Summary of Contents for Dohle ExOn7
- Page 1 Bedienungsanleitung Operating Instructions ExOn7 3x400V, DX315 Extrusionstechnik GmbH Dohle Eitorfer Strasse 1 D – 53809 Ruppichteroth www.dohle-extruder.de...
-
Page 2: Table Of Contents
Operating Instructions Industrial Extruder DX315 ExOn7 3x400V DOHLE We retain all copyrights of all descriptions, drawings and schedules contained in these operating instructions which may not be reproduced nor be made accessible by third parties or by competitors, neither in whole nor in part, unless we have expressly consented thereto. -
Page 3: Description Of Type
Operating Instructions Industrial Extruder DX315 ExOn7 3x400V DOHLE 1. Type Art.-no/Type of machine : DX315 ExOn7 3x400V Machine no..Required voltage 400 V / 50 – 60 Hz Heating unit for extruder : 1200 W Heating unit for air... - Page 4 Operating Instructions Industrial Extruder DX315 ExOn7 3x400V DOHLE Safety area: The hot air stream of the hand-held welding and extruding machine may not be directed to temperature-sensitive objects or living things. Ensure that a safety distance of 2 m is observed in all directions.
-
Page 5: Start-Up
Operating Instructions Industrial Extruder DX315 ExOn7 3x400V DOHLE 3. Start-up General: Observe the notes on safety contained in these operating instructions. In addition, the regulations on the prevention of accidents and the national regulations shall apply. Assembling the hand-held welding and extruding machine When dispatched, our hand-held welding and extruding machines are almost completely assembled. - Page 6 Operating Instructions Industrial Extruder DX315 ExOn7 3x400V DOHLE Display and control elements of front part of control unit Temperature unit Actual value temperature tettempevaluetemperatur AL (Alarm) Shines if the alarm Desired value temperatur exit is on Upward - key Downward - key Controller –...
- Page 7 Operating Instructions Industrial Extruder DX315 ExOn7 3x400V DOHLE Changing the welding filler Heat up the hand-held welding and extruding machine until operating temperature is reached to ensure that no welding filler is present in the machine, remove the weld shoe and exchange the die (caution, left-handed thread) by a new one or by a die used with the material to be applied now.
-
Page 8: Error Tracing
Operating Instructions Industrial Extruder DX315 ExOn7 3x400V DOHLE 4. Error tracing Malfunctioning Error– No. Driving motor does not start 01,02,04,05,06,07,08,09,10,11,12 Driving motor switches off 03,04,05,06,07,08,09,10 Extruder remains cold 04,05,06,07,08,09,15,17 Hot air remains cold 05,07,08,09,12 Hot air temperature is under 11,13... -
Page 9: Drawings, Informations
Operating Instructions Industrial Extruder DX315 ExOn7 3x400V DOHLE 5 Drawings, Informations DX315 ExOn7 3x400V DOHLE Extrusionstechnik GmbH... - Page 10 Operating Instructions Industrial Extruder DX315 ExOn7 3x400V DOHLE A rticle -N o D es crip tio n Q ty D - 01 26 s crew M 5x 1 0 D IN 91 2 D - 01 60 s crew M 6x1 0...
- Page 11 Operating Instructions Industrial Extruder DX315 ExOn7 3x400V DOHLE control box D - 0505 D - 2334 D - 2340 D - 0502 DH 020 D - 2286 D - 1091 D - 2193 D - 2196 D - 1092 D - 2062...
- Page 12 Operating Instructions Industrial Extruder DX315 ExOn7 3x400V DOHLE article-no description D - 0131 screw M4x16 Ms D - 0326 control box 5000-6000 D - 0502 front paneel D - 0505 head control box D - 1017 ULS screw M4x10 D - 1087...
- Page 13 Operating Instructions Industrial Extruder DX315 ExOn7 3x400V DOHLE Eron SSR, Art-Nr: D - 1058 DOHLE Extrusionstechnik GmbH...
- Page 14 Operating Instructions Industrial Extruder DX315 ExOn7 3x400V DOHLE article-no description 5101270 gasket 70x48x4 5101760 mica tube 47,6x95 5101776 heating element 230V/2200W 6100268 strain relief 6100284 countersunk screw M4x12 TX 6100287 hexagon nut M5 6100444 cord guard 9,6x75 6101242 connecting shackle...
- Page 15 Operating Instructions Industrial Extruder DX315 ExOn7 3x400V DOHLE DOHLE Extrusionstechnik GmbH...
- Page 16 Operating Instructions Industrial Extruder DX315 ExOn7 3x400V DOHLE DOHLE Extrusionstechnik GmbH...
- Page 17 Operating Instructions Industrial Extruder DX315 ExOn7 3x400V DOHLE DOHLE Extrusionstechnik GmbH...
- Page 18 Operating Instructions Industrial Extruder DX315 ExOn7 3x400V DOHLE Welding Shoes s = thickness of material fillet weld corner weld a = s x 0,7 thickness of material order - no. D-0195 10-12 D-0196 thickness of material order - no. D-0197...
