USER'S MANUAL
Washing Machine
EP24896

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EP24896 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Costway EP24896

Summary of Contents for Costway EP24896

  • Page 1 SHOP EASY. SAVE MONEY. USER'S MANUAL Washing Machine EP24896...

  • Page 2: Table Of Contents

    Contents Name of all components Note Using advice Name of all components Accessories Installation instructions Laying the machine Connection of the inlet/drain hose Connection of the power cord Operating instructions Control panel Operation Safety warning Maintenance Maintenance Trouble shooting Program Time Table Program Time Table...

  • Page 3: Note

    Note 1. This product belongs to Class I appliances. Please pay attention to electricity safety when using: This machine uses a single- phase two-pole grounded power outlet, the outlet must be reliably grounded, and grounding terminal should not be connected with gas pipelines, water pipes and other utilities.
  • Page 4 – farm houses; – by clients in hotels, motels and other residential type environments; – bed and breakfast type environments; – areas for communal use in blocks of flats or in launderettes. If the manufacturer wants to limit the use of the appliance to less than the above, this shall be clearly stated in the instructions.

  • Page 5: Using Advice

    clothing during washing or spinning. 18. Do not open the door cover when the washing machine is spinning. 19. When the washing machine is working, do not put your hand into the bucket of the running washing machine, even if the speed is very slow, it is dangerous.

  • Page 6: Name Of All Components

    Name of all components Water inlet valve Top lid Back control board Detergent box Power cord Filter Bleach injection Pulsator Control panel Up drain pipe Frame Back cover Body Base Adjustable foot Accessories Washing machine (1) Instruction manual (1) Inlet hose (1) MODEL: XQB50-1699J 110V 60Hz...

  • Page 7: Installation Instructions

    Installation instructions Laying the machine Insert the mice-proof plate into the washing machine base 2. Take out the mice-proof plate 1. Remove the plastic accessory at the top of the machine. as below picture from the bottom of washing machine before use. 4.

  • Page 8: Connection Of The Inlet/Drain Hose

    Installation instructions Connection of the inlet/drain hose Connection of the inlet hose 1. Select the appropriate type of outlet as shown in the figure. 2. Before installation, run water through both faucet and inlet hose, to get rid of particles in the water line that might clog the inlet valve screen. 3.

  • Page 9: Connection Of The Power Cord

    Connection of the drain hose (some modes have been connected) 1. Press down the fix ring, 2. Press down the fix ring, and 3. Top of tub must be no higher than then push it to the drain outlet. and hitch it over the drain 90cm from bottom of waster(A) Clasping the fix ring to make hose.

  • Page 10: Control Panel

    Control panel Program 01. Fuzzy 05.Soak&Wash Set the water level automatically Soak for certain time before according to the load of laundry. washing. 02. Heavy 06. Single Wash To wash the coverlet, jeans and Only for washing. other big clothes. 07.

  • Page 11: Operation

    Operation Install the water inlet hose Press POWER ON/OFF Plug-in power. and turn on the tap. to turn on the machine Press PROGRAM to select the desired program. Press WATER LEVEL to set the water level. Put down the drain pipe.
  • Page 12 Make sure the bottom ventilation, when the unit The water-proof clothes such as raincoat are not is placed on blanket. recommended to avoid abnormal vibration or damage for clothes. Bottom opening Blanket Do not place the washing machine in a damp Never use water over 50℃.

  • Page 13: Maintenance

    Maintenance Clean the filter in the inlet valve Clean the filter in the inlet valve regularly in order to prevent it from clogging Take off the inlet hose and Clean the valve filter with Restall the valve filter and take out the valve filter. a brush.

  • Page 14: Trouble Shooting

    Clean the lint filter 1. Pully upward to remove 2. Take the filter from 3. Clean and rinse 4. Reinstall the filter. the filter assy's. the filter cover. it thoroughly. Trouble shooting Malfunction phenomenon Reason The washing machine will start from the spin process Start the washing machine from in order to spin out the water and detergent from the rinse process, the washing...
  • Page 15 Trouble Shooting Method For some troubles, the machine buzzer will ring and alarm, and the indicator will flash. Indicator Light Troubles Possible Cause Solution The plug is badly connected Connect the plug properly or No indicator to the socket or the switch is activate the switch not activated.

  • Page 16: Program Time Table

    Program Time Table Rinse (min) Soak Spin Program (min) (min) (min) 1st rinse 2nd rinse 3rd rinse Spin Spin Fuzzy Spin Speedy Spin Spin Heavy Soak Spin Spin Soak & Wash /wash Spin Spin Spin Gentle Single spin Single wash Air dry Note: the table shows the default time of the system, which is not included the water inlet time.
