566 # Functional Parts * Non-Illustrated Parts FRT8S6ES SHELVES A FRT8S6ES (FRT8S6ESB6) B FRT8S6ES (FRT8S6ESK6) DESCRIPTION Tray, ice cube, plastic Shelf, freezer, full-width, wire Diffuser, air, top Diffuser, air, bottom Switch-light/lamp Light Bulb Socket-light Control Box...
- Page 8 Publication No: 5995449328 FRT8S6ES SYSTEM N05CAAAAA18 09/05...
- Page 9 5304418225 5303316859 240500801 241665801 5303918263 5303918222 # Functional Parts * Non-Illustrated Parts FRT8S6ES SYSTEM A FRT8S6ES (FRT8S6ESB6) B FRT8S6ES (FRT8S6ESK6) DESCRIPTION Condenser, dynamic Drier-filter, R134a System Harness-wiring, machine compt Harness-wiring, freezer Wiring Harness, control box Defrost Heater Kit Evaporator Kit...
-
Page 10: Wiring Schematic
Publication No: 5995449328 FRT8S6ES WIRING SCHEMATIC 09/05... -
Page 11: Wiring Diagram
FRT8S6ES Publication No: 5995449328 WIRING DIAGRAM 09/05 # Functional Parts * Non-Illustrated Parts...
