- Page 1 Rev. A Jul 07 Part # 562148-UV VD510-UV INSTRUCTION MANUAL DISPENSING VALVE MODEL VD510-UV ◀INSTRUCTION MANUAL▶...
-
Page 2: Table Of Contents
Rev. A Jul 07 Part # 562148-UV VD510-UV INSTRUCTION MANUAL CONTENTS 1 Introduction page 3 2 Specifications page 3 3 Part Description page 4 4 Operation Principles page 5 5 Operating Procedure page 6 5-1 Setup page 6 5-2 Maintenance page 9 6 Sectional Drawing &... -
Page 3: Introduction
VD510-UV INSTRUCTION MANUAL 1. INTRODUCTION The VD510-UV is a diaphragm valve designed for precise flow control of low to medium viscosity materials (under 10,000 cps). The valve is ideal for dispensing UV curable materials. Shot sizes may be fine tuned by turning the stroke adjustment knob at the top of the valve. -
Page 4: Part Description
Rev. A Jul 07 Part # 562148-UV VD510-UV INSTRUCTION MANUAL 3. PART DESCRIPTION... -
Page 5: Operation Principles
Rev. A Jul 07 Part # 562148-UV VD510-UV INSTRUCTION MANUAL 4. OPERATION PRINCIPLES Dispensing OFF Dispensing ON short Stroke long small Shot Volume large In the “Normal” state (air off), the diaphragm When air is applied, the diaphragm is opened and is closed –... -
Page 6: Operating Procedure
Rev. A Jul 07 Part # 562148-UV VD510-UV INSTRUCTION MANUAL 5. OPERATING PROCEDURE 5-1. Setup ▶example for general installation... - Page 7 Rev. A Jul 07 Part # 562148-UV VD510-UV INSTRUCTION MANUAL 5-1-1) Fasten the valve firmly using mount hole. (M5*P0.8*D98) 5-1-2) Connect air hose to Air In Port and Controller. Valve driving pressure is Min 4.0kgf/㎠ or more. 5-1-3) Connect fitting for material supply hose to the inner port (BSPT1/8") Notice Do not insert fitting too deeply (7 ㎜...
- Page 8 Rev. A Jul 07 Part # 562148-UV VD510-UV INSTRUCTION MANUAL 5-1-7) After steady mode in controller and reducing pressure of pressure container, make dispensing the liquid come out slowly. (This is to remove bubble and dispense the first liquid from valve) 5-1-8) Choose "timer"...
-
Page 9: Maintenance
Rev. A Jul 07 Part # 562148-UV VD510-UV INSTRUCTION MANUAL 5-2. Maintenance 5-2-1) Washing ①Wash valve thoroughly after using if dispensed liquid has tendency to be stiff or has possibility to damage liquid contacting part. ②First of all dispense all liquid entirely from pressure container, liquid supply hose and liquid contacting part until sufficient air comes out. - Page 10 Rev. A Jul 07 Part # 562148-UV VD510-UV INSTRUCTION MANUAL ⓓScrew new diaphragm carefully to become horizontal to piston road screw-thread. Notice If it isn't fit thread properly leakage may occur. ⓔAfter fixing diaphragm at regular intervals(0.4mm) like the picture, for matching cylinder body and mount screw, please turn to the location that you want using a screwdriver like next picture.
-
Page 11: Sectional Drawing & Dimension
Rev. A Jul 07 Part # 562148-UV VD510-UV INSTRUCTION MANUAL 6. SECTIONAL DRAWING & DIMENSIONS ▶ Cross-sectional View ▶ Dimension - Measurements shown in millimeters. -11-... -
Page 12: Exploded View & Parts List
Rev. A Jul 07 Part # 562148-UV VD510-UV INSTRUCTION MANUAL 7. EXPLODED VIEW & PARTS LIST ▶ Exploded View ▶ Parts List Part No Description Q'TY Part No Description Q'TY VD510-1-BLACK CHAMBER 1 VD510-7 WASHER VD510-2 CYLINDER BODY 1 VD510-8... - Page 13 Solder Click to view products by manufacturer: Fisnar Other Similar products are found below : 91362-6 14600 24-6040-0007 24-7150-8800 24-9574-7619 24-4060-2437 04-0595-0000 9SN-310G 5901006 8001111 ECC179707EU 49500-454G SMDLTLFP250T5 41-096-0201N ART.AGT-030 8001263 8001265 MPT2NY.IT MPT2SV.IT 0008752 04-6040-0050 580140 H560103-BULK H560106-BULK TDS12AS 5601380 BON-102F BON-102K BON-102S BR-102F 560006BA 560017A 560048...
