Frigidaire FRT21KG3C Factory Parts Catalog
Top mount refrigerator r134a series
Hide thumbs
Also See for FRT21KG3C:
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
PRODUCT NO.
BASE MODEL NO.
FRT21KG3CQ0
FRT21KG3C
FRT21KG3CW0
FRT21KG3C
MARKET
North America
WIRING DIAGRAM - # 240379010
OWNER'S GUIDE - # 240400109
SERVICE DATA SHEET - # 240379010
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque
R134a
white
Publication No.
5995389177
030416
-EN/SERVICE /ECL
357
FACTORY
PARTS CATALO
VOLTS
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT21KG3C
©2003 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FRT21KG3C
Summary of Contents for Frigidaire FRT21KG3C
- Page 1 PRODUCT NO. BASE MODEL NO. FRT21KG3CQ0 FRT21KG3C FRT21KG3CW0 FRT21KG3C MARKET North America WIRING DIAGRAM - # 240379010 OWNER’S GUIDE - # 240400109 SERVICE DATA SHEET - # 240379010 ELECTROLUX HOME PRODUCTS, INC P.O. Box 212378, Augusta, GA 30917 SERIES COLOR...
- Page 2 Publication No. FRT21KG3C 5995389177 DOOR 04/03...
- Page 3 A = FRT21KG3C (FRT21KG3CW0) B = FRT21KG3C (FRT21KG3CQ0) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRT21KG3C DOOR PART NO DESCRIPTION 240514607 Gasket,seal ,white ,frzr door ,magnetic 240514608 Gasket,seal ,white ,refr door ,magnetic 240534901 Rack-door 240534701 Rack-door,4B 240337701...
- Page 4 Publication No. FRT21KG3C 5995389177 CABINET 04/03...
- Page 5 A = FRT21KG3C (FRT21KG3CW0) B = FRT21KG3C (FRT21KG3CQ0) POS. NO 10*# 13 # # = Fast-moving Parts * = Non-Illustrated Parts FRT21KG3C CABINET PART NO DESCRIPTION 240355402 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan...
- Page 6 Publication No. FRT21KG3C 5995389177 SHELVES 04/03...
- Page 7 A = FRT21KG3C (FRT21KG3CW0) B = FRT21KG3C (FRT21KG3CQ0) POS. NO 14 # 17*# 21 # 23 # # = Fast-moving Parts * = Non-Illustrated Parts FRT21KG3C SHELVES PART NO DESCRIPTION 215667501 Tray,ice cube ,plastic 240358003 Shelf,freezer ,full-width ,wire 5303299664 Spacer,shelf...
- Page 8 Publication No. FRT21KG3C 5995389177 SYSTEM 04/03...
- Page 9 A = FRT21KG3C (FRT21KG3CW0) B = FRT21KG3C (FRT21KG3CQ0) POS. NO 6* # 6* # 14 # 15 # 21 # 29 # 30 # 55 # 60 # 61 # # = Fast-moving Parts * = Non-Illustrated Parts FRT21KG3C SYSTEM...
-
Page 10: Wiring Schematic
Publication No. FRT21KG3C 5995389177 WIRING SCHEMATIC 04/03... -
Page 11: Wiring Diagram
FRT21KG3C Publication No. 5995389177 WIRING DIAGRAM # = Fast-moving Parts 04/03 * = Non-Illustrated Parts...
