EWC Controls EWT-855 Installation Manual page 6

Programming
Default Programming
Factory Default Program
Day of
Events
the Week
Wake/OCC1
Leave/UNOCC1
Weekday
Return/OCC2
Sleep/UNOCC2
Wake/OCC1
Leave/UNOCC1
Saturday
Return/OCC2
Sleep/UNOCC2
Wake/OCC1
LeaveUNOCC1
Sunday
Return/OCC2
Sleep/UNOCC2
Programming
To customize your 7 day 4 time period Program schedule, follow
these steps:
Monday:
1. Select HEAT or COOL with the SYSTEM key.
Note: You have to program heat and cool each separately.
2. Press the MENU button (If menu does not appear first, press
RUN SCHED).
3. Press SET SCHED. Note: Monday is displayed and the
WAKE/OCC1 icon is shown. You are now programming the
WAKE/OCC1 time period for that day.
4. Time is flashing. Use the
selection for that day's WAKE/OCC1 time period.
Note: If you want the fan to run continuously during this time
period, select ON with the FAN key. If you want to use IAQ
mode during this time period, select IAQ with the FAN key.
5. Press NEXT.
6. The setpoint temperature is flashing. Use the
to make your setpoint selection for that day's WAKE/OCC1
period.
7. Press NEXT.
8. Repeat steps 4 through 7 for that day's LEAVE/UNOCC1
time period, for that day's RETURN/OCC2 time period,
and for that day's SLEEP/UNOCC2 time period.
Repeat steps 4 through 8 for the remaining days of the week.
A Note About Auto Changeover:
In Auto you have the ability to switch between Auto Heat or Auto Cool
by pressing the system key. This can be done once the current mode has
reached its setpoint. For example: if in Auto Heat, the heat setpoint must
be satisfied before the thermostat will allow you to switch to Auto Cool.
You can switch out of Auto by holding down the system key. To get back
into Auto, you must toggle the system key to Auto.
Setpoint
Time
Temperature Temperature
(HEAT)
6 AM ˚ ˚
70 F (21 C)
8 AM ˚ ˚
62 F (17 C)
6 PM ˚ ˚
70 F (21 C)
10 PM ˚ ˚
62 F (17 C)
˚ ˚
6 AM
70 F (21 C)
8 AM
˚ ˚
62 F (17 C)
6 PM ˚ ˚
70 F (21 C)
˚ ˚
10 PM
62 F (17 C)
˚ ˚
6 AM
70 F (21 C)
8 AM
˚ ˚
62 F (17 C)
˚ ˚
6 PM
70 F (21 C)
˚ ˚
62 F (17 C)
10 PM
or key to make your time
Programming
Setpoint
Day of
the Week
(COOL)
˚ ˚
75 F (24 C)
Weekday
˚ ˚
83 F (28 C)
˚ ˚
75 F (24 C)
Saturday
˚ ˚
78 F (26 C)
˚ ˚
75 F (24 C)
Sunday
˚ ˚
83 F (28 C)
˚ ˚
75 F (24 C)
You can use the table on the next page to plan your customized program
schedule if using 5+1+1.
˚ ˚
78 F (26 C)
˚ ˚
75 F (24 C)
˚ ˚
83 F (28 C)
˚ ˚
75 F (24 C)
˚ ˚
78 F (26 C)
Programming
Set Program Schedule For Two Time Periods
To customize your 5+1+1 Program schedule, follow these steps:
Weekday:
1. Select HEAT or COOL with the SYSTEM key.
Note: You have to program heat and cool each separately.
2. Press the MENU button (If menu does not appear first, press
RUN SCHED).
3. Press SET SCHED. Note: Monday-Friday is displayed and the
OCCUPIED text is shown. You are now programming the
OCCUPIED time period for the weekday setting.
4. Time is flashing. Use the
selection for the weekday OCCUPIED time period.
Note: If you want the fan to run continuously during this time
period, select ON with the FAN key. If you want to use IAQ
mode during this time period, select IAQ with the fan key.
5. Press NEXT.
or key
6. The setpoint temperature is flashing. Use the
to make your setpoint selection for the weekday OCCUPIED
period.
7. Press NEXT.
8. Repeat steps 4 through 7 for the weekday UNOCCUPIED
time period.
Saturday:
Repeat steps 4 through 7 for the Saturday OCCUPIED time period
and for the Saturday UNOCCUPIED time period.
Sunday:
Repeat steps 4 through 7 for the Sunday OCCUPIED time period, and
for the Sunday UNOCCUPIED time period.
Factory Default Program for 2 Time Periods
Events Time
Temperature
OCCUPIED
8 AM
70
UNOCCUPIED
64
6 PM
OCCUPIED 8 AM
70
UNOCCUPIED
64
6 PM
OCCUPIED
8 AM
70
UNOCCUPIED
6 PM
64
or
Setpoint Setpoint
Temperature
(HEAT) (COOL)
˚ ˚ ˚ ˚
F (21 C) 72 F (22 C)
˚ ˚ ˚ ˚
F (18 C) 80 F (27 C)
˚ ˚
˚ ˚
F (21 C)
72 F (22 C)
˚ ˚ ˚ ˚
F (18 C) 80 F (27 C)
˚ ˚
˚ ˚ 72 F (22 C)
F (21 C)
˚ ˚
˚ ˚ 80 F (27 C)
F (18 C)
(OCCUPIED, UNOCCUPIED)
key to make your time
or key
