Frigidaire FEF326A Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Ranges
  5. FEF326A
  6. Factory parts catalog
Frigidaire FEF326A Factory Parts Catalog

Frigidaire FEF326A Factory Parts Catalog

Electric range
Hide thumbs Also See for FEF326A:

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FEF326ABB
FEF326A
FEF326AQB
FEF326A
FEF326ASB
FEF326A
FEF326AUB
FEF326A
FEF326AWB
FEF326A
COLOR
MARKET
black
North America
bisque
North America
white
North America
black/bisque
North America
black/white
North America
Publication No.
5995369252
020328
-EN/SERVICE /ECL
369

Advertisement

loading
Need help?

Need help?

Do you have a question about the FEF326A and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FEF326A

Summary of Contents for Frigidaire FEF326A

  • Page 1 PRODUCT NO. BASE MODEL NO. FEF326ABB FEF326A FEF326AQB FEF326A FEF326ASB FEF326A FEF326AUB FEF326A FEF326AWB FEF326A COLOR MARKET black North America bisque North America white North America black/bisque North America black/white North America Publication No. 5995369252 020328 -EN/SERVICE /ECL...
  • Page 2 BACKGUARD 03/02...
  • Page 3 A = FEF326A (FEF326ASB) B = FEF326A (FEF326AQB) C = FEF326A (FEF326ABB) D = FEF326A (FEF326AUB) E = FEF326A (FEF326AWB) POS. NO PART NO 316239900 316248900 316241000 316241001 316022500 316220202 316220208 316220204 316220203 316220209 316220205 316240900 316240906 316240905 316240901 316240907...
  • Page 4 BODY 03/02...
  • Page 5 A = FEF326A (FEF326ASB) B = FEF326A (FEF326AQB) C = FEF326A (FEF326ABB) D = FEF326A (FEF326AUB) E = FEF326A (FEF326AWB) POS. NO PART NO 316201300 316230102 316230103 316230108 316230109 316230104 316230105 316201401 316129200 316067902 316212908 316212909 3203540 316081900 316082000 316116400...
  • Page 6 TOP/DRAWER 03/02...
  • Page 7 A = FEF326A (FEF326ASB) B = FEF326A (FEF326AQB) C = FEF326A (FEF326ABB) D = FEF326A (FEF326AUB) E = FEF326A (FEF326AWB) POS. NO PART NO 316011503 316231500 316231305 316231309 316231306 3051163 15 # 5303012223 15A# 08067762 316202307 316202309 316202306 316057601 316235900...
  • Page 8 DOOR 03/02...
  • Page 9 A = FEF326A (FEF326ASB) B = FEF326A (FEF326AQB) C = FEF326A (FEF326ABB) POS. NO PART NO 316050300 316050306 316050302 316222709 316236801 316088600 316230604 316001014 316008401 316239700 316202702 316202704 316202701 316248401 316248403 316248400 5303272476 316248301 316248304 316248300 5303280311 316245600 316021110 5303271648...
  • Page 10 DOOR 03/02...
  • Page 11 D = FEF326A (FEF326AUB) E = FEF326A (FEF326AWB) POS. NO PART NO 5303935191 5303935203 316222709 316236801 316088600 316230604 316001014 316008401 316239700 316248400 316248300 316201005 5303280311 316021110 5303271648 5303285179 DOOR DESCRIPTION - - - D E Trim kit-door,3 sided ,black ,w/tape and foil...

  • Page 12: Wiring Schematic

    WIRING SCHEMATIC 03/02...

  • Page 13: Wiring Diagram

    WIRING DIAGRAM...
