User Manual
HQE6807SDER
Important safety instructions .......................3
Description of your appliance .......................5
Installation .......................................7
Dimensions .......................................9
Electrolux Major Appliances International
10200 David Taylor Drive, Charlotte, NC 28262, USA
TABLE OF CONTENTS
www.white-westinghouse-intl.com
Using the appliance ..................................10
Care and cleaning .................................14
Troubleshooting ....................................15
Removing door handles .............................17
Made in Thailand
Advertisement
Related Manuals for White-Westinghouse HQE6807SDER
Summary of Contents for White-Westinghouse HQE6807SDER
-
Page 1: Table Of Contents
User Manual HQE6807SDER TABLE OF CONTENTS Important safety instructions .......3 Using the appliance ........10 Description of your appliance .......5 Care and cleaning .........14 Installation ........7 Troubleshooting ........15 Dimensions ........9 Removing door handles ......17 Electrolux Major Appliances International 10200 David Taylor Drive, Charlotte, NC 28262, USA Made in Thailand www.white-westinghouse-intl.com... - Page 2 BEFORE USING YOUR LEGEND: APPLIANCE WARNING Before you use the refrigerator, we recom- mend that you read through the whole user This symbol indicates information con- manual which provides the description of cerning your personal safety. the refrigerator and its functions. To avoid the risks that are always present when you use an electrical appliance, it is important CAUTION...
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Please read the user manual carefully and WARNING store in a handy place for later reference. Pass the user manual on to possible new The appliance must be plugged into its owners of the refrigerator. own dedicated 220-240V, 50Hz AC electri- Read the following carefully to avoid dam- cal outlet. - Page 4 IMPORTANT SAFETY INSTRUCTIONS WARNING WARNING It is important to use you refrigera- R600a refrigerant warning tor safely. This means you need to This appliance contains fl ammable R600a supervise young children and inform refrigerant. persons when they use it. You need Avoid safety hazards by carefully install- to make sure that young children do ing, handling, servicing and disposing of...
-
Page 5: Description Of Your Appliance
DESCRIPTION OF YOUR APPLIANCE Four-door refrigerator 12 11 23 Partition Lever Door bins (3 pcs) Deli compartment Adjustable glass shelf (2 pcs) Bottle bin (right) Fixed glass shelf Crisper Bottle bin (left) Twist ice and serve (2 pcs) Crisper Ice cube box Freezer drawer (small) Magnetic door seals Freezer drawer (large) - Page 6 DESCRIPTION OF YOUR APPLIANCE Control panel Function Select Timer LCD display Refrigerator temperature control Freezer temperature setting Freezer temperature control Refrigerator temperature setting Door alarm Function select button Child lock Setting selector Holiday mode Confi rmation button Express freezing Default setting Defrosting When power is turned on the display de- •...
-
Page 7: Installation
INSTALLATION 1. To ensure adequate ventilation for your • Do not place next to a heat generating refrigerator, it is recommended to pro- appliance. vide space of 60mm on both sides and • This refrigerator is designed for indoor use at the back, and space of 90mm above only –... -
Page 8: Dimensions
DIMENSIONS 890mm 890mm 441.5mm 13mm 685mm 817.5mm 1120mm 876.5mm 90° 1720mm Recommended clearances These are the recommended minimum clearances. 727.5mm 60mm 90mm 102mm 60mm 60mm Recommended airspace CABINET 817.5mm DOORS 200mm NOTE: Doors are designed to sit proud of 12mm cabinetry (not fl... -
Page 9: Using The Appliance
USING THE APPLIANCE The refrigerator controls its temperature 2. Press the button to select the automatically. desired temperature ( to increase, to decrease). However, if needed, adjust the temperature as follows. Refrigerator compartment 1. Press the “Function select” button and 3. - Page 10 USING THE APPLIANCE the end tone will sound (for about 30 To start operation seconds). 1. Press the “Function select” button and select the Door Alarm icon. 2. Press the button to select “ON”. 3. Press the button to confi rm. To stop the end tone, press Child lock The child lock can be turned on to prevent...
- Page 11 USING THE APPLIANCE select the Express freezing icon. 3. Press the button. 2. Press the button and select “ON”. The temperature inside the refrigerator compartment will be adjusted to 10°C. The 3. Press the button. temperature in the freezer is not changed. To cancel operation Select “OFF”...
- Page 12 USING THE APPLIANCE Dairy products and eggs NOTES: • Evenly place the food on the shelves • Most dairy products have a use by date to allow the cooling air to circulate ef- on the outer packaging which indicates fi ciently. the recommended temperature and •...
-
Page 13: Care And Cleaning
CARE AND CLEANING Care and cleaning NOTES: • Do not use hot water, household Some household cleaning chemicals can cleaning powders, creams or spray-on cause cracks, splits or discolouration on the cleaning products or any other cleaning inside surface of the refrigerator and door products such as mineral turpentine, liner. -
Page 14: Troubleshooting
TROUBLESHOOTING If you think something may be wrong with CAUTION your refrigerator, you can carry out some easy checks before calling for service. You The glass shelves weigh approxi- may locate the problem, sparing yourself mately 3kg each. Hold fi rmly when from inconvenience and saving time and removing from the cabinet or when money. - Page 15 TROUBLESHOOTING When the motor seems Your new refrigerator provides you with large capacities in both the to run more than refrigerator section and the separate freezer. It is normal for the motor to expected operate frequently. However, to keep operation to a minimum, check the following: •...
-
Page 16: Removing Door Handles
REMOVING DOOR HANDLES Removing door handles If you need to remove the handles from your door, please follow the instructions below: 1. Simply tap handle from below being sure not to scratch the handle. 2. Handle will unclip and can be pulled up and out to remove.
