Multi-Sector Batch Set Up - Quick Guide
Start ProtoCOL 3 software
1
Enter
2
Position plate
Capture image
Click
3
Slide
Click
Create batch
4
Click
Plate configuration
5
Select
Choose an application
6
Select
ProtoCOL 3
Log on to ProtoCOL 3
Insert the plate holder, ensuring the
plate holder that gives the best
contrast between the colony and
background is used
Place plate onto plate holder
Select the image tab and check the
live box
Adjust the exposure by increasing/
decreasing the sliding scale
Capture image
Click New Batch
Select Plate Configuration to set
plate size, sample volume and
threshold. Defaults are Circular
plate 90mm, Sample volume
1ml. Change if necessary
Select Multi-Sector Plate
Page 1 of 2
Advertisement
Related Manuals for SynOptics SYNBIOSIS ProtoCOL 3
Summary of Contents for SynOptics SYNBIOSIS ProtoCOL 3
- Page 1 ProtoCOL 3 Multi-Sector Batch Set Up - Quick Guide Start ProtoCOL 3 software Enter Log on to ProtoCOL 3 Insert the plate holder, ensuring the plate holder that gives the best contrast between the colony and Position plate background is used Place plate onto plate holder Capture image Select the image tab and check the...
- Page 2 Name the batch Name the batch Enter Set frame Click Select to increase or decrease the number of sectors Default is 4 sectors, to adjust click on the drop down menu Total plate count Click Select Total Plate Count or Colour Classification as per quick guide Enter a plate ID Enter a plate ID on the Measure tab .
