  • Page 1 RANGEHOOD & INSTALLATION GUIDE UM1390-6S www.schweigen.com.au (09.2018/v1.0)

  • Page 2: Welcome

    Upon collection or delivery of your appliance, any damage or defects must be reported within 48 hours to your retailer or Schweigen Customer Service, in order to recognise any claim. The manufacturer reserves the right to introduce product improvements, which do not affect the operation of the appliance.

  • Page 3: Table Of Contents

    Table of Contents 1. Welcome ____________________________________________________________________ 2 2. Important Safety Information ___________________________________________________ 4 3. Description __________________________________________________________________ 7 4. Installation __________________________________________________________________ 8 5. Operation __________________________________________________________________ 14 6. Cleaning and Maintenance _____________________________________________________ 15 7. Troubleshooting _____________________________________________________________ 18 8. Technical Specifications ______________________________________________________ 21 9.

  • Page 4: Important Safety Information

    2. Important Safety Information Please read the instructions carefully. Only then will you be able to operate your appliance safely and correctly. Retain the instruction manual for future use or for subsequent owners. Check the appliance for damage after unpacking it. Do not connect or install the appliance if it has been damaged in transport.
  • Page 5 Check that the indicated instructions and local regulations are met and carried out by a qualified technician, using materials that are complaint with the applicable legislation. Schweigen will not be responsible for any installations executed by non-qualified technicians that fail to heed the applicable legislation on electrical safety.
  • Page 6 2. Important Safety Information Product Use The Rangehood has one mode of operation: Air extraction: The air is drawn in by the rangehood, filtered through the grease filters, and then expelled outside. Please check the cleaning and maintenance section for advice on the filter’s cleaning schedule. This product is designed for household use and must not be used for commercial applications.

  • Page 7: Description

    3. Description Rangehood 1. For use with Isodrive motor system © 2. Male plug (main power 240V) 3. Single 200mm outlet 4. Reducer (for Isodrive 650 only) © 5. Filter 6. Lamp (for GU10 fittings, please twist to remove) NOTE: Filter and light quantity may vary from model to model.

  • Page 8: Installation

    4. Installation System Overview 1. Isodrive Motor 2. Roof Seal Kit (Dektite)* 3. Support Straps* 4. Attach Flexi Duct to Bell-Mouth Adaptor using cable tie or ring clamp. Please DO NOT rip the ducting. 5. Isodrive Motor Power Lead (Male Plug) 6.
  • Page 9 650mm 750 to 800mm Recomended Installation Height for Induction Cooktop Type of Cooktop Min. Height* Max. Height Notes * Schweigen’s recommended height will help avoid condensation, Induction 700mm 800mm particular to cooking with an Induction Cooktop. Refer to additional notes.
  • Page 10 4. Installation Overhead cabinet Rangehood Installation position It is important to consider the benchtop and overhead cabinetry depth before installing the rangehood. The information below is to be used as a guide only, drawings are not to scale and do not account for all circumstances.
  • Page 11 FRONT VIEW SIDE VIEW SIDE VIEW 4. Installation SIDE SIDE VIEW Mounting and Fixing Points The diagrams below are a guide for all mounting points. SIDE VIEW SIDE VIEW TOP VIEW Side View Front View FRONT VIEW Wall Cabinet Mounting point A and B need to be tighten with slightly angled screws to pull the...
  • Page 12 SIDE VIEW SIDE VIEW 4. Installation Optional Installation Example IMPORTANT TOP VIEW Please read the installation guide thoroughly prior to installation. This model has a different method of installation compared to standard undermounts. FRONT VIEW WARNING Please remove filters before installation. Failure to do so may damage the clips. BOTTOM VIEW Step 1 SIDE VIEW...
  • Page 13 4. Installation Flexible Ducting Installation Please do not crush or kink flexi ducting, as it will reduce air flow and may cause noise to occur through the system. Ducting must be kept taut at all times. Isodrive Motor Setup NOTE Please refer to the Isodrive motor installation guide for more details on flexi ducting and Isodrive motor installation.

  • Page 14: Operation

    5. Operation Schweigen silent rangehoods are recognised for their silent operation. Although this holds true for all of our rangehoods with external motors, one must note that the rangehoods are silent when they are used for regular cooking on the lower fan setting. Therefore, you will only hear the movement of air.

  • Page 15: Cleaning And Maintenance

    6. Cleaning and Maintenance WARNING Always switch off and disconnect power to the rangehood before cleaning. The manufacturer is exonerated from all responsibility in the event of fire due to poor maintenance of the filters and rangehood. Cleaning and user maintenance shall not be made by children without supervision. Filters •...
  • Page 16 6. Cleaning and Maintenance Surfaces The surface of the rangehood can be cleaned with warm soapy water and a soft sponge / cloth. • Never use abrasive detergents, scouring pads, steel wool or solvents on ANY part of this appliance. •...
  • Page 17 6. Cleaning and Maintenance Replacing the Lights DANGER Always switch off and disconnect power before replacing the lights. Failure to do so may cause serious injury. Please be aware that the light bulb may retain heat for a short period of time after being switched off.

  • Page 18: Troubleshooting

    7. Troubleshooting Cooking with Induction Cooktops Cooking with an induction or similar cooktop, may produce condensation on the rangehood. Unlike basic electric or gas cooking, induction cooktops heat food and liquid instantly, which in turn, produces vapours rapidly. Because of the accelerated process, the rangehood filters do not have enough time to warm up, which increases the chance of condensation forming.
  • Page 19 7. Troubleshooting Before you contact the technical service department, make sure that the product is plugged in and power is supplied. • Do not take any action that will damage the product. IMPORTANT Never attempt to repair this appliance by yourself. Always refer to a qualified Service Technician. Rangehood does not work Light does not...
  • Page 20 It is not the responsibility of Schweigen Home Appliances to rectify any incorrect installations. A service call out fee will be charged for any Schweigen technician that attends a call, whereby it is established that the fault is due to an incorrect installation or non-manufacturing fault. Should the appliance be installed in such a way that the service agent is unable to gain access to the appliance, the person/s who own the premises where the appliance resides —...

  • Page 21: Technical Specifications

    2 x 3W Weight 6.3kg 350.5 350.5 UM1390-6S 16.4 16.4 47.5 47.5 Note: Product specifications subject to change without notice, images are for illustrative purposes only. Please check final product details with your retailer. © Schweigen Home Appliances Pty Ltd. Page 21...
  • Page 22 8. Technical Specifications Note: Product specifications subject to change without notice, images are for illustrative purposes only. Please check final product details with your retailer. © Schweigen Home Appliances Pty Ltd. Page 22...

  • Page 23: Disclaimer

    All information supplied is to be used for general reference purposes only and is on the understanding that Schweigen Home Appliances will not be liable for any loss, liability or damage of whatever kind arising as a result of any reliance upon such information. All pictures used in the guide are for illustrative purposes only.
