- Page 1 Pneumatic 1” Impact Wrench #505108, JAT-108 Operation & Parts Manual M-505108 Edition 1 05/2019 427 New Sanford Road LaVergne, TN 37086 Ph.: 800-274-6848 www.jettools.com Copyright © 2019 JET...
- Page 2 15. Excessive air pressure and too much free Do not use this tool for other than its intended rotation may decrease life of the tool and may use. If used for other purposes, JET disclaims cause a hazardous situation. any real or implied warranty and holds itself 16.
- Page 3 32. Do not lubricate the tool with combustible how often you do this type of work. To reduce liquids, such as kerosene, diesel or jet fuel. your exposure to these chemicals, work in a well-ventilated area and work with approved 33.
-
Page 4: About This Manual
As with any tool operation, safety of operator and bystanders should be first priority. If there are questions or comments, please contact your local supplier or JET. JET can also be reached at our web site: www.jettools.com. -
Page 5: Tool Specifications
Specifications were current at time of publication, but because of our policy of continuous improvement, JET reserves the right to change specifications at any time and without prior notice, without incurring obligations. -
Page 6: Setup And Assembly
Any missing parts or damage should be reported Rotate regulator dial to preferred setting. ® immediately to your JET distributor. Do not use a Regulator settings are for reference only and damaged tool. Read this instruction manual do not indicate specific power settings. -
Page 7: Maintenance
Tool Pressure Air system requirements JET Air Tools operate on 70-to-100 psi (pounds per square inch) air pressure measured at the tool Use proper air hose size (refer to tool when the tool is operating. Set tool to 90 psi specifications). - Page 8 Use a light oil containing rust inhibitors, such as directly, rather than with quick connect fittings SAE #10. Many JET air tools have integral oil which may cause pressure drops and tool power reservoirs, which should be kept filled when in-line reduction.
- Page 9 Troubleshooting JAT-108 Impact Wrench Any disassembly of the tool should be done by qualified service personnel. For problems not addressed below, contact JET technical service at 800-274-6846. Problem Possible cause Remedy Tool will not start. Air valve closed or obstructed.
- Page 10 Possible cause Remedy Severe air leakage. Air valve obstructed or damaged. Clean or replace. (Note: Minimal escape of Housing loose or damaged. Tighten or replace as needed. air is often normal for air tools.) JAT-108 Impact Wrench ...
-
Page 11: Replacement Parts
Replacement parts Service parts are listed on the following pages. To order parts or reach our service department, call 1-800- 274-6848 Monday through Friday, 8:00 a.m. to 5:00 p.m. CST. Please have the stock number and serial number of your tool available when you call, so that we may serve you quickly and accurately. Some parts are shown for reference only, and may not be available individually. - Page 12 #505108, JAT-108, 1-inch Impact Wrench – exploded view JAT-108 Impact Wrench ...
- Page 13 #505108, JAT-108, 1-inch Impact Wrench – parts list # Part No. Description # Part No. Description 1 JAT105-01 Motor housing 35 JAT105-35 Hammer pin 7.6x63.5 mm * 2 JAT101-02 Spring pin 2x20L mm 36 JAT108-36 Anvil 1 in. * 3 JAT108-03...
-
Page 14: Warranty And Service
Shop Tools; Warehouse & Dock products; Hand Tools: Air Tools NOTE: JET is a division of JPW Industries, Inc. References in this document to JET also apply to JPW Industries, Inc., or any of its successors in interest to the JET brand. - Page 15 This page intentionally left blank. ...
- Page 16 427 New Sanford Road LaVergne, Tennessee 37086 Phone: 800-274-6848 www.jettools.com JAT-108 Impact Wrench ...
