- Page 1 Mini Pick-Up Broom Mini Skid Steer Loaders Mini Track Loaders Operator’s Manual Maintenance Parts Information Read this Manual Before Use...
-
Page 2: Table Of Contents
Serial Number………….._____________ YOUR ATTACHMENT DEALER ADDRESS: PHONE: CONTACT: NOTE: Erskine Attachments LLC reserves the right to make improvements in design or changes in specifications at any time without notice and without incurring any obligations to install them on units previously sold. -
Page 3: Safety
Indicates potentially Erskine Attachments LLC cannot anticipate every hazardous situation which, if not avoided, possible circumstance that might involve potential will result in death or serious injury. hazard. The safety messages found in this manual ... - Page 4 Do not modify equipment or add attachments that hydraulic lines. are not approved by Erskine Attachments LLC. Use a piece of paper or cardboard, NOT BODY Use adequate safety warning lights and devices as PARTS, to check for suspected leaks.
-
Page 5: Serial Number/Decal Location
SERIAL NUMBER AND SAFETY DECAL LOCATIONS Serial Number Location: It is important to refer to the serial number of the attachment when making repairs or ordering parts. Early or later models (identification made by serial number) may use different parts, or it may be necessary to use different procedures in doing a specific operation. - Page 6 Safety Decals Locations: Location: Centered on top of hood The locations of the safety decals are shown. If these decals are missing, damaged, or painted over Quantity: 1 they must be replaced. Call Erskine Attachments LLC (218-435-4045) for replacement decals.
-
Page 7: User's Mounting Instructions
USER’S MOUNTING INSTRUCTIONS After the initial set-up assembly is completed, use the following procedure to mount the attachment to the loader. Coupler wedges or pins must extend through holes in attachment. Levers must be fully down and locked. Failure to secure wedges or pins can allow the attachment to come off and cause injury or death. - Page 8 USER’S MOUNTING INSTRUCTIONS Connecting Hydraulics: 1. Connect the hydraulic quick couplers from the attachment to the loader. IMPORTANT: Wipe the ends of the hydraulic quick couplers (both lead and loader) with a rag to remove possible contamination. Contamination can cause hydraulic components to fail and is not covered under warranty.
-
Page 9: Operating Instructions
OPERATING INSTRUCTIONS 1. With the operator in the seat of the loader, the seatbelt fastened, and the seat bar lowered (if so equipped), start the engine. 2. Position the attachment so that the bucket is slightly off of the ground, and the broom assembly wheel is resting on the ground. - Page 10 3 feet off of the ground. NOTE: In some cases, it may be necessary to run the mini pick-up broom while dumping to remove the debris from inside and around the bristles. 4. Lower the attachment and resume sweeping...
-
Page 11: Routine Maintenance
ROUTINE MAINTENANCE Lower the attachment to rest flat on the ground, disengage the hydraulic drive, shut down the engine, set the park brake, and wait for all motion to stop before leaving the operator’s seat to perform service of any kind. It is the operator’s responsibility to make daily inspections of the loader and attachment for damage, loose bolts, fluid leaks, or anything else that could cause a potential service or safety problem. - Page 12 ROUTINE MAINTENANCE Replacing Brush Sections 1. Remove the side rubber shields from both sides of the attachment. 2. Remove the two endplate mounting bolts and nuts on each side. Retain for later reassembly. NOTE: The motor hex drive block will be removed with the endplate.
- Page 13 ROUTINE MAINTENANCE 5. Remove the bearing retaining bolt and washer. 6. Loosen the set screws on the bearing assembly and slide the bearing and endplate off of the arbor. 7. Remove the three bolts holding the brush retainer to the arbor, and remove the brush retainer. 8.
- Page 14 ROUTINE MAINTENANCE 14. Continue this pattern until all “wavy” brush sections are installed. NOTE: Install 28 “wavy” brush sections on a 60” arbor, 36 “wavy” brush sections on a 72” arbor, or 42 “wavy” brush sections on an 84” arbor. 15.
-
Page 15: Bolt Torque Information
BOLT TORQUE INFORMATION... -
Page 16: Parts Information
PARTS INFORMATION ITEM PART NO. DESCRIPTION STOCK NO. 318403 BRACKET PIVOT RH 318404 BRACKET PIVOT LH 318427 SHEILD RUBBER SIDE 400331 BODY PICK UP BROOM 48 W/A 400343 SHIELD RUBBER FRONT 48 318559 WHEEL CASTER ASSM 10.13 TALL X 8X2 REPLACED 318499 318499 CASTER ASSEMBLY 8 X 2 REPLACED BY 318559... - Page 17 PARTS INFORMATION...
- Page 18 PARTS INFORMATION ITEM PART NO. DESCRIPTION STOCK NO. DRIVE BLOCK HEX 1" BORE-SNAP RING 318459 INCLUDED 203741 FLANGET 3-BOLT 1-1/8" 202159 BRG INSERT 1-1/4" SM 400307 ARBOR 45 W/A 318411 WAFER CONVOLUTED POLY 24” OD OPT. POLY WAFER PKG 318411 WAFER CONVOLUTED POLY 24”...
- Page 19 PARTS INFORMATION ITEM PART NO. DESCRIPTION STOCK NO. 400311 MOTOR 41.3 400381 HOSE 1/2 X 100 10MB-8FJX...
-
Page 20: General Specifications
GENERAL SPECIFICATIONS Model Mini Pick-Up Broom 45” Working Width 56.9” Overall Width 25” Overall Height 55.6” Overall Length (w/out mount) 24” Bristle Wafer Diameter Bristle Wafer Quantity 2 Straight, 21 Convoluted 1/2" x 4” bolt-on Cutting Edge Drive System Direct drive hydraulic motor... -
Page 21: Notes
NOTES ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________... - Page 22 NOTES ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________...
-
Page 23: Warranty
Erskine Attachments LLC to improve its products whenever it is possible and practical to do so. Erskine Attachments LLC reserves the right to make changes and or add improvements at any time without incurring any obligation to make such changes or add such improvements to products previously sold. - Page 24 P/N 300437 Date Printed: 6/5/2018 Printed in U.S.A. Erskine Attachments LLC...
