Frigidaire GLGFS86D Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Ranges
  5. GLGFS86D
  6. Factory parts catalog
Frigidaire GLGFS86D Factory Parts Catalog

Frigidaire GLGFS86D Factory Parts Catalog

30-inch freestanding gas range
Hide thumbs

Advertisement

Quick Links

Download this manual
GLGF386DC.eps T24G0012.eps T24B0007.eps T24V0026.eps T24T0024.eps
T24D0012.eps
316417808d.eps 316417808s.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
GLGFS86DCA
Series
30" f/s gas
Color
stainless
Market
North America
Wiring Diagram
316417808
Owner's Guide
316417102
Installation Instructions 316259336
Service Data Sheet
316417603
Publication No.
5995421400
04/11/08
(EN/SERVICE/ECL)
369
Copyright
30-INCH FREE-
STANDING GAS
RANGE
Model No.
GLGFS86D
©
2004 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading

Related Manuals for Frigidaire GLGFS86D

Summary of Contents for Frigidaire GLGFS86D

  • Page 1 Market North America Wiring Diagram 316417808 Owner's Guide 316417102 Installation Instructions 316259336 Service Data Sheet 316417603 30-INCH FREE- STANDING GAS Model No. GLGFS86D Publication No. 5995421400 04/11/08 (EN/SERVICE/ECL) © Copyright 2004 Electrolux Home Products, Inc. RANGE All rights reserved.
  • Page 2 Publication No: 5995421400 GLGFS86DCA BACKGUARD 11/04...
  • Page 3 POS. NO PART NO. 316416100 316051600 316235100 316022500 316411405 316411404 316424194 20 # 316418306 316419303 24C# 316114002 316220002 316204974 316416200 316040201 316230701 316021105 316021108 316021109 316021110 # Functional Parts * Non-Illustrated Parts GLGFS86DCA BACKGUARD DESCRIPTION Shield, backguard, rear wall Shield, backguard, inner Shield, top, inner Light/Lamp, indicator, 125 V Support, backguard, black, RH...
  • Page 4 Publication No: 5995421400 GLGFS86DCA BURNER 11/04...
  • Page 5 POS. NO PART NO. 316219501 5303935233 2A # 5303935235 2B # 5303935232 2C # 5303935234 316215600 316219006 318079001 10 # 316223300 10A# 316206400 10B# 316212300 10C# 316212400 11 # 316430500 11A# 316430800 11B# 316430401 11C# 316430600 11D# 316430700 13 # 316405300 14 # 316091706...
  • Page 6 Publication No: 5995421400 GLGFS86DCA BODY 11/04...
  • Page 7 POS. NO PART NO. 316401600 316402201 316437100 316400104 316400105 316201403 316272900 316407200 316404501 316400603 12 # 316407100 316116400 5303013071 08011086 316087500 18 # 316405800 316408000 316406200 316407301 316217700 316217701 316402500 316116600 316208901 37 # 316217001 3202006 316400703 3131732 316246501 316234200 316404200 316404800 316403700...
  • Page 8 Publication No: 5995421400 GLGFS86DCA TOP/DRAWER 11/04...
  • Page 9 POS. NO PART NO. 316408701 316403200 316409300 316407400 316411216 316424601 316424801 316271900 316206600 316213600 316213500 316246100 316099500 316279700 316021105 316021108 316021109 316021110 # Functional Parts * Non-Illustrated Parts GLGFS86DCA TOP/DRAWER DESCRIPTION Drawer, utility Liner, drawer Panel, drawer, stainless, outer Glide, drawer, rear Maintop, black Grate, black, (2) Grate, center, black...
  • Page 10 Publication No: 5995421400 GLGFS86DCA DOOR 11/04...
  • Page 11 POS. NO PART NO. 316408501 316402307 316403900 316117500 316423801 316001002 316008401 316403101 316407800 316102208 316102205 316402403 316408600 316406909 316418900 316246100 316408101 316422201 316408300 316021110 316433603 316431100 316279700 316021109 5303271648 5303285179 # Functional Parts * Non-Illustrated Parts GLGFS86DCA DOOR DESCRIPTION Glass, door front, black Shield, wool Insulation, oven door Glass, oven door, heat barrier...

  • Page 12: Wiring Schematic

    Publication No: 5995421400 GLGFS86DCA WIRING SCHEMATIC 11/04...

  • Page 13: Wiring Diagram

    GLGFS86DCA Publication No: 5995421400 WIRING DIAGRAM 11/04 # Functional Parts * Non-Illustrated Parts...
