COLLINGWOOD LEDGE
MODEL N0. 068-7643-8
Assembly Instructions
Toll-free: 1-888-670-6684
IMPORTANT: Please read this manual carefully before beginning assembly of
this product. Keep this manual for future reference.
Advertisement
Table of Contents
Related Manuals for Canvas COLLINGWOOD LEDGE 068-7643-8
Summary of Contents for Canvas COLLINGWOOD LEDGE 068-7643-8
- Page 1 COLLINGWOOD LEDGE MODEL N0. 068-7643-8 Assembly Instructions Toll-free: 1-888-670-6684 IMPORTANT: Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference.
- Page 2 Shelf Body - 1 Bracket Support - 1 Installation Screws 4 x 60 mm - 2 Drywall Anchors - 2 Set Screws 3 x 12 mm - 2 WARNING: It is strongly recommended that this shelf be installed in at least one stud to ensure maximum stability and load capacity.
- Page 3 Step 1 Pencil, Level and Bracket Support (2) Requires: Use a stud finder (not included) to find studs in desired mounting area. Place bracket (2) against the wall in the desired position. Use a level (not included) to ensure the bracket (2) is level, then mark holes with a pencil (not included).
- Page 4 WARNING: For proper installation of this shelf system, it is recommended that the screws be installed in studs. Failure to install the shelf in wood studs will greatly affect Shelf weight capacity: 17 lb (7.7 kg). weight loading stability and capacity. Please read and understand this entire manual before attempting to assemble, operate or install the product.
