Summary of Contents for Innes SAP10e

  • Page 1 User manual regular-1.10.10 001A...
  • Page 2 Legal no ce regular-1.10.10 (001A_en) © 2020 Qeedji Rights and Responsibili es All rights reserved. No part of this manual may be reproduced in any form or by any means whatsoever. or by any means whatsoever without the wri en permission of the publisher.

  • Page 3: Table Of Contents

    Table of contents Part I : Descrip on and installa on Introduc on Ge ng started with the device 1.1.1 Device dimensions 1.1.2 Labelling 1.1.3 Installa on 1.1.4 Uninstalla on 1.1.5 Applica ons Part II : Applica ve user interface Applica ve user interface Part III : Administra on console user interface Administra on console user interface...

  • Page 4: Part I : Descrip On And Installa On

    Descrip on and installa on Part I...

  • Page 5: Introduc On

    This manual explains how to install and configure your SAP10e device. The SAP10e device allows up to 10 SLATE106 e-papers to be connected to a TCP/IP network. In its standard version, the access point can be used with the MS-PowerPoint so ware supplemented by the Add-in.

  • Page 6: Ge Ng Started With The Device

    Ge ng started with the device 1.1.1 Front and side face The SAP10e device has: 1 male Ethernet connector 1 power red LED 1 status green LED...

  • Page 7: Device Dimensions

    Device dimensions 1.1.2 37,00 mm 20,48 mm 15,75 mm (1,45 ") (0,62 ") (0,80 ")

  • Page 8: Labelling

    ☛ The serial number of the device can be requested in case of technical support. PSN label The model of the device, the power supply characteris cs, the serial number (PSN) and the MAC address are wri en on labels stuck on the case. Model: SAP10e PSN01390-00001 CD6 MAC: 00-1C-E6-02-4C-EC...

  • Page 9: Installa On

    Consequently, the Ethernet wall plug whose plastron is angled is not supported. ☛ Thanks to the lock pin of its Ethernet connector, the SAP10e device can be installed on ver cal surfaces, like wall as well as horizontal surfaces, like ceilings.

  • Page 10: Uninstalla On

    Uninstalla on 1.1.5 With a screw driver, hold down the pin of the Ethernet connector of the SAP10e device at the same me you are releasing with the hand the SAP10e device from the Ethernet wall plug.

  • Page 11: Applica Ons

    3 very short and consecu ve The so ware resource of the SAP10e device set at factory are not valid. It should never occur. For further Recovery green flashs (250 ms) with a 5 informa on, contact support@qeedji.tech.

  • Page 12: Part Ii : Applica Ve User Interface

    Applica ve user interface Part II...

  • Page 13: Applica Ve User Interface

    Refresh ☛ To be synchronized, the SLATEs needs to be paired first with the right index. To check simply whether some SLATEs are paired to the SAP10e, refer to the chapter § Informa on > WPAN peripherals. Then, a hub.ppk content must be present in the respec ve WebDAV directories.

  • Page 14: Part Iii : Administra On Console User Interface

    Administra on console user interface Part III...

  • Page 15: Administra On Console User Interface

    Administra on console user interface The SAP10e device Web user interface that can be accessed with a Web browser. The supported browsers are: Google Chrome Mozilla Firefox MS-Edge MS-Edge (Chromium) It is accessible from the URL: http://<device_IP_addr>/ By default, the login creden als for the device Web user interface are:...

  • Page 16: Configura On > Administrator

    ☛ The same login creden als are used to access to the WebDAV server. It is recommended that you enter one unique value for each device. In case several SAP10e devices are located in different buildings or geographical loca ons, we Hostname recommend that you enter hostname values with informa on about the building and the loca on (e.g.

  • Page 17: Configura On > Lan

    Configura on > LAN 3.1.2 In the pane, select the LAN menu to set up the network configura on of the interface of your device. Configuration ☛ By default, the device is configured with DHCP ac vated. In case the DHCP server is not available, a er the DHCP meout, the device ends up using the sta c IP address whose default value is 192.168.0.2 when it has not been changed yet by the end user.

  • Page 18: Configura On > Servers

    NTP time server ☛ The NTP me server is the only way for the SAP10e device to be on me. Once the device is on me, the date and me can be transmi ed to the SLATEs. When the NTP...

