VIKING SERVICE MANUAL
MICROWAVE DRAWER MODELS
DMOD240SS
Setup/
Sensor
Sensor
Sensor
Sensor
OPEN
OPEN
Help
Popcorn
Reheat
Cook
Cook
Control
Keep Warm
Defrost
Reheat
Reheat
CLOSE
CLOSE
Lock
On/Off
In the interest of user-safety the unit should be restored to its original condition and only parts identical to those specified should
be used.
WARNING TO SERVICE PERSONNEL:
This service manual is intended for use by persons having electrical and mechanical training and a level of
knowledge of these subjects generally considered acceptable in the appliance repair trade. Sharp Electronics
Corporation cannot be responsible, nor assume any liability, for injury or damage of any kind arising from the
use of this manual.
Microwave ovens contain circuitry capable of producing very high voltage and current. Contact with the
following parts may result in a severe, possibly fatal, electrical shock. (High Voltage Capacitor, High Voltage
Power Transformer, High Voltage Rectifier and Heat sink etc., and Magnetron, High Voltage Harness etc..)
BEFORE SERVICING ....................................................................................................... INSIDE FRONT COVER
WARNING TO SERVICE PERSONNEL ................................................................................................................. 3
MICROWAVE MEASUREMENT PROCEDURE ..................................................................................................... 4
FOREWORD AND WARNING ............................................................................................................................... 5
PRODUCT SPECIFICATIONS ............................................................................................................................... 6
SCHEMATICS ...................................................................................................................................................... 0
TEST PROCEDURES ..........................................................................................................................................
TOUCH CONTROL PANEL ASSEMBLY .............................................................................................................. 9
MICROWAVE DRAWER DISASSEMBLY ............................................................................................................. 27
WIRING DIAGRAMS ............................................................................................................................................ 33
PRINTED WIRING BOARDS ............................................................................................................................... 34
PARTS LIST ......................................................................................................................................................... 38
PACKING AND ACCESSORIES .......................................................................................................................... 43
This document has been published to be used for after sales service only. The contents are subject to change without notice
