BRIGHTLUX AL17-36FT-RGB-2 Use And Care Manual

TOOLS REQUIRED
Phillips Screwdriver
I
NSTALLATION
PREPARING TO EXTEND THE
ROPE LIGHTS
Ensure all rope lights are unplugged
before adding the additional rope
light (A) to the series.
Remove the end cap (1) from the last
rope light in the series by turning
counterclockwise.
Remove the power cord (2) from
additional extension rope lights (A).
Extend up to 72ft. (21.9m) maximum.
Use only the following BrightLux rope
light extension segments:
9000-0002.
S I
AFETY NFORMATION
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
Ground Fault Circuit Interrupter (GFCI) protection should be provided in the circuits
or outlet to be used for outdoor use. Receptacles are available that have built-in GFCI
protection.
Only use outdoor extension cords such as type SW, SOW, STW, STOW, SJW, SJOW, SJTW,
or SJTOW. This designation is marked on the wire of the extension cord.
The rated voltage for this product is 120VAC, 60Hz, 72W, 0.6A.
Do not operate this product with the flexible light tightly coiled.
Do not route the cord or flexible light cable through walls, doors, windows, or any
similar part of a building structure.
Do not subject flexible lighting to continous flexing.
Do not exceed the maximum extension length in feet permitted by the marking. The
maximum extension length for this rope light is 72ft. (21.9m).
The RF remote controller included utilizes a 3V CR2025 battery; only replace with same
battery type. Please dispose of batteries properly. Batteries are not a toy! If swallowed,
contact local emergency services immediatley.
SAVE THESE INSTRUCTIONS
WARNING: This product has a polarized plug (one blade is
wider than the other) as a feature to reduce the risk of electrick
shock. This plug will fit in a polarized outlet only one way. If the
plug does not fit fully in the outlet, reverse the plug. If it still
does not fit, contact a qualified electrician. Never use with an
extension cord unless the plug can be fully inserted.
Do not alter the plug.
Brightlux is a trademark of American Ligthing, Inc.
© 2021 All Rights Reserved.
HARDWARE INCLUDED
A - 36ft. LED Chasing B - Inline Controller
Rope Light x 1
CONNECTING THE
ROPE LIGHTS
Connect the last rope light in the
series and the extension rope.
light (A) together and ensure the
connectors are tightly secured.
Attach the end cap (1) to the last rope
light in the series and ensure the
connection is secure.
Use and Care Guide
36ft. LED Chasing Rope Light
C - Mounting
w/120V Plug x 1 Clip x 18
PAGE1
Item # 9000-0002
Model # AL17-36FT-RGB-2
SC
C3
C7
4H 8H
C16
D - Screw x 36 E - 28 Key IR
Remote x 1
MOUNTING THE ROPE LIGHTS
Insert the screw (D) through the
opening in the mounting clip (B).
Screw the mounting clip (C) into
position at the installation location.
Place the rope light (A) securely into
the mounting clip (C).
Mounting clips should be evenly spaced
and be a maximum of 3ft. (0.91 m) apart.
Make sure the distance between two
lines of rope light is at least 1/2in. (12 mm).
D
WARNING: When using this product outdoors,
basic safety precautions should always be
followed to reduce the risk of fire, electric
shock, and personal injury.
WARNING: Do not cover this product as the
covering may cause the flexible light to
overheat and either melt or ignite.
WARNING: Do not puncture, cut, shorten, or
splice the flexible lighting.
WARNING: Do not use if there is any
damage to the light or cord insulation.
Inspect periodically.
WARNING: Do not mount or secure the rope
light in a manner than can cut the outer jacket
or damage the cord insulation. Inspect the
rope light carefully before use and discard any
rope lights that have a broken outer jacket,
loose connections, or frayed wire insulation.
WARNING: Do not submerge the flexible light
in liquids or use the product in the vicinity of
standing water or other liquids.
WARNING: Secure the rope lights using only
the mounting clips provided. Do not secure
this product with staples, nails, or similar
objects that may damage the insulation.
WARNING: Do not install the rope light
within 16 ft. (4.87 m) of pool or spa. Do not
install rope lighting in cabinets, tanks, or
enclosures of any kind.
CAUTION: All units must be unplugged before
you add additional segments. Only use
segments recommended by the manufacturer
of this lighting system.
CAUTION: Ensure all connections and the end
cap on the last segment are tightly secured to
prevent the entry of water.
Please contact us at 1-844-255-9692 for further assistance.
F - 3V CR2025
Battery x 1
C