  • Page 19: Configura On > Slates Pairing

    The SAP10e device is designed to work with at least one and up to ten SLATEs. In case you are using a SAP10e device already installed, it is recommended to double check its heartbeat configura on before star ng any configura on. For further ◬...
  • Page 20 SLATEs detected If the SLATE does not appear in the list a er 15 minutes, either they are too far from the SAP10e device or the wake-up policy configura on does not allow to wake up ◬ now. For further informa on, refer to the...
  • Page 21 file download success rate meaning that the APPLI.CFG configura on or the content will be not updated within the 15 minutes interval. The SLATE can not be used in this condi on. It is required to install the SLATE at another loca on or install a new SAP10e device closer to this SLATE.
  • Page 22 : allows to unpair a SLATE from this SAP10e device,  Unpair : allows to pair manually a SLATE to this SAP10e device by entering its PSN and an op onal PIN code,  Pair ☛ If required, it is possible to change the hostname of each slate, set the same PIN code for all SLATEs and ac vate temporarily the TestCard by changing some user preferences.
  • Page 23   d) Finalize the pairing procedure with bu on: Deactivate To complete the SAP10e device configura on, press on the bu on. Deactivate ☛ When the pairing is finished, you can save the file preciously to be able to restore the device configura on a erwards. For further informa on, refer to the prefs.json...
  • Page 24 Time to obtain a connec on quality The connec on quality status is showing the file download error rate averaged on the ten last files downloading between the SAP10e device and the SLATEs. The files can be as well: an APPLI.CFG configura on file, a .ppk file,...

  • Page 25: Maintenance > Firmware

    Maintenance > Firmware 3.1.5 From the pane, select the Firmware menu to view the version of the firmware installed on your device. Maintenance ☛ Correc ve and evolu ve maintenance so ware versions are regularly made available in the support tab of the official website ps://www.qeedji.tech.

  • Page 26: Maintenance > Preferences

    If true, when the configura on appli.pictureframe.slate.*.testcard.enabled (default) file is taken into account, the SLATE removes the test content and displays the content communicated by the SAP10e. false If false, allows to inac vate the vibra on sensor on the SLATE. appli.pictureframe.slate.*.vibration_sensor.enabled...
  • Page 27 Timezone Con nent Country/Town pair values supported for the preference system.datetime.timezone Africa Africa/Brazzaville, Africa/Cairo, Africa/Casablanca, Africa/Harare, Africa/Lagos, Africa/Nairobi, Africa/Onitsha, Africa/Windhoek America/Anchorage, America/Argen na/Buenos_Aires, America/Barbados, America/Bogota, America/Boston, America/Caracas, America/Chicago, America/Chihuahua, America/Costa_Rica, America/Dallas, America/Denver, America/Godthab, America/Halifax, America/Houston, America/Los_Angeles, America America/Manaus, America/Mexico_City, America/Montevideo, America/New_York, America/Phoenix, America/Recife, America/Regina, America/Rio_de_Janeiro, America/San_Francisco, America/San ago, America/Sao_Paulo, America/St_Johns, America/Tijuana, America/Washington,_D.C.

  • Page 28: Maintenance > Tools

    ¹ The flash memory storage is used to store all the directories and files hosted at the root of the WebDAV directory, and the user preferences as well. In case flash forma ng, all the file are deleted and consequently the SAP10e device returns to the default factory se ngs.

  • Page 29: Maintenance > Files

    01/01/2020 00:00 ☛ When the server NTP is ac vated and the device is properly configured, the date and me for the SAP10e device is updated automa cally by NTP at the device boot-up. Then it is progressing every seconds.
  • Page 30 Install a new pictureframe release version for SLATEs with your SAP10e device To install a new pictureframe release version for the SLATEs paired to your SAP10e device, download the wished pictureframe so ware version from the Qeedji Web site. In the pane, select the menu Files to see the files hosted at the root WebDAV directory.

  • Page 31: Informa On > Device

    Informa on > Device 3.1.9 In the pane, select the menu Device to view system informa on about the device. Information : model of the device, Model Qeedji : name of the device on the network, Hostname : Universal Unique IDen fier, UUID : Product Serial Number.

