This book is valuable. In addition to instructing you on how to install and maintain your appliance, it also
contains information that will enable you to obtain replacement parts or accessory items when needed. Keep
it with your other important papers.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
This wood burning fireplace complies with UL127
CAN/ULC-S610-M87 standard as a FACTORY
BUILT FIREPLACE.
This fireplace is approved for use as a wood burning fireplace or for use with a vented gas log approved to
ANSI Z21.60 or Z21.84 standards or for use with a vent-free gas log heater approved to ANSI Z21.11.2 standard .
FOR CANADA: The authority having jurisdiction
(such as the municipal building department, fire
department, etc.) should be contacted before
installation to determine the need to obtain a permit.
This installation manual will enable you to obtain a safe, efficient and dependable installation of your fireplace
system. Please read and understand these instructions before beginning your installation.
Do not alter or modify the fireplace or its components under any circumstances. Any modification or alteration of
the fireplace system, including but not limited to the fireplace, chimney components and accessories, may void the
warranty, listings and approvals of this system and could result in an unsafe and potentially dangerous installation.
IMPORTANT! TO ASSURE PROPER ALIGNMENT OF GLASS DOORS: INSTALL THIS FIREPLACE IN A SQUARE
AND PLUMB CONDITION, USING SHIMS AS NECESSARY AT SIDES AND/OR BOTTOM.
PFS
C
REPORT NO. F09-095
SAVE THIS BOOK
NOTE: DIAGRAMS AND ILLUSTRATIONS THROUGHOUT THE MANUAL ARE NOT TO SCALE.
Installation and Operation Instructions
Superior® Outdoor Wood Burning Fireplace
Models
WRE6036RS
WRE6036IS
®
WRE6036RH
US
WRE6036IH
Installateur : Laissez cette notice avec l'appareil.
Consommateur : Conservez cette notice pour consultation ultérieure.
Ce foyer au bois est conforme aux UL 127 CAN/ULC-
S610-M87 norme comme une USINE CONSTRUITE
CHEMINÉE.
POUR LE CANADA: L'autorité compétente (comme le
service municipal du bâtiment, les pompiers, etc.) doit
être contacté avant l'installation afin de déterminer la
nécessité d'obtenir un permis.
WRE6042RS
WRE6050RS
WRE6042IS
WRE6050IS
WRE6042RH
WRE6050RH
WRE6042IH
WRE6050IH
Advertisement
Table of Contents
Related Manuals for Superior Fireplaces WRE6036RS
Summary of Contents for Superior Fireplaces WRE6036RS
- Page 1 Installation and Operation Instructions Superior® Outdoor Wood Burning Fireplace Models P/N 127008-01 Rev. E 07/2017 WRE6036RS WRE6042RS WRE6050RS WRE6036IS WRE6042IS WRE6050IS Ce manuel est disponible en francais, simplement ® WRE6036RH WRE6042RH WRE6050RH en faire la demande. Numéro de la pièce 127008-02.
-
Page 2: Table Of Contents
Thank you for your purchase. We appreciate your TABLE OF CONTENTS business! Safety .....................2 Please carefully read and follow all instructions in this manual. Pay Specifications .................4 special attention to all warnings and safety information. Fireplace Installation ..............7 Following these safety, care, and operation instructions will help Venting Installation ................9 ensure many years of dependable and enjoyable service from your Firebrick Wall Installation..............16... - Page 3 SAFETY Continued Overfiring of a fireplace is a condition where excessive WARNING: BURNING IMPROPER FUEL (I.E. CHAR- temperatures are reached, beyond the design capabilities COAL) CAN RESULT IN CARBON MONOXIDE POISON- of the appliance. The damage that occurs from overfiring ING, WHICH MAY LEAD TO DEATH! is not covered under the manufacturer’s limited warranty.
-
Page 4: Specifications
(267 mm) (242 mm) (178 mm) " 36" (915 mm) " (115 mm) (89 mm) 11" 1" (26 mm) " (1159 mm) (280 mm) " (185 mm) " (388 mm) Figure 1 - 36" WRE6036RS, WRE6036IS, WRE6036RH and WRE6036IH SuperiorFireplaces.us.com 127008-01_E... - Page 5 SPECIFICATIONS Continued 42" MODEL " (775 mm) " (578 mm) " (400 mm) " (670 mm) 29" (737 mm) 23" " (585 mm) (553 mm) (Ref.) " (448 mm) " (32 mm) " (1051 mm) 42" HEARTH " (16 mm) "...
- Page 6 SPECIFICATIONS Continued 50" MODEL " (978 mm) 24" (610 mm) " " (489 mm) (874 mm) " " 23" (724 mm) (553 mm) (585 mm) (Ref.) " (448 mm) " " (32 mm) (1255 mm) 50" HEARTH " (112 mm) 67"...
