Factory Parts Catalog
N05L00004.eps N05DBDCKA0.eps N05BBAABA6.eps N05SAAAEF14.eps
N05CABBAB6.eps
240398801.eps 240398601.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
FRT21KG3DQ0 FRT21KG3DW0
Series
R134a
Color
bisque
Volts
115
Wiring Diagram
240398801
Owner's Guide
240400111
Market
North America
Service Data Sheet
240379014
Installation Instructions 240568300
Publication No.
5995412607
04/07/01
(EN/SERVICE/WC)
390
R134a
white
115
240398801
240400111
North America
240379014
240568300
TOP-MOUNT
REFRIGERATOR
Model No.
FRT21KG3D
©
Copyright
2004 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRT21KG3D
Summary of Contents for Frigidaire FRT21KG3D
- Page 1 P.O. Box 212378, Augusta, GA 30917 FRT21KG3DQ0 FRT21KG3DW0 R134a R134a bisque white 240398801 240398801 240400111 240400111 North America North America 240379014 240379014 240568300 TOP-MOUNT REFRIGERATOR Model No. FRT21KG3D Publication No. 5995412607 04/07/01 (EN/SERVICE/WC) © Copyright 2004 Electrolux Home Products, Inc. All rights reserved.
- Page 2 Publication No: 5995412607 FRT21KG3D DOOR 07/04...
- Page 3 240521301 218252200 240527101 218396700 215503200 # Functional Parts * Non-Illustrated Parts FRT21KG3D DOOR A FRT21KG3D (FRT21KG3DQ0) B FRT21KG3D (FRT21KG3DW0) DESCRIPTION Gasket, seal, white, frzr door, magnetic Gasket, seal, white, refr door, magnetic Rack-door Rack-door, 4B Door-dairy, w/o graphics, white Rack-door...
- Page 4 Publication No: 5995412607 FRT21KG3D CABINET 07/04...
- Page 5 241500301 216850900 218990901 240479601 5304414035 5303305324 # Functional Parts * Non-Illustrated Parts FRT21KG3D CABINET A FRT21KG3D (FRT21KG3DQ0) B FRT21KG3D (FRT21KG3DW0) DESCRIPTION Cover-fan Knob-damper control Nut, push-on Damper-fan cover Fan Blade, red, evaporator fan Bushing-motor mtg, (2) Bracket-motor mtg, front Cover-evap coil, w/o light...
- Page 6 Publication No: 5995412607 07/04 FRT21KG3D SHELVES N05SAAAEF14...
- Page 7 240561502 240530601 240530701 240350609 5308016566 215005100 # Functional Parts * Non-Illustrated Parts FRT21KG3D SHELVES A FRT21KG3D (FRT21KG3DQ0) B FRT21KG3D (FRT21KG3DW0) DESCRIPTION Tray, ice cube, plastic Shelf, freezer, full-width, wire Spacer, shelf Diffuser-air, top Diffuser, air, bottom Switch-light/lamp Light Bulb Socket-light/lamp...
- Page 8 Publication No: 5995412607 FRT21KG3D SYSTEM N05CABBAB6 07/04...
- Page 9 240493101 240409302 240396801 5303918210 5304421289 # Functional Parts * Non-Illustrated Parts FRT21KG3D SYSTEM A FRT21KG3D (FRT21KG3DQ0) B FRT21KG3D (FRT21KG3DW0) DESCRIPTION Condenser, dynamic Drier-filter, R134a System Harness-wiring, machine compt Wiring Harness, control box Wiring Harness, freezer section Defrost Heater Kit Evaporator Kit...
-
Page 10: Wiring Schematic
Publication No: 5995412607 FRT21KG3D WIRING SCHEMATIC 07/04... -
Page 11: Wiring Diagram
FRT21KG3D Publication No: 5995412607 WIRING DIAGRAM 07/04 # Functional Parts * Non-Illustrated Parts...
