- Page 1 ComfortLink™ II XL1050 One System. Limitless Potential. Complete Control. WITH Model TZON1050AC52ZA 32-5093-04A-EN...
- Page 2 Congratulations! Thank you for choosing the XL1050 Smart Features Include: Control. The intuitive interface and powerful • Wi-Fi or Ethernet Connectivity features incorporated into this large color touch • Nexia™ climate service screen control represent the latest in climate • Built in Nexia Bridge control technology from the industry’s leader in residential heating and air conditioning systems.
-
Page 3: Table Of Contents
Quiet Mode ............. 30 Notices Nexia Remote Climate Access is included with the purchase of Trane smart connected controls. Up to four Trane smart controls, of any FCC & IC NOTICE ............ 31 combination, may be connected to a Nexia smart home system account without a monthly service fee. Additional smart controls and home automation devices may require a monthly subscription for remote access via most web-enabled smartphones, tablets and computers. -
Page 4: Navigation Overview
Navigation Overview All of the XL1050 features may be accessed via the Home, Menu, and Settings screens Home Screen Menu Screen Settings Screen Wed, Jul 13 4:19 PM Menu Settings ° Settings Schedules Weather System Info Zones Thermostat Screen Date & Time Network Cool to 74°... -
Page 5: Home Screen
Home Screen Notifications and System Alerts appear here Date and Network 4:19 PM Wed, Jul 13 Time appear Status here Press arrow to increase Current temperature ° temperature and status is Press to select Cool to displayed 74° Heating or Cooling Heat to temperature... -
Page 6: Menu Screen
Menu Screen Press to view 5-Day Weather Press to access Alerts, Notifications and Press to enable, disable, view or edit Forecast, Radar and Alerts information about the Control your schedule (requires Nexia registration) Menu View individual Press to access all Zone Temperature user settings (see and Temperature... -
Page 7: Settings Screen
Settings Screen Press to set Temperature Sensor, Press to set up Display features, Screen Layout, Press to set up Date & Time. Date & Time auto features and calibration Clean Screen and Screen Lock/Guest Access update when connected/registered with Nexia Settings Press to connect to a WiFi... -
Page 8: Home Screen Customization
Home Screen Customization You may choose to use the Default home screen or customize the interface with the following features. Default Default + Presets Add Optional Widgets (Scheduling is Disabled) (Scheduling is Disabled) (Scheduling may be Enabled or Disabled) Wed, Jul 13 4:19 PM Home Preset... -
Page 9: Default + Presets
Default + Presets 1-Touch Presets provide predetermined Set To edit the parameters, press the EDIT Choose the desired preset and press Points for Home, Away and Sleep time periods. button, and first, select AWAY. APPLY. The preset temperature settings will be displayed on the Home Screen. The Note: 1-Touch Presets requires Scheduling To change the Cooling Set Point, press the selected preset will display at bottom right:... -
Page 10: Adding Widgets
Adding Widgets Optionally, up to 3 widgets may be chosen to appear on your home screen. They can be selected by navigating to Menu > Settings > Screen > Screen Layout When scheduling is 4:19 PM Wed, Jul 13 enabled, the Preset button is disabled In multi-zone and a Permanent Outdoor Temp... -
Page 11: User Setup Wizard
User Setup Wizard The User Setup Wizard guides you through the The User Setup Wizard will guide you through After each step, the Wizard will show your XL1050’s User configurable settings. the following screens: progress. Press Next to begin the next section. To complete the Setup Wizard and connect the Display XL1050 to Nexia Smart Home Systems, you need... -
Page 12: Display
Begin wizard 1) Display From Home Screen, Press: MENU > SETTINGS > USER SETUP WIZARD Settings Press NEXT Thermostat Screen Date & Time Network User Setup SW Upgrades Reminders Reboot Wizard Home Back Select User Setup Wizard to begin. Press NEXT and set your preferred display brightness, backlight, screen saver and color theme settings. -
Page 13: Screen Layout
1 Requires internet service and registration with Nexia™ smart home system. 2 Requires the servicing Trane dealers code to be entered in the control. 3 Requires weather service to be enabled. 4 Requires accessories to be installed. -
Page 14: Scheduling
3) Scheduling 4A) Guided Scheduling (If Scheduling Enabled Chosen) After pressing Scheduling Enabled, the welcome to Guided Scheduling screen is displayed. Scheduling Options in Wizard Select STAY HOME or LEAVE. Press NEXT. Stay Home will set up 2 periods per day, wake •... - Page 15 4B) 1-Touch Presets (If Scheduling Disabled Chosen) 1-Touch Presets provide predetermined Heating and Cooling Set Points for Home, Away and Sleep time periods. See page 9 for detailed instructions how to configure 1-Touch presets. Adjust the time you would prefer the Wake Period to Start using the up and down arrows.
