Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FRT8G6FQ0 FRT8G6FW0 FRT8G6FMB0
Series
R134a
Color
bisque
Volts
115
Wiring Diagram
240398801
Owner's Guide
241694400
Market
North America North America North America
Energy Guide
241613725
Service Data Sheet
240379018
Installation Instructions 240568301
Publication No.
5995462867
06/03/07
(EN/SERVICE/DCS)
390
R134a
R134a
white
silvermist
115
115
240398801
240398801
241694400
241694400
241613725
241613725
240379018
240379018
240568301
240568301
TOP-MOUNT
REFRIGERATOR
Model No.
FRT8G6F
©
Copyright
2006 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Related Manuals for Frigidaire FRT8G6F
Summary of Contents for Frigidaire FRT8G6F
- Page 1 240398801 240398801 240398801 241694400 241694400 241694400 North America North America North America 241613725 241613725 241613725 240379018 240379018 240379018 240568301 240568301 TOP-MOUNT REFRIGERATOR Model No. FRT8G6F Publication No. 5995462867 06/03/07 (EN/SERVICE/DCS) © Copyright 2006 Electrolux Home Products, Inc. All rights reserved.
- Page 2 Publication No: 5995462867 03/06 FRT8G6F DOOR N05DAACKA1...
- Page 3 240527102 215870633 215870629 215870636 218676004 # Functional Parts * Non-Illustrated Parts FRT8G6F DOOR A FRT8G6F (FRT8G6FQ0) B FRT8G6F (FRT8G6FW0) C FRT8G6FM (FRT8G6FMB0) DESCRIPTION A B - Gasket-frzr door, white, magnetic - - C Gasket-frzr door, black, magnetic A B -...
- Page 4 Publication No: 5995462867 03/06 FRT8G6F CABINET N05BBAABA22...
- Page 5 240442701 240442703 240368206 240368205 240368207 5308016566 # Functional Parts * Non-Illustrated Parts FRT8G6F CABINET A FRT8G6F (FRT8G6FQ0) B FRT8G6F (FRT8G6FW0) C FRT8G6FM (FRT8G6FMB0) DESCRIPTION A B C Cover-fan A B C Knob-damper control A B C Nut, push-on A B C...
- Page 6 Publication No: 5995462867 03/06 FRT8G6F CABINET N05BBAABA22...
- Page 7 5304414035 5303321319 5303321321 # Functional Parts * Non-Illustrated Parts FRT8G6F CABINET A FRT8G6F (FRT8G6FQ0) B FRT8G6F (FRT8G6FW0) C FRT8G6FM (FRT8G6FMB0) DESCRIPTION A B C Roller, compressor base, rear, (2) A B C Rivet, flat head, 1/4 OD x 1-3/4, roller pin...
- Page 8 Publication No: 5995462867 03/06 FRT8G6F SHELVES N05SAAAEF16...
- Page 9 240530601 240530701 240350608 5308016566 215005100 # Functional Parts * Non-Illustrated Parts FRT8G6F SHELVES A FRT8G6F (FRT8G6FQ0) B FRT8G6F (FRT8G6FW0) C FRT8G6FM (FRT8G6FMB0) DESCRIPTION A B C Tray, ice cube, plastic A B C Shelf, freezer, full-width, wire A B C...
- Page 10 Publication No: 5995462867 FRT8G6F SYSTEM N05CAAAAA18 03/06...
- Page 11 240500801 241665801 240396801 5303918263 5303918222 # Functional Parts * Non-Illustrated Parts FRT8G6F SYSTEM A FRT8G6F (FRT8G6FQ0) B FRT8G6F (FRT8G6FW0) C FRT8G6FM (FRT8G6FMB0) DESCRIPTION A B C Condenser, dynamic A B C Drier-filter, R134a System A B C Harness-wiring, machine compt...
-
Page 12: Wiring Schematic
Publication No: 5995462867 FRT8G6F WIRING SCHEMATIC 03/06... -
Page 13: Wiring Diagram
FRT8G6F Publication No: 5995462867 WIRING DIAGRAM 03/06 # Functional Parts * Non-Illustrated Parts...
