G1 SCBA Radio Pairing Guide |
G1 SCBA Radio Pairing Guide for
BKR 5000
with the Bluetooth Option (BKR0560)
BK Technologies
2
3
4
6
7
8
9
10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BKR 5000 and is the answer not in the manual?

Questions and answers

Related Manuals for BK TECHNOLOGIES BKR 5000

Summary of Contents for BK TECHNOLOGIES BKR 5000

  • Page 1: Table Of Contents

    Creating a BKR 5000 Radio Pairing Tag Pairing a G1 SCBA and BKR 5000 Radio Using the G1 SCBA and BKR 5000 Radio Clearing Radio Pair Info from the G1 SCBA Clearing SCBA Pairing Info from the BKR 5000 Radio Troubleshooting...

  • Page 2: Bkr 5000 Configuration Settings

    Download, install, and open the latest version of RES (Radio Editor Software) (BKR0733). Contact your radio dealer for instructions and Serial Key Step 2. Connect the programming cable to the BKR 5000 Radio and the computer. Step 3. Turn on the BKR 5000 Radio using the volume knob. Step 4.

  • Page 3: Creating A G1 Scba Configuration Tag (For Bluetooth Pair Save Preferences)

    G1 SCBA Radio Pairing Guide | BK Technologies G1 Bluetooth Creating a G1 SCBA Configuration Tag (for Bluetooth Pair Save Preferences) Settings Tag The purpose of this section is to: (1) enable the Bluetooth radio on the G1 SCBA and (2) to set Bluetooth Pair Save behavior based on the department’s preference.

  • Page 4: Creating A Bkr 5000 Radio Pairing Tag

    If either is not visible there or under "Select Other device": disconnect and reconnect the hardware; Restart the A2 service if necessary. • Step 5. Turn on the BKR 5000 Radio using the volume knob. Step 6. Ensure Bluetooth is “ON”...
  • Page 5 G1 SCBA Radio Pairing Guide | BK Technologies Step 9. Verifying the Information Written to the Tag: Place RFID Tag on the RFID Reader / Writer Select the Read G1 Tag icon (top-right hand side of A2 application) The “Found Tag” screen will appear.

  • Page 6: Pairing A G1 Scba And Bkr 5000 Radio

    G1 regulator & breathes. If you encouter difficulty pairing the radio: • Clear the pair information stored on the radio, as described in the “Clearing SCBA Pairing Info from the BKR 5000 Radio” section in the pages hereafter. •...

  • Page 7: Using The G1 Scba And Bkr 5000 Radio

    Confirm that the G1 SCBA, and Radio, are paired together: Radio Tag has been applied (or applied previously and pair is saved) Step 1. Turn on the BKR 5000 Radio using volume knob. Step 2. Don the G1 SCBA and G1 Facepiece.

  • Page 8: Clearing Radio Pair Info From The G1 Scba

    G1 Pairing Removal Method 2 – Pair New Radio Step 1. Pair a different Bluetooth BKR 5000 Radio with the G1 SCBA using the new radio’s Bluetooth Audio Pairing Tag, as described in the “Pairing a G1 SCBA and BKR 5000 Radio” section.

  • Page 9: Clearing Scba Pairing Info From The Bkr 5000 Radio

    Step 2. Select “Forget All Devices” and press “ENT”. Bluetooth audio pair info is cleared from the BKR 5000 Radio. If not done already: Clear the pairing info from the previously connected G1 SCBA’s pair history using the process described in the “Clearing Radio Pair Info from the G1 SCBA” section, above.

  • Page 10: Troubleshooting

    Radio is a not a Contact your Radio dealer to To use G1 Bluetooth audio, BKR 5000 with get the Bluetooth Option pair with a BKR 5000 with Bluetooth Option (BKR0560). Bluetooth Option Radio and/or G1 was Clear the pairing information on...
