Summary of Contents for Textron Greenlee GATOR ES32FLX11
- Page 1 Serial Number (ES20T/X shown) GATOR ® Battery-powered In-line Cutters Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. Register this product at www.greenlee.com 52080507 © 2016 Greenlee Textron Inc. 6/16...
-
Page 2: Table Of Contents
6,401,515, 6,718,870, 7,086,979, and 7,254,982. All specifications are nominal and may change as design improvements occur. Greenlee Textron Inc. shall not be liable for damages resulting from misapplication or misuse of its products. GATOR is a registered trademark of Textron Innovations Inc. -
Page 3: Important Safety Information
Failure to observe this warning could result in severe Failure to observe this warning injury from harmful fumes or burns from flying could result in severe injury or death. debris. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... - Page 4 Failure to observe these precautions may result in and property damage. injury or property damage. Note: Keep all decals clean and legible, and replace when necessary. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
-
Page 5: Identification
5. LED Indicator (red) 6. Lanyard Ring 7. LED Work Light (white) 8. Trigger ESG25T/X ESG45T/X 9. Cutting Blades (ETS8T/X and ETS12T/X) 10. Pull Pin (ESG45T/X) Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 6: Specifications
Depth ......................4.92" (125 mm) Weight ......................5.77 lb (2.62 kg) Cutting Capacity Maximum Cable Cutting Diameter (copper and aluminum, regular and fine) ............1.38" (35 mm) Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... - Page 7 Guy Strand ............... 5/16" dia. (3/8" dia. using two cycles) EHS Guy Strand ....................5/16" dia. Aircraft Cable ......................1/4" dia. Not recommended for fine stranded cables. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
- Page 8 Hydraulic Oil ............52057878 biodegradable hydraulic fluid Recommended Operating Temperature Range ....5 °F to 122 °F (–15 °C to 50 °C) Battery Charger .........Read the instructions supplied with the battery charger Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
-
Page 9: Operation
Flashing light for 20 seconds Send tool in for service at end of cycle * Running the battery below 16 V can damage the battery. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... - Page 10 Note: The cutting process can be interrupted at any moment by releasing the trigger. By actuating the retract slide, the piston and movable blade will return to the starting position. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
- Page 11 Note: If it is necessary to retract the ram before a cutting cycle is completed, push the retract button. Pushing the retract button will result in the complete retraction of the ram. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
-
Page 12: Lcd Screen
® only for the T version of this tool. Mobile unit not found Pressure sensor not found Burst pressure exceeded Battery temperature too low Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 13: Maintenance
Failure to observe these warnings could result in severe injury or death. Relief valve adjustments must be done by an authorized service center. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 14: Troubleshooting
LED glows for 20 Battery charge low. Charge or replace battery. seconds. Tool loses oil. Damaged seal. Contact Greenlee customer service at 800-435-0786 for warranty service or repair. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... - Page 15 Battery-powered In-line Cutters Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
- Page 16 4455 Boeing Drive • Rockford, IL 61109-2988 • USA • 815-397-7070 USA Tel: 800-435-0786 Canada Tel: 800-435-0786 International Tel: +1-815-397-7070 An ISO 9001 Company • Fax: 800-451-2632 Fax: 800-524-2853 Fax: +1-815-397-9247 Greenlee Textron Inc. is a subsidiary of Textron Inc. www.greenlee.com...