  • Page 32: Informa On > Network

    Informa on > Network 3.1.10 In the pane, select the Network menu to view a summary of the device's network configura on. Information...

  • Page 33: Informa On > Wpan Peripherals

    Informa on > WPAN peripherals 3.1.11 In the pane, select the menu WPAN Peripherals to see WPAN peripherals paired to your SAP10e device. Information The panel allows to display system informa on like: : SLATE index column : Qeedji or EnOcean,...

  • Page 34: Qether

    MAC address of the device with the format <SAP10e_device_MAC_address> 00:1C:E6:AB:CD:EF The MAC address of the device is wri en on the label stuck at the back of the SAP10e device with the format ◬ 00-1C-E6-AB-CD-EF Discover command example This command allows to find out the SAP10e devices present on the local network:...

  • Page 35: Part Iv : Technical Informa On

    Technical informa on Part IV...

  • Page 36: Technical Specifica Ons

    Technical specifica ons Model Manufacturer SAP10e Qeedji Power supply Informa on PoE IEEE802.3af POE power supply input: ES1 / PS2 (48V DC – 20mA max) Processors Nordic Semiconductor nRF52 Security processor ARM CryptoCell 310 Storage Flash Memory for file system...

  • Page 37: Conformi Es

    Conformi es EUROPE In conformity with the following European direc ves: LVD 2014/35/EU EMC 2014/30/EU RED 2014/53/EU...

  • Page 38: Part V : Contacts

    Contacts Part V...

  • Page 39: Contacts

    Refer to the Web site for FAQ, applica on notes, and so ware downloads: h ps://www.qeedji.tech/ Qeedji Qeedji FRANCE INNES SA 5A rue Pierre Joseph Colin 35700 RENNES Tel: +33 (0)2 23 20 01 62 Fax: +33 (0)2 23 20 22 59...

  • Page 40: Part Vi : Appendix

    Appendix Part VI...

  • Page 41: Appendix: Qeedji Powerpoint Publisher For Slate

    Cardiologist ☛ In the example, the SLATEs are spread on two floors. In case your MS-PowerPoint presenta on needs to deal with two SAP10e devices or more, do prefer use a MS- PowerPoint presenta on with sec ons. In case your MS-PowerPoint presenta on deals with only one SAP10e device, do prefer use a MS-PowerPoint presenta on without sec on.
  • Page 42 255-255-255 ☛ Some sec ons can be used especially to publish on several SAP10e devices, with one sec on per SAP10e device or to shorten the publica on me for a given SAP10e device by avoiding to publish unuseful slides. With a right click on the slide thumbnail list on the le , it is possible to remove one or all the sec ons. To add a sec on a er a slide, select a slide in the slide thumbnail list, right clic, and choose .
  • Page 43 Qeedji PowerPoint Publisher for SLATE: installa on PowerPoint Add In needs to be installed once: Qeedji PowerPoint Publisher for SLATE download the appropriate installer (.msi file): Qeedji PowerPoint Publisher for SLATE (nt_ia64) for your MS-Office (nt_ia64), Qeedji PowerPoint Publisher for SLATE (nt_ia32) for your MS-Office (nt_ia32).
  • Page 44 Select then the only SAP10e devices on which you want to publish, by double clicking on them. ☛ The SAP10e devices sor ng order in the list is decisive because it is taken into account during the publica on. The slides of the first sec on, or the first 10 slides, are always affected to the SAP10e device located at the top of the list.
  • Page 46 The Publishing status report is showing whether the publishing on each SAP10e devices has succeeded or not: : the publica on has succeeded Publishing succeeded : the publishing has failed. In this case, check the network connec on between your computer and the SAP10e. Publishing failure (Error: 503) Publishing status report example: 1/2 - Publishing on device: *floor-1* (192.168.1.121)

  • Page 47: Appendix: Web Services

    "pictureSyncState" = "synchronized" | "unsynchronized" | "undefined". Examples by using Curl tool 192.168.1.50 is an IP address example of a SAP10e device, and , its login creden als to access to the Web server of the SAP10e: admin admin curl command example to get the device firmware version:...
