BKR0700 Cloning Cable
User Instructions
Contents
Operation ..............................................................................................1
Source Radio .......................................................................................2
....................................................................................4
Cloneable Information .........................................................................5
Advertisement
Table of Contents
Related Manuals for BK TECHNOLOGIES BKR0700
Summary of Contents for BK TECHNOLOGIES BKR0700
- Page 1 ® BKR0700 Cloning Cable User Instructions Contents Operation ....................1 Source Radio ..................2 Target Radio ..................4 Cloneable Information .................5...
-
Page 2: Operation
The BKR0700 Cloning Cable offers radio users the ability to share programmed information between BKR portable radios. For BKR portable radio cloning, one BKR0700 Cloning Cable is to be connected to to a Source BKR portable radio and a Target BKR portable... -
Page 3: Source Radio
Source Radio On the Source radio, select the zone with the information to be cloned by pressing the Zone button, or selecting “Zone Select” from the menu, then entering the number of the desired zone. On the Target radio select the Zone or Group to which the information is to be sent. - Page 4 Receiving Information Target radios display a message to indicate receiving incoming information. Destination Clone Start Target radios display “Destination Clone Start” during the cloning process. When the cloning process is successfully completed, the Target radio will automatically shut down and reset. NOTE: Upon reset the Target radio reverts to Zone 1.
-
Page 5: Target Radio
Target Radio The Target radio must be put in “Destination Clone Mode.” The BKR portable radio can only receive “Active Zone” or “Picklist” clone information. On the Target radio: Cloning 1. Select the Menu button. 1: Label 1 Clone Active Zone Clone Picklists 2. -
Page 6: Cloneable Information
Cloneable Information Channel Capacity Considerations When a Source radio’s zone is programmed with less channels than a Target radio, channels about the highest programmed Source channel will be set to inactive. A Target radio’s zone will assume the channel structure of the Source radio. - Page 7 ® BK Technologies 7100 Technology Drive West Melbourne, FL 32904 1-800-648-0947 ©2021 BK Technologies PN 7001-31153-100 REV. 04-21...
