Frigidaire PLES399E Supplementary Manual

Frigidaire ples399e: supplementary guide
Hide thumbs

Advertisement

Quick Links

PLES399EC.eps LA20BG0050.eps BPLES389ECB.eps LA20CT0058.eps
DPLES389ECB.eps
318271927-1.eps 318271927-2.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
PLES399ECB
37957366J53S2
Series
30" slide-in
Color
stainless
Market
North America
Wiring Diagram
318271927
Owner's Guide
318203859
Installation Instructions 318201611
Timer Guide
318200194
Publication No.
5995449880
05/09/30
(EN/SERVICE/ECL)
377
30-INCH SLIDE-IN
ELECTRIC RANGE
Model No.
PLES399E
©
Copyright
2005 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading

  Related Manuals for Frigidaire PLES399E

  Summary of Contents for Frigidaire PLES399E

  • Page 1 30" slide-in Color stainless Market North America Wiring Diagram 318271927 Owner's Guide 318203859 Installation Instructions 318201611 Timer Guide 318200194 30-INCH SLIDE-IN ELECTRIC RANGE PLES399E Publication No. 5995449880 05/09/30 (EN/SERVICE/ECL) © Copyright 2005 Electrolux Home Products, Inc. Model No. All rights reserved.
  • Page 2 Publication No: 5995449880 PLES399ECB BACKGUARD 09/05...
  • Page 3 POS. NO PART NO. 318299102 318306900 318313826 318224405 20 # 316418735 5304451726 318233710 318319301 318298001 54 # 316441800 54A# 316441801 54B# 316441804 316247700 316247800 5303323134 316435702 318223900 318233400 318228818 318224813 318083021 08016432 5303300265 5303311333 # Functional Parts * Non-Illustrated Parts PLES399ECB BACKGUARD DESCRIPTION...
  • Page 4 Publication No: 5995449880 PLES399ECB BODY 09/05...
  • Page 5 POS. NO PART NO. 318259203 318225112 318258902 318225210 318225211 318175503 318262503 318219500 318262001 318318600 5303317977 5303317976 12 # 318089917 318224000 5303013071 3201911 5304400195 318147411 37 # 316217002 5303310526 318222400 318285055 318285056 318072560 318261600 5303935061 5303323139 5303323144 318264200 66 # 318255600 318254901 5304403015 318259100...
  • Page 6 Publication No: 5995449880 PLES399ECB BODY 09/05...
  • Page 7 POS. NO PART NO. 112# 318112703 119# 318005212 125# 316415800 318317100 318272900 318003000 318123910 161# 318255503 318014110 318298401 166A 318298402 318335500 318165800 318298201 318298210 219# 318003614 219A 318003613 316136500 318224941 318235300 3051050 3201861 08016432 5303211311 5303307980 5303323129 5304415832 5304436875 # Functional Parts * Non-Illustrated Parts PLES399ECB BODY...
  • Page 8 Publication No: 5995449880 PLES399ECB TOP/DRAWER 09/05...
  • Page 9 POS. NO PART NO. 318304401 318300000 318300300 318303901 318298810 318259501 318259500 15 # 318198817 15A# 318258201 15B# 318198926 318223647 318147430 318219802 318225410 51 # 318044822 318122006 318122008 318122011 5303311174 81 # 318255300 84 # 318005105 318257600 316095800 318300100 318303800 316105501 141# 318005211 318227503...
  • Page 10 Publication No: 5995449880 PLES399ECB DOOR 09/05...
  • Page 11 POS. NO PART NO. 318260401 318262101 318260500 318285057 318285062 316117500 318259605 5303311174 318053130 318272162 316402403 318024714 5304415832 318260301 318219802 318242700 5304436875 318165800 316221001 # Functional Parts * Non-Illustrated Parts PLES399ECB DOOR DESCRIPTION Trim, oven door, side, (2) Cover, rear door, black, (2) Baffle, door Insulation, oven door Insulation, oven door...
  • Page 12: Wiring Diagram

    Publication No: 5995449880 BK-9 T.B. BK-6 BK-6 BR-2 BR-6 BAKE ELEMENT ELEMENT CUISSON BROIL ELEMENT ELEMENT GRIL BL-6 OPTIONAL WARMER DRAWER/TIROIR RECHAUD FACULTATIF WARMER ELEMENT/ELEMENT RECHAUD TIMER BR-5 MINUTERIE P11-4 TIMER MINUTERIE P11-1 LO LIMIT THM/THM BASSE LIMITE LEGEND/LEGENDE - SWITCH/INTERRUPTEUR R.F.
  • Page 13 PLES399ECB Publication No: 5995449880 WIRING DIAGRAM 09/05 # Functional Parts * Non-Illustrated Parts...