-
Page 7: Fireplace Installation
FIREPLACE INSTALLATION SELECTING LOCATION 6. Using screws or nails, secure fireplace to framing through flanges located on sides of fireplace. To determine the safest and most efficient location for the fireplace, you must take into consideration the following guidelines: Note: For outdoor installations, fireplace enclosure must allow for adequate drainage and fresh air ventilation. - Page 8 FIREPLACE INSTALLATION Continued HEARTH EXTENSION MANTELS A hearth extension projecting a minimum of 20" in front of and a A mantel may be installed if desired (see Figure 7). Woodwork such as minimum of 12" beyond each side of fireplace opening is required wood trims, mantels or any other combustible material projecting from to protect combustible floor construction in front of fireplace.
-
Page 9: Venting Installation
VENTING INSTALLATION LINEAL GAIN OPTIONAL OUTSIDE AIR KIT (MODEL AK4/AK4F) PART NO. DESCRIPTION GAIN The installation of an outside air kit should be performed during Signature Fireplace " the rough framing of the fireplace due to the nature of it's location. 12-12DM Pipe Section "... - Page 10 VENTING INSTALLATION Continued USING ELBOW OFFSETS (30E-12DM) OFFSET RISE CHIMNEY LENGTH 12" 18" 24" 36" 48" 1. To achieve desired offset, you may install combinations of 12", " " ELBOW SET ONLY 18", 24", 36" and 48" length of double wall pipe (see offset chart "...
- Page 11 VENTING INSTALLATION Continued Return Return Elbow Return Elbow Elbow Offset Offset Elbow Elbow 6' (1.88 m) 6' (1.88 m) Ceiling Max. Max. Support Pipe Return Return 12S-12DM Elbow 6' (1.88 m) Elbow Max. 6' (1.88 m) Offset Offset Max. Elbow Elbow 6' (1.88 m) 6' (1.88 m)
- Page 12 VENTING INSTALLATION Continued FLASHING INSTALLATION (V6F-10DM OR V12F-10DM) 17" Determine the flashing to be used with the roof opening chart. Slide (432 mm) 30" (762 mm) flashing over pipe until base is flat against roof. Replace as many Min. 1" (26 mm) Min.
- Page 13 VENTING INSTALLATION Continued Terminations/Spark Arrestor 10 FOOT RULE The fireplace system must be terminated with the listed round top or All flue gas outlet chimney terminations must extend a minimum of chase terminations. In any case, refer to the installation instructions 3 feet in height above the highest point where it passes through the supplied with the termination.
- Page 14 VENTING INSTALLATION Continued Secure flashing through sides with 8-penny nails or sheet rock Termination screws. Place galvanized sleeve through hole in flashing and around last Sheet Metal Screw section of chimney (see Figure 23). 1" Noncombustible Place termination cap over opening and slip stainless steel inner Spacer pipe into stainless steel chimney section.
- Page 15 VENTING INSTALLATION Continued Attach noncombustible spacers at each corner and place flashing Note: Do Not Seal Termination Cap over chase (see Figure 27). Secure flashing through sides with Ventilation Openings 8-penny nails or sheet rock screws. Caulk Place termination cap over opening. Slip stainless steel inner pipe of termination into inner stainless steel chimney section Storm Collar 6"...
-
Page 16: Firebrick Wall Installation
FIREBRICK WALL INSTALLATION WARNING Slot Right Face LIFTING HAZARD SINGLE -PERSON LIFT COULD CAUSE INJURY. USE ASSISTANCE WHEN MOVING OR LIFTING. FIREBRICK WALL INSTALLATION IMPORTANT: Installation of brick should be done Hearth after the fireplace is placed in a permanent location. Figure 32 - Slots for Firebrick Walls 1. - Page 17 FIREBRICK WALL INSTALLATION Continued GROUTING INSTRUCTIONS INSTALLING SCREEN Material provided: 1. Slide round end of screen rod into rings at top of screen. Attach one push-on nut to end of rod before attaching last ring of screen. Bag of cement 2.
