Frigidaire FEF329E Factory Parts Catalog

30-inch freestanding electric range
Hide thumbs

Advertisement

Quick Links

Download this manual
Product No.
Series
Color
Market
Wiring Diagram
Owner's Guide
Installation Instructions 316259206
Service Data Sheet
FEF329E.eps T20G0059.eps T20V0078.eps L20T0003.eps L20D0028.eps
316255302d.eps 316255302s.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
FEF329EBB
FEF329EBC
FEF329EQB
30" f/s elec
30" f/s elec
30" f/s elec
black
black
bisque
North America North America North America North America North America North America
316255302
316255302
316255302
316257129
316257129
316257129
316259206
316259206
316218512
316218512
316218512
Publication No.
5995450599
05/10/06
(EN/SERVICE/ECL)
369
FEF329EQC
FEF329ESB
FEF329ESC
30" f/s elec
30" f/s elec
30" f/s elec
bisque
white
white
316255302
316255302
316255302
316257129
316257129
316257129
316259206
316259206
316259206
316218512
316218512
316218512
30-INCH FREE-
STANDING ELECTRIC
RANGE
Model No.
FEF329E
©
Copyright
2005 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading

Related Manuals for Frigidaire FEF329E

Summary of Contents for Frigidaire FEF329E

  • Page 1 North America North America North America North America North America North America Wiring Diagram 316255302 Owner's Guide 316257129 Installation Instructions 316259206 Service Data Sheet 316218512 FEF329E.eps T20G0059.eps T20V0078.eps L20T0003.eps L20D0028.eps 316255302d.eps 316255302s.eps Electrolux Major Appliances North & Latin America P.O. BOX 212378 AUGUSTA, GA 30917 FEF329EBC FEF329EQB...
  • Page 2 Publication No: 5995450599 FEF329E BACKGUARD 10/05...
  • Page 3 5303288565 316021105 316021108 316021110 # Functional Parts * Non-Illustrated Parts FEF329E BACKGUARD A FEF329E (FEF329ESB) B FEF329E (FEF329ESC) C FEF329E (FEF329EBB) D FEF329E (FEF329EBC) E FEF329E (FEF329EQB) F FEF329E (FEF329EQC) DESCRIPTION A B C D E F Shield, backguard, rear wall...
  • Page 4 Publication No: 5995450599 FEF329E BODY 58A 58B NOTE: Oven Liner N/A T20V0078 Ass. du four N/A 10/05...
  • Page 5 316021110 316089500 5303271648 5303285179 5308014215 # Functional Parts * Non-Illustrated Parts FEF329E BODY A FEF329E (FEF329ESB) B FEF329E (FEF329ESC) C FEF329E (FEF329EBB) D FEF329E (FEF329EBC) E FEF329E (FEF329EQB) F FEF329E (FEF329EQC) DESCRIPTION A B C D E F Back, main...
  • Page 6 Publication No: 5995450599 FEF329E TOP/DRAWER L20T0003 10/05...
  • Page 7 316058600 316021105 316021108 316021110 5308014215 # Functional Parts * Non-Illustrated Parts FEF329E TOP/DRAWER A FEF329E (FEF329ESB) B FEF329E (FEF329ESC) C FEF329E (FEF329EBB) D FEF329E (FEF329EBC) E FEF329E (FEF329EQB) F FEF329E (FEF329EQC) DESCRIPTION A B C D E F Drawer A B C D E F...
  • Page 8 Publication No: 5995450599 FEF329E DOOR 10/05...
  • Page 9 316021110 316433600 5303271648 5303285179 # Functional Parts * Non-Illustrated Parts FEF329E DOOR A FEF329E (FEF329ESB) B FEF329E (FEF329ESC) C FEF329E (FEF329EBB) D FEF329E (FEF329EBC) E FEF329E (FEF329EQB) F FEF329E (FEF329EQC) DESCRIPTION A B - - - - Trim kit-door, 3 sided, white, w/tape and foil...

  • Page 10: Wiring Schematic

    Publication No: 5995450599 FEF329E WIRING SCHEMATIC 10/05...

  • Page 11: Wiring Diagram

    FEF329E Publication No: 5995450599 WIRING DIAGRAM 10/05 # Functional Parts * Non-Illustrated Parts...
