PRODUCT NO.
BASE MODEL NO.
FRS26RBCW0
FRS26RBC
MARKET
North America
ENERGY GUIDE - 240598618
OWNER'S GUIDE - 240389311
SERVICE DATA SHEET - 240389610
ELECTROLUX HOME PRODUCTS, INC
P.O. BOX 212378, Augusta, GA 30917
SERIES
COLOR
R134a
white
Publication No.
5995391520
030606
-EN/SERVICE/KHB
357
PARTS CATALO
VOLTS
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS26RBC
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY
G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS26RBC and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRS26RBC

Summary of Contents for Frigidaire FRS26RBC

  • Page 1 PRODUCT NO. BASE MODEL NO. FRS26RBCW0 FRS26RBC MARKET North America ENERGY GUIDE - 240598618 OWNER’S GUIDE - 240389311 SERVICE DATA SHEET - 240389610 ELECTROLUX HOME PRODUCTS, INC P.O. BOX 212378, Augusta, GA 30917 SERIES COLOR R134a white SIDE BY SIDE REFRIGERATOR Publication No.

  • Page 2: Freezer Door

    Publication number FRS26RBCW0 5995391520 FREEZER DOOR 06/03...
  • Page 3 POS. NO 37A* # = Fast-moving Parts * = Non-Illustrated Parts FRS26RBCW0 FREEZER DOOR PART NO DESCRIPTION 240390602 Gasket-frzr door,white ,magnetic 240334201 Bin-door,frzr-upper 240351601 Bin-door 240451802 Door-frzr,white ,complete assy 240537102 Door Stop,white ,frzr 218762701 Handle-door,white 5308016566 Screw,hex washer hd, 8-15A x 0.625, low profile 218781100 Screw,pan head ,8-18 x 0.625 240328202...

  • Page 4: Refrigerator Door

    Publication number FRS26RBCW0 5995391520 REFRIGERATOR DOOR 06/03...
  • Page 5 POS. NO 37A* # = Fast-moving Parts * = Non-Illustrated Parts FRS26RBCW0 REFRIGERATOR DOOR PART NO DESCRIPTION 240390601 Gasket-refr door,white ,magnetic 240323001 Bin-door,pseudo ,bottom 240326203 Door-dairy 240537101 Door Stop,white ,ref 240451902 Door-refr,white ,complete assy 218762701 Handle-door,white 5308016566 Screw, hex washer head, 8-15A x 0.625, low profile 218781100 Screw,pan head ,8-18 x 0.625...
  • Page 6 Publication number FRS26RBCW0 5995391520 CABINET 06/03...
  • Page 7 POS. NO 14 # 14A# 66B* 100* # = Fast-moving Parts * = Non-Illustrated Parts FRS26RBCW0 CABINET PART NO DESCRIPTION 240435902 Cover-air duct 240475902 Cover-evap coil,lower 5303208309 Plug-hole,factory test 240505801 Switch,light/lamp 215486600 Switch-light/lamp 218252200 Screw,#8 truss hd ,10-32CA x 0.500 240457701 Plate-door closer 240402701...
  • Page 8 Publication number FRS26RBCW0 5995391520 SHELVES 06/03...
  • Page 9 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRS26RBCW0 SHELVES PART NO DESCRIPTION 240434604 Trim-basket 240338802 Shelf-freezer,flip-up 240338702 Shelf-freezer,fixed wire 240338704 Shelf-freezer,fixed wire 240373108 Frame-shelf,cantilever 240350702 Cover-crisper pan,upper 240362101 Clip-slide,cover-crisper 240350902 Cover-crisper pan,lower 240351005 Pan-crisper,upper 240349801 Clip-slide,pan-crisper 240362201 Control-humidity 240351207 Pan-crisper,lower...
  • Page 10 Publication number FRS26RBCW0 5995391520 CONTROLS 06/03...
  • Page 11 POS. NO 13 # 21 # 137# 138* # = Fast-moving Parts * = Non-Illustrated Parts FRS26RBCW0 CONTROLS PART NO DESCRIPTION 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240315803 Motor-evap fan 215474201 Washer,"slinger" ,nylon ,evap fan shaft 5303292397 Bracket-motor mtg,rear 240436702...
  • Page 12 Publication number FRS26RBCW0 5995391520 SYSTEM 06/03...
  • Page 13 POS. NO 14 # 15 # 29 # 30 # 55 # 60 # 61 # # = Fast-moving Parts * = Non-Illustrated Parts FRS26RBCW0 SYSTEM PART NO DESCRIPTION 240333603 Condenser 218679607 Block-evap coil,styrofoam ,(2) 218944001 Drier-filter,R134a System 240346402 Harness-wiring,machine compt 240439901 Wiring Harness,controls 240449601...
  • Page 14 Publication number FRS26RBCW0 5995391520 DISPENSER 06/03...
  • Page 15 POS. NO 38A# # = Fast-moving Parts * = Non-Illustrated Parts FRS26RBCW0 DISPENSER PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet, inlet valve to ice maker 218976904 Tube-water inlet, valve to filter 218976907 Tube-water inlet, valve to door 5304428805 Cover-module, white 5304421823 Module-dispenser, white 5304426649...

  • Page 16: Ice Container

    Publication number FRS26RBCW0 5995391520 ICE CONTAINER 06/03...
  • Page 17 POS. NO 18 # # = Fast-moving Parts * = Non-Illustrated Parts FRS26RBCW0 ICE CONTAINER PART NO DESCRIPTION 5304428402 Auger-ice 5304404343 Cam-drive 218815300 Container-ice,bucket only 5304404346 Drum-ice disp 218815400 Front-ice container 5304404337 Bar-drive 5304404359 Gate 5303001179 Light Bulb/Lamp,40 W 5303289050 Socket-light/lamp 5304404345 Drive Blade...

  • Page 18: Ice Maker

    Publication number FRS26RBCW0 5995391520 ICE MAKER 06/03...
  • Page 19 POS. NO 11 # 12 # 13 # 15 # 17 # 55 # # = Fast-moving Parts * = Non-Illustrated Parts FRS26RBCW0 ICE MAKER PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet, inlet valve to ice maker 218976904 Tube-water inlet, valve to filter 218976907 Tube-water inlet, valve to door 240561701...

  • Page 20: Wiring Schematic

    Publication number FRS26RBCW0 5995391520 WIRING SCHEMATIC 06/03...

  • Page 21: Wiring Diagram

    FRS26RBCW0 Publication No. 5995391520 WIRING DIAGRAM # = Fast-moving Parts 06/03 * = Non-Illustrated Parts...
