Summary of Contents for Erskine Attachments VP48SM
- Page 1 Vibratory Packer Skid Steer Loaders Operator’s Manual Maintenance Parts Information Read this Manual Before Use...
-
Page 2: Table Of Contents
Serial Number………….._____________ YOUR ATTACHMENT DEALER ADDRESS: PHONE: CONTACT: NOTE: Erskine Attachments LLC reserves the right to make improvements in design or changes in specifications at any time without notice and without incurring any obligations to install them on units previously sold. -
Page 3: Safety
Indicates potentially Erskine Attachments LLC cannot anticipate every hazardous situation which, if not avoided, possible circumstance that might involve potential will result in death or serious injury. hazard. The safety messages found in this manual ... - Page 4 Escaping fluid under pressure can penetrate the skin causing serious Do not modify equipment or add attachments that injury. are not approved by Erskine Attachments LLC. Avoid the hazard by relieving the Use adequate safety warning lights and devices as pressure...
-
Page 5: Serial Number/Decal Location
SERIAL NUMBER AND SAFETY DECAL LOCATIONS Serial Number Location: It is important to refer to the serial number of the attachment when making repairs or ordering parts. Early or later models (identification made by serial number) may use different parts, or it may be necessary to use different procedures in doing a specific operation. - Page 6 SERIAL NUMBER AND SAFETY DECAL LOCATIONS________ Safety Decals Locations: The locations of the safety decals are shown. If these decals are missing, damaged, or painted over they must be replaced. Call Erskine Attachments LLC (218-435-4045) for replacement decals. Part number: 314526 Part number: 313594...
-
Page 7: User's Mounting Instructions
USER’S MOUNTING INSTRUCTIONS After the initial set-up assembly is completed use the following procedure to mount the attachment to the loader. Levers must be fully down and locked. Failure to secure wedges or pins can allow the attachment to come off and cause injury or death. 1. - Page 8 USER’S MOUNTING INSTRUCTIONS 7. Connect the hydraulic quick couplers from the attachment to the loader auxiliary couplers and case drain. IMPORTANT: Wipe the ends of the hydraulic quick couplers (both lead and loader) with a rag remove possible contamination. Contamination can cause hydraulic components to fail and is not covered under warranty.
-
Page 9: Operating Instructions
OPERATING INSTRUCTIONS 1. With the operator in the seat of the loader, the seatbelt fastened, and the seat bar lowered (if so equipped), start the engine. 2. With the loader arms fully lowered, position the attachment flat on the ground. 3. -
Page 10: Routine Maintenance
ROUTINE MAINTENANCE Lower the attachment to rest on the ground, shut down the engine, relieve the hydraulic pressure to the attachment, set the park brake, and wait for all motion to stop before leaving the operator’s seat to perform service of any kind. It is the operator’s responsibility to make daily inspections of the loader and attachment for damage, loose bolts, fluid leaks, or anything else that could cause a potential service or safety problem. - Page 11 ROUTINE MAINTENANCE Grease the center oscillation pivot [C] every 40 hours of operation. NOTE: The attachment must be disconnected from the loader in order to access this grease zerk. Visually inspect the eight isolation mounts (four on each end) for cuts or tears weekly. IMPORTANT: If a rubber isolation mount has a cut or tear, it must be replaced.
- Page 12 ROUTINE MAINTENANCE Visually check the drive coupler rubber member for wear every 80 hours of operation. 1. Remove the two bolts from the coupler shield. 2. Visually inspect. 3. Grab the coupler and check by hand to see if it feels tight or loose.
-
Page 13: Bolt Torque Information
BOLT TORQUE INFORMATION... -
Page 14: Parts Information
PARTS INFORMATION ITEM PART NO. DESCRIPTION STOCK NO. 313501 FRAME 72 W/A 313504 FRAME 48 W/A 313508 DRUM 72 SMOOTH W/A 313505 DRUM 48 SMOOTH W/A 314538 DRUM 72 PADDED W/A 314537 DRUM 48 PADDED W/A 313506 MOUNT W/A 313507 PIVOT W/A 314518 MOTOR MOUNT W/A... - Page 15 PARTS INFORMATION...
- Page 16 PARTS INFORMATION ITEM PART NO. DESCRIPTION STOCK NO. 313510 SHAFT 72 W/A 313517 SHAFT 48 W/A 314510 PLATE ISOLATION MOUNT W/A 313539 PLATE ISOLATION MOUNT PAINTED 314521 BEARING HOUSING MACHINED 313511 BRG DRUM 313580 BRG TAPER ADAPTER 313540 TUBE BRG SPACER 313551 TUBE BRG SPACER MOTOR SIDE 314507...
- Page 17 PARTS INFORMATION...
- Page 18 VIBRATORY ROLLER PARTS INFORMATION HYDRAULIC ASSEMBLY ITEM PART NO. DESCRIPTION STOCK NO. 33:1 313595 HOSE 5/8 X 58 12FJX-10FJX-90 LEAD 33:2 313596 HOSE 1/2 X 17 10MB-10FJX MOTOR TO VALVE 33:3 313597 HOSE 1/2 X 22 10MB-10FJX MOTOR TO VALVE 33:4 330894 HOSE 1/2 X 80 6FJX-8FJX...
- Page 19 PARTS INFORMATION...
-
Page 20: General Specifications
GENERAL SPECIFICATIONS Model VP48SM VP48PD Dynamic Force 4050 lbs. 4000 lbs. .08” .07” Amplitude Compacting Energy 100 lbs./in 350 lbs./in Vibrations per Minute 2000* vpm 2000* vpm Hydraulic Flow Range 11-22* gpm 11-22* gpm Operating Weight 1,390 lbs. 1,480 lbs. -
Page 21: Notes
NOTES ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________... - Page 22 NOTES ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________...
-
Page 23: Warranty
Erskine Attachments LLC to improve its products whenever it is possible and practical to do so. Erskine Attachments LLC reserves the right to make changes and or add improvements at any time without incurring any obligation to make such changes or add such improvements to products previously sold. - Page 24 P/N 313599 Date Printed: 1/11/2019 Printed in U.S.A. Erskine Attachments LLC...
