PRODUCT NO.
BASE MODEL NO.
FEF361AWA
FEF361A
SERVICE DATA SHEET - # 316259142
WIRING DIAGRAM - #316255105
OWNER'S GUIDE - # 316257105
INSTALLATION INSTRUCTIONS -# 316259200
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
COLOR
MARKET
black/white
North America
Publication No.
5995358354
010830
-EN/SERVICE /ECL
369
FACTORY
PARTS CATALO
ELECTRIC
RANGE
Model No.
FEF361A
©2001 White Consolidated Industries, Inc.
All rights reserved
G
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FEF361A
Summary of Contents for Frigidaire FEF361A
- Page 1 PRODUCT NO. BASE MODEL NO. FEF361AWA FEF361A SERVICE DATA SHEET - # 316259142 WIRING DIAGRAM - #316255105 OWNER’S GUIDE - # 316257105 INSTALLATION INSTRUCTIONS -# 316259200 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O. Box 212378, Augusta, GA 30917 COLOR MARKET black/white North America Publication No.
- Page 2 Publication No. FEF361AWA 5995358354 BACKGUARD 08/01...
- Page 3 POS. NO 20 # 24 # 54 # 54A# # = Fast-moving Parts * = Non-Illustrated Parts FEF361AWA BACKGUARD PART NO DESCRIPTION 316239900 Shield,backguard ,rear wall 316241000 Shield,end cap ,RH 316241001 Shield,end cap ,LH 316022503 Light/Lamp,indicator ,surface ,250 V 316220204 Support,backguard ,black ,RH 316220205 Support,backguard ,black ,LH...
- Page 4 Publication No. FEF361AWA 5995358354 BODY 08/01...
- Page 5 POS. NO 12 # 18 # 37 # 62 # 66 # 67 # 89 # 170* 170* 170* # = Fast-moving Parts * = Non-Illustrated Parts FEF361AWA BODY PART NO DESCRIPTION 316201300 Back,main 316230102 Panel,bodyside ,white ,RH 316230103 Panel,bodyside ,white ,LH 316129200 Screw,leveling ,plastic ,with stop 316067902...
- Page 6 Publication No. FEF361AWA 5995358354 TOP/DRAWER 08/01...
- Page 7 POS. NO 15 # 15A# # = Fast-moving Parts * = Non-Illustrated Parts FEF361AWA TOP/DRAWER PART NO DESCRIPTION 316011503 Drawer 316231500 Liner,drawer 316231305 Panel,drawer ,white 3051163 Glide,drawer ,rear 316010206 Element,8" ,surface ,2200 W ,radiant 316010205 Element,6" ,surface ,1200 W ,radiant 316251920 Main Top Assy,glass/steel ,white 316235900...
- Page 8 Publication No. FEF361AWA 5995358354 DOOR 08/01...
- Page 9 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FEF361AWA DOOR PART NO DESCRIPTION 5303935191 Trim kit-door,3 sided ,black ,w/tape and foil 316202801 Glass,oven door ,black ,outer 316222705 Shield,wool ,oven door 316076404 Insulation,oven door 316230603 Liner,oven door 316001014 Screw,waf hd sq ,10-24 x 1.6 ,handle ,(2) 316008401 Washer,3/4 OD x 1/4 ID ,steel 316230900...
-
Page 10: Wiring Diagram
Publication No. FEF361AWA 5995358354 WIRING DIAGRAM 08/01...
