Product No.
FRT8IB5EQ2 FRT8IB5EW2 FRT8IB5EW4
Series
R134a
Color
bisque
Volts
115
Wiring Diagram
240398801
Owner's Guide
240400112
Market
North America North America North America
Energy Guide
241613703
Service Data Sheet
241643300
Installation Instructions 240568300
240398801.eps 240398601.eps
Publication No.
5995435566
05/04/27
(EN/SERVICE/WC)
390
R134a
R134a
white
white
115
115
240398801
240398801
240400112
240400112
241613703
241613703
241643300
240379015
240568300
240568300
TOP-MOUNT
REFRIGERATOR WITH
ICE-MAKER
Model No.
FRT8IB5E
©
Copyright
2005 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRT8IB5E
Summary of Contents for Frigidaire FRT8IB5E
- Page 1 240398801 240400112 240400112 240400112 North America North America North America 241613703 241613703 241613703 241643300 241643300 240379015 240568300 240568300 TOP-MOUNT REFRIGERATOR WITH ICE-MAKER Model No. FRT8IB5E Publication No. 5995435566 05/04/27 (EN/SERVICE/WC) © Copyright 2005 Electrolux Home Products, Inc. All rights reserved.
- Page 2 Publication No: 5995435566 04/05 FRT8IB5E DOOR N05DAACKA1...
- Page 3 218252200 240527101 215870633 215870629 218676004 # Functional Parts * Non-Illustrated Parts FRT8IB5E DOOR A FRT8IB5E (FRT8IB5EQ2) B FRT8IB5E (FRT8IB5EW2) C FRT8IB5E (FRT8IB5EW4) DESCRIPTION A B - Gasket-frzr door, white, magnetic - - C Gasket-frzr door, white, magnetic A B -...
- Page 4 Publication No: 5995435566 04/05 FRT8IB5E CABINET N05BBAAAA11...
- Page 5 5304418225 5303316859 5303001479 241624301 5304414035 5303305324 # Functional Parts * Non-Illustrated Parts FRT8IB5E CABINET A FRT8IB5E (FRT8IB5EQ2) B FRT8IB5E (FRT8IB5EW2) C FRT8IB5E (FRT8IB5EW4) DESCRIPTION A B C Cover-fan A B C Knob-damper control A B C Nut, push-on A B C...
- Page 6 Publication No: 5995435566 04/05 FRT8IB5E SHELVES N05SADDEA3...
- Page 7 240361301 240337107 240385201 240350608 5308016566 # Functional Parts * Non-Illustrated Parts FRT8IB5E SHELVES A FRT8IB5E (FRT8IB5EQ2) B FRT8IB5E (FRT8IB5EW2) C FRT8IB5E (FRT8IB5EW4) DESCRIPTION A B C Shelf-freezer, "table type" A B C Spacer, shelf A B C Diffuser, air, top...
- Page 8 Publication No: 5995435566 04/05 FRT8IB5E SYSTEM N05CBBBAC1...
- Page 9 241505701 241544301 240396801 5303918263 5303918234 # Functional Parts * Non-Illustrated Parts FRT8IB5E SYSTEM A FRT8IB5E (FRT8IB5EQ2) B FRT8IB5E (FRT8IB5EW2) C FRT8IB5E (FRT8IB5EW4) DESCRIPTION A B C Condenser, static A B C Grommet, rubber, black, cond tube/wire A B C Spacer, condenser tube, black A B C Spacer-cond tube, round, 5/8 OD x .81"lg...
-
Page 10: Ice Maker
Publication No: 5995435566 FRT8IB5E ICE MAKER 04/05... - Page 11 241523501 55 # 240519601 # Functional Parts * Non-Illustrated Parts FRT8IB5E ICE MAKER A FRT8IB5E (FRT8IB5EQ2) B FRT8IB5E (FRT8IB5EW2) C FRT8IB5E (FRT8IB5EW4) DESCRIPTION A B C Tube-water inlet, inlet valve, to ice maker A B C Seal-water inlet, inlet valve, to ice maker...
- Page 12 Publication No: 5995435566 FRT8IB5E ICE MAKER 04/05...
- Page 13 240352409 241642601 218888001 # Functional Parts * Non-Illustrated Parts FRT8IB5E ICE MAKER A FRT8IB5E (FRT8IB5EQ2) B FRT8IB5E (FRT8IB5EW2) C FRT8IB5E (FRT8IB5EW4) DESCRIPTION A B C Bracket-leveling, ICE MAKER A B C Screw-IM brkt mtg, hex washer head, 8-32D x 0.375 A B C Clamp, 0.31 ID, steel, copper wtr line...
-
Page 14: Wiring Schematic
Publication No: 5995435566 FRT8IB5E WIRING SCHEMATIC 04/05... -
Page 15: Wiring Diagram
FRT8IB5E Publication No: 5995435566 WIRING DIAGRAM 04/05 # Functional Parts * Non-Illustrated Parts...
