PRODUCT NO.
BASE MODEL NO.
FEF336WHSC
FEF336WH
WIRING DIAGRAM - #316002707
OWNER'S GUIDE - # 316000290
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. BOX 212378, Augusta, GA 30917
FACTORY PARTS CATALOG
COLOR
MARKET
white\white
USA
Publication No.
5995343281
000912
-EN/SERVICE /ECL
369
RANGE
ELECTRIC
RANGE
Model No.
FEF336WH
©2001 White Consolidated Industries, Inc.
All rights reserved
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FEF336WH
Summary of Contents for Frigidaire FEF336WH
- Page 1 PRODUCT NO. BASE MODEL NO. FEF336WHSC FEF336WH WIRING DIAGRAM - #316002707 OWNER’S GUIDE - # 316000290 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O. BOX 212378, Augusta, GA 30917 FACTORY PARTS CATALOG COLOR MARKET white\white Publication No. 5995343281 000912 -EN/SERVICE /ECL ©2001 White Consolidated Industries, Inc.
- Page 2 Publication No. FEF336WHSC 5995343281 BACKGUARD 01/01...
- Page 3 POS. NO 12 # 13 # 20 # 24 # 54 # 54A# # = Fast-moving Parts * = Non-Illustrated Parts FEF336WHSC BACKGUARD PART NO DESCRIPTION 316081600 Shield-backguard,galv steel ,rear wall 316015905 Shield-backguard,inner 316083721 Trim-wrapper,textured ,white ,w/switch hole 316032405 Thermostat,oven ,non self-clean 316032500 Switch-selector 316022503...
- Page 4 Publication No. FEF336WHSC 5995343281 BODY 01/01...
- Page 5 POS. NO 62 # 66 # 67 # 170* 170* 170* # = Fast-moving Parts * = Non-Illustrated Parts FEF336WHSC BODY PART NO DESCRIPTION 316080803 Panel-main back,galv steel ,short 316021105 Screw,hex head cup pt ,8-18 x 0.375 ,black,back/bodyside 316081034 Panel-bodyside,white ,RH 316081035 Panel-bodyside,white ,LH 316129200...
- Page 6 Publication No. FEF336WHSC 5995343281 TOP/DRAWER 01/01...
- Page 7 POS. NO 15 # 15A# 51 # # = Fast-moving Parts * = Non-Illustrated Parts FEF336WHSC TOP/DRAWER PART NO DESCRIPTION 316011501 Drawer-utility 316089600 Spacer-drawer,(2) 5303288582 Shield-drawer,liner ,galv steel ,front panel 316084405 Panel-drawer front,white 3051163 Glide-drawer,rear 318178100 Element-surface,radiant ,small/6 inch ,1200 W 318178101 Element-surface,radiant ,large/8 inch ,2100 W 316098105...
- Page 8 Publication No. FEF336WHSC 5995343281 DOOR 01/01...
- Page 9 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FEF336WHSC DOOR PART NO DESCRIPTION 316050300 Glass-oven door, white , outer 316088403 Shield-wool 316076401 Insulation,oven door 316088600 Glass-oven door,inner 316066610 Liner-oven door 5303280308 Screw-handle mtg,wafer hd sq dr ,10-24T x 2.00 316008401 Washer,3/4 OD x 1/4 ID ,steel 5303202011...
-
Page 10: Wiring Diagram
Publication No. FEF336WHSC 5995343281 WIRING DIAGRAM 01/01...
