axing basic UIM 1-0 Manual page 3

 Observe the safety instructions supplied with the device!
They are also available at the following Internet address:
https://download.axing.com/BAs/Sicherheitshinweise_9sprachig.pdf
 Use the device only as described in these operating instructions and in
particular in accordance with the state of the art.
If the device is used for other purposes, no warranty will be assumed!
Technical improvements, changes in design, printing- and other errors reserved.
Page 1 of 2 |
QA_UIM-1-00.pdf | 2021-06-18
Technical data:
Type
Inputs
Number 1 × IP | 1 × HDMI | 1 × USB
Supported protocols PTV: IPv4/v6, TCP, UDP, HTTP, HLS, RTP, RTSP, RTMP,
USB: MPEG-TS, MPEG4, AVI, MOV, MPEG, MKV
HDMI: 1080p@60 Hz PCM Stereo
Output
Number of channels
Frequency range
Channel bandwidth
Output level adjustable
Video resolution
Output modulation
Type 64QAM, 128QAM, 256QAM @ DVB-C
QPSK, 16QAM, 64QAM @ DVB-T
Supported output formats
MER
FFT
FEC 1/2, 3/5, 2/3, 3/4, 5/6, 7/8 @ DVB-T
Guard interval 1/4, 1/8, 1/16, 1/32 @ DVB-T
Symbol rate
Interfaces
IPTV input
Compliance IPTV interface
Configuration interface
Compliance configuration interface
General
Operating voltage
Current consumption
Operating temperature range
Operating humidity (non-condensing)
Dimensions (W × H × D) appr.
Weight
External accessories
Plug-in power supply 100 ... 240 VAC / 50 ... 60 Hz | 12 VDC / 2 A
Herewith AXING AG declares that the marked products comply with the valid
guidelines.
WEEE Nr. DE26869279 | Electrical and electronic components must not be
disposed of as residual waste, it must be disposed of separately.
Manufacturer EEA contact address
AXING AG Bechler GmbH
Gewerbehaus Moskau Am Rebberg 44
8262 Ramsen 78239 Rielasingen
UIM 1-00
IGMP (Multicast)
UIM
1 × DVB-C | 1 × DVB-T
100 ... 950 MHz
6, 7, 8 MHz
100 dBμV basic-line
1080p @ 60 Hz
Universal Input
H.264 (MPEG-4)
Modulator
Typ. 35 dB
2K, 8K @ DVB-T
Quick start guide
5 ... 8 MBauds/s
1 x RJ45
IEEE 802.3, 10/100 Base-T
1 x RJ45
IEEE 802.3, 10/100 Base-T
12 VDC
830 mA
5 °C ... 40 °C
80 % @ 30 °C
128 × 125 × 44 mm
0.450 kg
