PRODUCT NO.
BASE MODEL NO.
FRS26R2AQ6
FRS26R2A
FRS26R2AW6
FRS26R2A
MARKET
North America
WIRING DIAGRAM - 240389613
OWNER'S GUIDE - 240389311
SERVICE DATA SHEET - 240389613
ELECTROLUX HOME PRODUCTS, INC
P.O. BOX 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque
R134a
white
Publication No.
5995396578
030925
-EN/SERVICE /DCS
357
PARTS CATALO
VOLTS
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS26R2A
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY
G
Advertisement
Table of Contents
Related Manuals for Frigidaire FRS26R2A
Summary of Contents for Frigidaire FRS26R2A
- Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRS26R2AQ6 FRS26R2A R134a bisque FRS26R2AW6 FRS26R2A R134a white MARKET North America WIRING DIAGRAM - 240389613 OWNER’S GUIDE - 240389311 SERVICE DATA SHEET - 240389613 SIDE BY SIDE REFRIGERATOR ELECTROLUX HOME PRODUCTS, INC Model No.
-
Page 2: Freezer Door
Publication No. FRS26R2A 5995396578 FREEZER DOOR 09/03... - Page 3 FRS26R2A Publication No. 5995396578 FREEZER DOOR A = FRS26R2A (FRS26R2AQ6) B = FRS26R2A (FRS26R2AW6) POS. NO PART NO DESCRIPTION 240390602 Gasket-frzr door,white ,magnetic 240334201 Bin-door,frzr-upper 240351601 Bin-door 240451808 Door-frzr,bisque ,complete assy 240451802 Door-frzr,white ,complete assy 240537104 Door Stop,bisque ,frzr 240537102 Door Stop,white ,frzr 218762706 Handle-door,bisque...
-
Page 4: Refrigerator Door
Publication No. FRS26R2A 5995396578 REFRIGERATOR DOOR 09/03... - Page 5 FRS26R2A Publication No. 5995396578 REFRIGERATOR DOOR A = FRS26R2A (FRS26R2AQ6) B = FRS26R2A (FRS26R2AW6) POS. NO PART NO DESCRIPTION 240390601 Gasket-refr door,white ,magnetic 240323001 Bin-door,pseudo ,bottom 240326203 Door-dairy 240537103 Door Stop,bisque ,ref 240537101 Door Stop,white ,ref 240451906 Door-refr,bisque ,complete assy 240451902 Door-refr,white ,complete assy 218762706...
- Page 6 Publication No. FRS26R2A 5995396578 CABINET 09/03...
- Page 7 FRS26R2A Publication No. 5995396578 CABINET A = FRS26R2A (FRS26R2AQ6) B = FRS26R2A (FRS26R2AW6) POS. NO PART NO DESCRIPTION 240435904 Cover-air duct 240475904 Cover-evap coil,lower 5303208309 Plug-hole,factory test 14 # 240505801 Switch,light/lamp 14A# 215486600 Switch-light/lamp 218252200 Screw,#8 truss hd ,10-32CA x 0.500 240457701 Plate-door closer 240402701...
- Page 8 Publication No. FRS26R2A 5995396578 SHELVES 09/03...
- Page 9 FRS26R2A Publication No. 5995396578 SHELVES A = FRS26R2A (FRS26R2AQ6) B = FRS26R2A (FRS26R2AW6) POS. NO PART NO DESCRIPTION 240434604 Trim-basket 240338802 Shelf-freezer,flip-up 240338702 Shelf-freezer,fixed wire 240338704 Shelf-freezer,fixed wire 240355208 Shelf-"Spill-Safe",fixed 240350702 Cover-crisper pan,upper 240362101 Clip-slide,cover-crisper 240350902 Cover-crisper pan,lower 240351007 Pan-crisper,upper 240349801 Clip-slide,pan-crisper 240351207...
- Page 10 Publication No. FRS26R2A 5995396578 CONTROLS 09/03...
- Page 11 FRS26R2A Publication No. 5995396578 CONTROLS A = FRS26R2A (FRS26R2AQ6) B = FRS26R2A (FRS26R2AW6) POS. NO PART NO DESCRIPTION 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 13 # 240315803 Motor-evap fan 215474201 Washer,"slinger" ,nylon ,evap fan shaft 5303292397 Bracket-motor mtg,rear 240436702...
- Page 12 Publication No. FRS26R2A 5995396578 SYSTEM 09/03...
- Page 13 FRS26R2A Publication No. 5995396578 SYSTEM A = FRS26R2A (FRS26R2AQ6) B = FRS26R2A (FRS26R2AW6) POS. NO PART NO DESCRIPTION 240333603 Condenser 218679607 Block-evap coil,styrofoam ,(2) 218944001 Drier-filter,R134a System 240346402 Harness-wiring,machine compt 240449601 Harness-wiring 241508102 Harness-wiring,control box 14 # 5303918253 Defrost Heater Kit 15 # 5303918284 Evaporator Kit...
- Page 14 Publication No. FRS26R2A 5995396578 DISPENSER 09/03...
- Page 15 FRS26R2A Publication No. 5995396578 DISPENSER A = FRS26R2A (FRS26R2AQ6) B = FRS26R2A (FRS26R2AW6) POS. NO PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet,inlet valve ,to ice maker 218976904 Tube-water inlet,valve to filter 218976907 Tube-water inlet,valve to door 5304429705 Cover-module,bisque 5304428805 Cover-module,white 5304422144 Module-dispenser,bisque...
-
Page 16: Ice Container
Publication No. FRS26R2A 5995396578 ICE CONTAINER 09/03... - Page 17 FRS26R2A Publication No. 5995396578 ICE CONTAINER A = FRS26R2A (FRS26R2AQ6) B = FRS26R2A (FRS26R2AW6) POS. NO PART NO DESCRIPTION 5304428402 Auger-ice 5304404343 Cam-drive 218815300 Container-ice,bucket only 5304404346 Drum-ice disp 218815400 Front-ice container 5304404337 Bar-drive 5304404359 Gate 5303001179 Light Bulb/Lamp,40 W 5303289050 Socket-light/lamp 5304404345...
-
Page 18: Ice Maker
Publication No. FRS26R2A 5995396578 ICE MAKER 09/03... - Page 19 FRS26R2A Publication No. 5995396578 ICE MAKER A = FRS26R2A (FRS26R2AQ6) B = FRS26R2A (FRS26R2AW6) POS. NO PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet,inlet valve ,to ice maker 218976904 Tube-water inlet,valve to filter 218976907 Tube-water inlet,valve to door 240561701 Seal-water inlet,inlet valve ,to ice maker 5304420650 Spring,shut-off arm 3206299...
-
Page 20: Wiring Schematic
Publication No. FRS26R2A 5995396578 WIRING SCHEMATIC 09/03... -
Page 21: Wiring Diagram
FRS26R2A Publication No. 5995396578 WIRING DIAGRAM # = Fast-moving Parts 09/03 * = Non-Illustrated Parts...