-
Page 18: Optional Gas Line Installation
OPTIONAL GAS LINE INSTALLATION Gas line hook up should be done by your supplier or a qualified Outside of service person. Fireplace Side Firebrick Note: Before you proceed, make sure your gas supply is turned off. Incoming Finished Side Use only a 1/2" black iron pipe and appropriate fittings. 1/2"... -
Page 19: Glass Door Installation
GLASS DOOR INSTALLATION DOOR FRAME MODELS INSTALLING GLASS DOORS Spring clips have been installed but some adjustments may be BDMO36E/G/C, BDMO42E/G/C AND BDMO50E/G/C needed. Install the doors using the following steps: Installation 1. With bifold doors completely folded, insert bottom pivot pin into 1. -
Page 20: Operation And Maintenance Guidelines
OPERATION AND MAINTENANCE GUIDELINES GLASS DOORS OUTSIDE AIR AND DAMPER HANDLE OPERATION Glass doors are optional with the fireplace. When fireplace is in operation, The damper handle, which opens and closes the damper blade, is doors must be fully opened or fully closed position only or a fire hazard located in the upper front face of the fireplace. -
Page 21: Technical Service
IMPORTANT NOTICES - CANADA TECHNICAL SERVICE You may have further questions about installation, operation, or IMPORTANT NOTICE troubleshooting. Please contact your IHP dealer for any questions A manufactured shroud which has been approved by a or concerns a. When contacting your dealer please have your model national testing agency for use with this fireplace may and serial numbers of your fireplace ready. -
Page 22: Parts
PARTS MODELS 36", 42", AND 50" Catalog numbers are included for convenience. MODEL CATALOG NO. WRE6036RS F0409 WRE6036IS F0410 WRE6036RH F0411 WRE6036IH F0412 WRE6042RS F0413 WRE6042IS F0414 WRE6042RH F0415 WRE6042IH F0416 WRE6050RS F0417 WRE6050IS F0418 WRE6050RH F0419 WRE6050IH F0420 16/17 SuperiorFireplaces.us.com... - Page 23 21 of this manual. Catalog numbers are included for convenience. WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved by IHP. Use of non-approved parts can result in poor performance and safety hazards. WRE6036RS (F0409) WRE6042RS (F0413) WRE6050RS (F0417)
- Page 24 PARTS MODELS 36", 42" AND 50" Picture may vary from actual MODEL CATALOG NO. WRE6036RS F0409 WRE6036IS F0410 WRE6036RH F0411 WRE6036IH F0412 WRE6042RS F0413 WRE6042IS F0414 WRE6042RH F0415 WRE6042IH F0416 WRE6050RS F0417 WRE6050IS F0418 WRE6050RH F0419 WRE6050IH F0420 Note: See pages 23 and 24 for part numbers.
- Page 25 PARTS This list contains replaceable parts used in your firebox. When ordering parts, follow the instructions listed under Replacement Parts on page 21 of this manual. WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved by IHP.
- Page 26 PARTS This list contains replaceable parts used in your firebox. When ordering parts, follow the instructions listed under Replacement Parts on page 21 of this manual. WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved by IHP.
-
Page 27: Accessories
ACCESSORIES BI-FOLD GLASS DOORS (For Use With Mosaic Brick Only) CAT NO. MODEL DESCRIPTION F1011 BDMO36E GLASS DOOR, 36" EBONY F1012 BDMO36G GLASS DOOR, 36" PEWTER F1013 BDMO36C GLASS DOOR, 36" OILED BRONZE F1014 BDMO42E GLASS DOOR, 42" EBONY F1015 BDMO42G GLASS DOOR, 42"... - Page 28 ACCESSORIES Continued ROOF FLASHING F0942 V6F-10DM Roof Flashing 0 to 6/12 Pitch F0943 V12F-10DM Roof Flashing 6/12 to 12/12 Pitch SQUARE CHASE-TOP TERMINATION F0948 STL-12D Square Top Termination with Slip Section Square TopTermination with Slip Section (Pre-Painted F0949 STL-12DMP Black) ROUND TOP TERMINATIONS F0947 RLT-12D...
-
Page 29: Draft Smoke Guidelines
APPENDIX A Draft Requirements take into account all variables within the installation and install the appliance in such a manner that satisfies the draft requirements of Your wood-burning appliance is dependent upon a properly func- the appliance. See Chimney Guidelines to assist you in selecting the tioning chimney for optimum performance. - Page 30 APPENDIX A Continued Smoking – Causes And Troubleshooting Location Recommended To reduce the likelihood of smoking when opening the door, open Marginal Location the combustion air control or damper before opening the door. Wind Direction Your appliance has been designed and tested to provide smoke free Tree operation.
-
Page 31: Warranty
Innovative Hearth Products Superior Brand Wood-Burning Fireplace ® 20 Year Limited Warranty THE WARRANTY Innovative Hearth Products ("IHP") 20 Year Limited Warranty warrants your Superior Brand wood burning fi replace ("Product") to be free from defects in materials and ® workmanship at the time of manufacture. - Page 32 SuperiorFireplaces.us.com Record the following important information about your fireplace: Fireplace model number Fireplace serial number Date fireplace was Installed Dealer name P127008-01 Innovative Hearth Products reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products. Consult your local distributor for fireplace code information.
