Specification
Radio Output:
Frequency
2.4GHz
16 channels, automatically selected
Direct-sequence spread spectrum
Compliance
IEEE 802.15.4-2006
Aerial Characteristics
Gain
2.0dBi
VSWR
<2:1
Data Encryption:
AES 128
Power Output:
+10dBm
Power Supply:
Internal 3.6Vdc NiMH battery
Environmental:
Operating:
Temperature
-10°C to +50°C
RH
0 to 90%, non-condensing
Storage:
Temperature
-10°C to +80°C
RH
0 to 90%, non-condensing
Country of origin:
UK
UK Sales Tel: 0845 345 7253
Radio Sensor Site Survey Hand-Held Monitor
Page 1 of 2
© 2008 Sontay
Features
•
High power output
•
High quality external whip antenna
•
Encrypted data transmission
•
Large LCD display
Product Codes
RF-HHT
Radio sensor site survey hand-held monitor
International Tel: +44 1732 861225
RF-HHT
Issue: 1.0
Date Of Issue: 01/07/2010
®
Limited. All rights reserved.
Advertisement
Related Manuals for Sontay RF-HHT
Summary of Contents for Sontay RF-HHT
- Page 1 RF-HHT Issue: 1.0 Date Of Issue: 01/07/2010 ® © 2008 Sontay Limited. All rights reserved. Radio Sensor Site Survey Hand-Held Monitor Features • High power output • High quality external whip antenna • Encrypted data transmission • Large LCD display...
- Page 2 Sontay RF-PS522 site survey routers, RF-RXSS site survey receiver and RF-TS911 nodes, which form a site To switch on the RF-HHT, press and hold the OK survey kit (SSK). key for 2 seconds. To switch off, press and hold the OK key for 2 seconds.
