T&S B-0200-LN Quick Start Manual

Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.com
This Space for Architect/Engineer Approval
Job Name __________________________Date_________
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Contractor_______________________________________
Architect/Engineer_________________________________
4"
102mm
4 13/16"
121mm
Product Specifications:
Double Pantry Faucet, Eterna Cartridges, Spreader w/ 1/2" NPT
Male Inlets & Lever Handles
T&S BRASS AND BRONZE WORKS, INC.
2 Saddleback Cove / P.O. Box 1088
Travelers Rest, SC 29690
Swivel Outlet Accepts
Standard T&S Swing
Nozzles
4"
102mm
Eterna Cartridges &
Lever Handles w/
Color Coded Indexes
Ø 1 1/8" [29mm]
1/2" NPT
Male Inlets
Drawn
Scale:
Model No.
B-0200-LN
REG. #A2601
ISO #9001 Item No.
2 1/4"
57mm
(2) 150A Tailpiece
and Nut Furnished
For Optional 1/4" NPT
Connection
Checked Approved
DHL KJG
Date:
1:4 04/04/11
Sheet:
JHB
1 of 2
