ITEM NO. 92334 – WHITE
ITEM NO. 92336 – BROWN
1
TABLE TOP W/ DRAWER
1PC
4
BACK STRETCHER
1PC
A
BOLT 1/4" X 1/2"
10PCS
*** Do not tighten screws & bolts until the entire unit is completely assembled. ***
ASSEMBLY
RIGHT SIDE PANEL
MIRROR TOP
LEVELER
4PCS
INSTRUCTIONS
2
1PC
5
1PC
B
3
LEFT SIDE PANEL
1PC
6
HANDLE
1PC
C
ALLEN KEY
1PC
Advertisement
Table of Contents
Related Manuals for Acme Furniture Boice 92334
Summary of Contents for Acme Furniture Boice 92334
- Page 1 ITEM NO. 92334 – WHITE ITEM NO. 92336 – BROWN ASSEMBLY INSTRUCTIONS TABLE TOP W/ DRAWER RIGHT SIDE PANEL LEFT SIDE PANEL BACK STRETCHER MIRROR TOP HANDLE BOLT 1/4” X 1/2” LEVELER ALLEN KEY 10PCS 4PCS *** Do not tighten screws & bolts until the entire unit is completely assembled. ***...
- Page 2 STEP 1 *Please put all parts on a soft surface to prevent scratches. Attach back stretcher (4) to right side panel (2) and left side panel (3) by using bolt (A) as shown. STEP 2 Attach metal frame to table top w/ drawer (1) by using bolt (A) as shown.
- Page 3 STEP 3 Turn the table upright carefully and disassemble the handle (6) from the inside of drawer and re-assemble it to the outside of drawer as shown. STEP 4 Put mirror top (5) on table top (1) carefully. You desk is now complete.
