- Page 1 FRS28ZRGD0 FRS28ZRG FRS28ZRGD1 FRS28ZRG FRS28ZRGW0 FRS28ZRG FRS28ZRGW1 FRS28ZRG 101 Masters Blvd. Anderson, SC 29624 R134a almond R134a almond R134a white R134a white Publication No. 5995310504 980715 -EN/SERVICE /JLT ©1998 White Consolidated Industries, Inc. All rights reserved...
-
Page 2: Freezer Door
Publication No. FRS28ZRGD0, FRS28ZRGD1, FRS28ZRGW0, FRS28ZRGW1 5995310504 FREEZER DOOR 07/98... - Page 3 FRS28ZRGD0, FRS28ZRGD1, FRS28ZRGW0, FRS28ZRGW1 A = FRS28ZRG (FRS28ZRGD0) B = FRS28ZRG (FRS28ZRGD1) C = FRS28ZRG (FRS28ZRGW0) D = FRS28ZRG (FRS28ZRGW1) 37A* 37A* # = Fast-moving Parts * = Non-Illustrated Parts FREEZER DOOR 215734305 A B - - Gasket-frzr door,almond ,magnetic...
-
Page 4: Refrigerator Door
Publication No. FRS28ZRGD0, FRS28ZRGD1, FRS28ZRGW0, FRS28ZRGW1 5995310504 REFRIGERATOR DOOR 07/98... - Page 5 FRS28ZRGD0, FRS28ZRGD1, FRS28ZRGW0, FRS28ZRGW1 A = FRS28ZRG (FRS28ZRGD0) B = FRS28ZRG (FRS28ZRGD1) C = FRS28ZRG (FRS28ZRGW0) D = FRS28ZRG (FRS28ZRGW1) 37A* 37A* # = Fast-moving Parts * = Non-Illustrated Parts REFRIGERATOR DOOR 215734306 A B - - Gasket-refr door,almond ,magnetic...
- Page 6 Publication No. FRS28ZRGD0, FRS28ZRGD1, FRS28ZRGW0, FRS28ZRGW1 5995310504 CABINET 07/98...
- Page 7 FRS28ZRGD0, FRS28ZRGD1, FRS28ZRGW0, FRS28ZRGW1 A = FRS28ZRG (FRS28ZRGD0) B = FRS28ZRG (FRS28ZRGD1) C = FRS28ZRG (FRS28ZRGW0) D = FRS28ZRG (FRS28ZRGW1) 5303209814 5303208309 5303289043 5303289044 5303289062 5303321082 5303321081 5303318774 5303318773 5303001609 5308009759 5308017044 5303288974 5308002748 5303001216 5303274237 5308016566 5303322647 5303001479 5303288973...
- Page 8 Publication No. FRS28ZRGD0, FRS28ZRGD1, FRS28ZRGW0, FRS28ZRGW1 5995310504 CONTROLS 07/98...
- Page 9 FRS28ZRGD0, FRS28ZRGD1, FRS28ZRGW0, FRS28ZRGW1 A = FRS28ZRG (FRS28ZRGD0) B = FRS28ZRG (FRS28ZRGD1) C = FRS28ZRG (FRS28ZRGW0) D = FRS28ZRG (FRS28ZRGW1) 42 * 52A* 100A 100B # = Fast-moving Parts * = Non-Illustrated Parts CONTROLS 5303298147 A B C D Trim-basket...
- Page 10 Publication No. FRS28ZRGD0, FRS28ZRGD1, FRS28ZRGW0, FRS28ZRGW1 5995310504 SHELVES 07/98...
- Page 11 FRS28ZRGD0, FRS28ZRGD1, FRS28ZRGW0, FRS28ZRGW1 A = FRS28ZRG (FRS28ZRGD0) B = FRS28ZRG (FRS28ZRGD1) C = FRS28ZRG (FRS28ZRGW0) D = FRS28ZRG (FRS28ZRGW1) 13 # 20A* 21 # 23 # 114# 137# 141# 141# # = Fast-moving Parts * = Non-Illustrated Parts SHELVES...
- Page 12 Publication No. FRS28ZRGD0, FRS28ZRGD1, FRS28ZRGW0, FRS28ZRGW1 5995310504 SYSTEM 07/98...
- Page 13 FRS28ZRGD0, FRS28ZRGD1, FRS28ZRGW0, FRS28ZRGW1 A = FRS28ZRG (FRS28ZRGD0) B = FRS28ZRG (FRS28ZRGD1) C = FRS28ZRG (FRS28ZRGW0) D = FRS28ZRG (FRS28ZRGW1) 13 # 14 # 15 # 21 # 30 # 31 # 55 # 60 # # = Fast-moving Parts...
- Page 14 Publication No. FRS28ZRGD0, FRS28ZRGD1, FRS28ZRGW0, FRS28ZRGW1 5995310504 DISPENSER 07/98...
- Page 15 FRS28ZRGD0, FRS28ZRGD1, FRS28ZRGW0, FRS28ZRGW1 A = FRS28ZRG (FRS28ZRGD0) B = FRS28ZRG (FRS28ZRGD1) C = FRS28ZRG (FRS28ZRGW0) D = FRS28ZRG (FRS28ZRGW1) 17A* 33 # 35 # 38A# 38B# # = Fast-moving Parts * = Non-Illustrated Parts DISPENSER 5308010366 A - C - Tube-water inlet,93"...
-
Page 16: Ice Container
Publication No. FRS28ZRGD0, FRS28ZRGD1, FRS28ZRGW0, FRS28ZRGW1 5995310504 ICE CONTAINER 07/98... - Page 17 FRS28ZRGD0, FRS28ZRGD1, FRS28ZRGW0, FRS28ZRGW1 A = FRS28ZRG (FRS28ZRGD0) B = FRS28ZRG (FRS28ZRGD1) C = FRS28ZRG (FRS28ZRGW0) D = FRS28ZRG (FRS28ZRGW1) 18 # 45 # # = Fast-moving Parts * = Non-Illustrated Parts ICE CONTAINER 5304404344 A B C D Auger-ice...
-
Page 18: Ice Maker
Publication No. FRS28ZRGD0, FRS28ZRGD1, FRS28ZRGW0, FRS28ZRGW1 5995310504 ICE MAKER 07/98... - Page 19 FRS28ZRGD0, FRS28ZRGD1, FRS28ZRGW0, FRS28ZRGW1 A = FRS28ZRG (FRS28ZRGD0) B = FRS28ZRG (FRS28ZRGD1) C = FRS28ZRG (FRS28ZRGW0) D = FRS28ZRG (FRS28ZRGW1) 5308010366 5318582501 11 # 12 # 13 # 15 # 17 # 5303320545 5303320544 5303207445 5308000133 5303001343 5303001193 5303001191 5303001549...
