Summary of Contents for Autool TW 500
- Page 1 AUTOOL TW 500 Tire Pressure Monitoring System User Manual www.autooltech.com...
- Page 3 . With regard to the other trademark, service logo, domain name, icon and company name mentioned in this manual, they shall all belong to AUTOOL and its other affiliated company, in other countries without the registration yet of these trademark, service logo, domain name, icon and company name of AUTOOL, here we announce they are owned by AUTOOL.
- Page 4 you guys may send us feedback during the course of you use it. Your suggestion and support are the driving force of our progress! "Happy to go out, peacefully come back" is our hope, and finally we sincerely wish you family all happy, everything goes well.
-
Page 5: Product Profile
pressure, high pressure, air leakage, high temperature and other abnormal situation, to remind the driver who need to take corresponding effective measures to play a role in safety assistance to achieve car travel more Safe, reliable, comfortable, and economical. IV.Product profile： The TPMS/HUD intelligent integrated machine extends the concept of combining the HUD car head-up display function with the two functions of the car slope meter, greatly improving the safety escort level of the product... -
Page 6: Product Functions
Start with the car, stop automatic sleep function. Cool mini body design. VI.Product functions： Tire pressure display. Tire temperature display. Speed display. Clock display. Altitude display. In-vehicle temperature display. VII.Alarm： Tire leak alarm. ... - Page 7 1, back key 2, M key 3. Forward key 4. Display 5. Solar charging board 6. USB charging port IX.Introduction of TPMS fetal pressure monitoring and display interface Take the mainframe out and start the TPMS tire pressure monitoring interface (as shown in the figure below, taking the English unit as an example), (Note: the product speed, tire pressure display, tire temperature is synchronous display) A.
- Page 8 B. When the sun light reaches the charging condition, the “ ” icon will be lit on the display to indicate that the solar panel has entered the working state. At this time, the mainframe battery icon scroll bar is blinking, indicating that the Perform charging mode.
- Page 9 Tire pressure mode metric (KM/H) unit interface display X.Introduction of HUD display interface 1. Take the mainframe out and turn it on. Press and hold the “forward key” for 5 seconds to switch to the HUD mode interface (as shown in the figure below, take the English unit as an example) and press the “forward key”...
- Page 10 F. This “ ” speed display icon shows the speed of the car when the car is driving. I. The current altitude display area. J. This " " picture shows the altitude icon. When it is in HUD mode, the icon lights up and the real-time altitude is displayed.
- Page 11 2. External sensor installation(as shown in the following figure)
- Page 12 3.Internal sensor installation (as shown in the following figure) * Please repeat the above steps to complete the installation of the...
- Page 13 III. The working principle of tire pressure monitoring system The Tire Pressure Monitoring System (TPMS) is designed to monitor the internal pressure and whole sensor step by step. XII. Receive mainframe on/off and function introduction of keys 1.On / off key * In the case of the shutdown state, you can choose to press the "back key"...
- Page 14 2.M key *mainframe interface In tire pressure mode, long press "M key" to enter "menu and settings". * Also in the settings is the "Select and Confirm". 3. Forward key * Long press 5 seconds "forward key" to switch between HUD mode and TPMS tire pressure monitoring mode * In the settings, think of "increasing"...
- Page 15 * Press the “M” key once again, and the display interface 4 is flashing.(as shown in the following figure) * Then press "back key" and "forward key" simultaneously for 5 seconds to enter the tire matching interface.(as shown in the following figure) * Then twist the tire valve cap that is installed with the sensor, keep the air pressure between 0.7-2.5Bar, and inflate or deflate the tire.
- Page 16 XIV. Introduction to the function of mainframe (Note: Only press the “M” button in the tire pressure mode to enter the setting interface.) 1.Clock setting *Mainframe interface In the tire pressure mode, long press the "M" key to enter the setting mode, press the left key twice to enter the interface (as shown in the following figure).
- Page 17 hours (480 minutes) faster than Greenwich Mean Time (GMT), and should be set to 480. US Eastern Time is West 5th District, 5 hours slower than Greenwich Mean Time (GMT), (300 minutes), should be set to -300. 2.Unit switching setting *The mainframe interface in the tire pressure mode, long press the "M"...
- Page 18 low pressure to "1.8 Bar", the normal tire normal pressure is "2.0-2.8 Bar" and the low air pressure cannot be lower than "1.8 Bar". 4. High air pressure setting of the tire Mainframe interface In the tire pressure mode, long press the "M" key, press the "forward key"...
- Page 19 6. High voltage alarm When the receiving mainframe detects that a certain tire pressure value has changed and the tire pressure value exceeds the set "3.00Bar" air pressure value, the mainframe alarm icon " " will be illuminated, The tire data value does not flash at the same time, and the alarm of “di, di, di...”...
- Page 20 following figure) 7. Low voltage alarm and fast air leakage alarm When the receiving mainframe detects that a certain tire pressure value has changed, but does not lower the set air pressure value, the receiving mainframe alarm icon " " will light up, and the tire data value flashes at the same time.
- Page 21 alarm icon " " is illuminated, and the tire pressure display data value position and temperature position are no data, and Issue an alert message for "di, di, di...". (as shown in the following figure) 10.Alignment settings for tyres 1. If the user needs to adjust the tires to each other, no need to re-assemble the sensor, just receive the mainframe for the tire adjustment operation;...
-
Page 22: Product List
and will issue a "di, di, di..." alarm warning A hint indicates that the sensor is low on battery. (as shown in the following figure) 12. Restore factory settings In the tire pressure mode, press the “M” key to enter the air pressure setting interface, and then press the “forward key”... -
Page 23: Important Statement
UBS cable User manual/Waranty card Certificate Theftproof nut Wrench XVI. Important statement 1. This product is the car tire pressure, temperature monitoring of the electronic device, in the above conditions can remind the driver to take timely measures to eliminate hidden dangers, but can not ignore the tire itself should be good at any time requirements. -
Page 24: Warranty Regulations
When TPMS give out alarm, driver should immediately slow down or stop the car for full check untill you make sure all tires are ok before you come back to the your drive. 4. Not proper installation will do harm to TPMS operation, even worse will bring damage to this product.So it is suggested the installation should be handled by professional skiller according to manual. - Page 25 During the warranty period, our dealer or customer service center is responsible for product repairing or product replacement as long as it is in accordance with the terms of our company. (unless other rules by law) Free changing of product materials, design and tenical defects. Product warranty must meet the following content to get our warranty service: 1.
- Page 26 If you have any questions, please contact the dealer or the Autool service center. The company have the final explanation right of product and shall not bear...
