PRODUCT NO.
BASE MODEL NO.
GLGFS66CBA
GLGFS66C
GLGFS66CQA
GLGFS66C
GLGFS66CSA
GLGFS66C
SERVICE DATA SHEET - # 316218504
WIRING DIAGRAM - #316255216
OWNER'S GUIDE - # 316257503
INSTALLATION INSTRUCTIONS -# 316259315
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
Gallery
black
Gallery
bisque
Gallery
white
Publication No.
5995385662
030210
-EN/SERVICE /ECL
369
FACTORY
PARTS CATALO
MARKET
North America
North America
North America
GAS
RANGE
Model No.
GLGFS66C
©2003 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire GLGFS66C
Summary of Contents for Frigidaire GLGFS66C
- Page 1 PRODUCT NO. BASE MODEL NO. GLGFS66CBA GLGFS66C GLGFS66CQA GLGFS66C GLGFS66CSA GLGFS66C SERVICE DATA SHEET - # 316218504 WIRING DIAGRAM - #316255216 OWNER’S GUIDE - # 316257503 INSTALLATION INSTRUCTIONS -# 316259315 ELECTROLUX HOME PRODUCTS, INC. P.O. Box 212378, Augusta, GA 30917...
- Page 2 Publication No. GLGFS66C 5995385662 BACKGUARD 02/03...
- Page 3 A = GLGFS66C (GLGFS66CSA) B = GLGFS66C (GLGFS66CBA) C = GLGFS66C (GLGFS66CQA) POS. NO 20 # 24 # # = Fast-moving Parts * = Non-Illustrated Parts GLGFS66C BACKGUARD PART NO DESCRIPTION 316239900 A B C Shield,backguard ,rear wall 316051600 A B C...
- Page 4 Publication No. GLGFS66C 5995385662 BURNER 02/03...
- Page 5 A = GLGFS66C (GLGFS66CSA) B = GLGFS66C (GLGFS66CBA) C = GLGFS66C (GLGFS66CQA) POS. NO 2A # 2B # 2C # 10A# 10B# 10C# 11 # 11A# 11B# 11C# 13 # 14 # 16 # 17 # 18 # 19 #...
- Page 6 Publication No. GLGFS66C 5995385662 BODY 02/03...
- Page 7 A = GLGFS66C (GLGFS66CSA) B = GLGFS66C (GLGFS66CBA) C = GLGFS66C (GLGFS66CQA) POS. NO 12 # 18 # 37 # 89 # 170* 170* 170* # = Fast-moving Parts * = Non-Illustrated Parts GLGFS66C BODY PART NO DESCRIPTION 316029416 A B C...
- Page 8 Publication No. GLGFS66C 5995385662 TOP/DRAWER 02/03...
- Page 9 A = GLGFS66C (GLGFS66CSA) B = GLGFS66C (GLGFS66CBA) C = GLGFS66C (GLGFS66CQA) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts GLGFS66C TOP/DRAWER PART NO DESCRIPTION 316011503 A B C Drawer 316231400 A B C Liner,drawer 316231205 A - -...
- Page 10 Publication No. GLGFS66C 5995385662 DOOR 02/03...
- Page 11 A = GLGFS66C (GLGFS66CSA) B = GLGFS66C (GLGFS66CBA) C = GLGFS66C (GLGFS66CQA) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts GLGFS66C DOOR PART NO DESCRIPTION 5303935192 A - - Trim kit-door,3 sided ,white ,w/tape and foil 5303935191 - B -...
-
Page 12: Wiring Schematic
Publication No. GLGFS66C 5995385662 WIRING SCHEMATIC 02/03... -
Page 13: Wiring Diagram
GLGFS66C Publication No. 5995385662 WIRING DIAGRAM # = Fast-moving Parts 02/03 * = Non-Illustrated Parts...