-
Page 16: Network Setup
5) Network Setup There are three ways to connect the XL1050 2. Wi-Fi connection using WPS Press “Hidden Network” which will be at the end Control to a local network: of the list of available networks. If there are more than eight networks, you will need to scroll to the next page. -
Page 17: Nexia Registration
Wireless setup screens and display the Nexia Registration screen next. Select SIGN UP NOW to set up an account or log in to an existing account. Select the ENROLL button for Trane XL824, Press NEXT XL850 or the XL1050 Control. 32-5093-04A-EN... - Page 18 6) Nexia Registration (cont.) Your XL1050 comes equipped with remote climate access from Nexia™ Smart Home Systems: • Control your home climate from your smartphone • View local weather • Receive alerts Go to www.mynexia.com to set up your account before proceeding. Return to the XL1050 control and Press NEXT.
-
Page 19: Weather Setup
7) Weather Setup To view your local weather press LOCATION To view the 5 day forecast press FORECAST. To view weather warnings press ALERTS and enter your Zip Code. Use the backspace button to delete the current To view the weather map press RADAR. Wizard zip code. -
Page 20: Manual Scheduling
Manual Scheduling The XL1050 Smart Control is capable of adjusting After pressing ENABLE SCHEDULE, the factory • Guided Scheduling – See the Guided Scheduling the temperature settings throughout the day default week-long schedule screen will be displayed. portion in the User Wizard. A series of screens will according to a user-programmable schedule. -
Page 21: Changing The Schedule
Changing the Schedule The day of the week to be To change the temperature settings in each period and adjust the period start and stop time press the red or blue area. The up/down Day arrows will change to Temperature and Add/Delete period buttons scheduled is highlighted will change to Time Start/Time Stop Schedule... - Page 22 Changing the Schedule (cont.) Changing Period Start or End Times To change temperature settings press in the red or blue 1. Press anywhere in a Period to make it active. area, then adjust the setting up or down with the arrows Press to adjust start and Other Periods will dim and the Start and on the right.
-
Page 23: Adding Periods
Adding Periods Adding Periods 1. Press ADD PERIOD, the Add Period Screen is displayed. 2. Press the green circle where you would like to insert a Period. Press one of the plus signs to insert a new period here. 3. Choose a name for the new Period or select New to define a custom name and press Add Period NEXT. -
Page 24: Deleting Periods
Deleting Periods Deleting Periods 1. From the Schedule Screen press DELETE PERIOD, the Delete Periods Screen is displayed. Press one of the trash cans to delete that period. 2. Press the TRASH CAN icon in the Period(s) you wish to delete. Delete Period 3. - Page 25 Screen Lock and Guest Access The XL1050 features several options to lock the screen so users cannot make unwanted changes. Turning on Guest Access allows Users to make up to 5 degree changes to temperature settings. All other settings will remain locked. Applying screen lock will cause the screen to lock Screen Lock after 1 minute of inactivity.
-
Page 26: Nexia™ Smart Home System
Nexia™ smart home system When enrolled to a Nexia™ smart home account, the XL1050 is a Z-Wave Plus security-enabled device that can serve as a central hub for an entire network of home automation devices, POWER NETWORK including all non-battery powered devices that will act as repeaters on your network. -
Page 27: Adding/Removing Z-Wave Devices (Via 1050)
Adding/Removing Z-Wave Devices (via XL1050) Your XL1050 is designed to integrate seamlessly have four minutes to set the device into Adding Z-Wave Devices with a Nexia™ smart home system. learn mode after pressing the ADD DEVICE 1. From the HOME Screen, press MENU, then press NEXIA. -
Page 28: Adding Z-Wave Devices (Via Mobile App)
Adding Z-Wave Devices (via mobile app) Alternatively, your XL1050 allows you to add 4. Select Z-Wave Device. Z-Wave devices using the Nexia app on your mobile device. Adding Z-Wave Devices 1. Start the Nexia app. 2. Press the menu button in the top left corner. 3. -
Page 29: Advanced Z-Wave Settings
Advanced Z-Wave Settings Nexia’s ADVANCED SETTINGS screen contains Bridge Information three very powerful functions. Each of these If this bridge is being used as a secondary or functions is very specific and should be inclusion controller in the network, please reset approached with a measure of caution. -
Page 30: Other Features
Characteristics of Quiet Mode Locally Lifeline Factory Reset Lifeline Notification • For use with Trane’s TruComfort™ variable speed systems. • During heating mode, indoor heat is Terminology allowed if the system cannot maintain space conditions while Quiet Mode is active The following terms may be used interchangeably by other devices, manufacturers, and Nexia. -
Page 31: Fcc & Ic Notice
Notices FCC Notice to radio communications. However, there is no IC NOTICE guarantee that interference will not occur in a INFORMATION TO USER This device complies with Industry Canada particular installation. If this equipment does license-exempt RSS standards. Operation is This device complies with Part 15 of the FCC cause harmful interference to radio or television subject to the following two conditions: (1) this... - Page 32 For more information, please visit trane.com or tranetechnologies.com. Trane has a policy of continuous data improvement and it reserves the right to change design and specifications without notice. We are committed to using environmentally conscious print practices.
