- Page 1 PRODUCT NO. BASE MODEL NO. FEF322BXAWA FEF322BXA COLOR MARKET white North America Publication No. 5995372793 020524 -EN/SERVICE /ECL...
- Page 2 BACKGUARD 05/02...
- Page 3 BACKGUARD POS. NO PART NO DESCRIPTION 316081600 Shield,backguard ,galv steel ,rear wall 316248900 Spacer,shield ,rear wall 316015907 Shield,backguard ,black ,inner 316083719 Trim,wrapper ,black 12 # 316032405 Thermostat,oven ,non self-clean 13 # 316032500 Switch,selector 316022503 Light/Lamp,indicator ,surface ,250 V 316023108 Support,backguard ,RH 316023109 Support,backguard ,LH 316100529...
- Page 4 BODY 05/02...
- Page 5 BODY POS. NO PART NO DESCRIPTION 316201300 Back,main 316230102 Panel,bodyside ,white ,RH 316230103 Panel,bodyside ,white ,LH 316201401 Burner Box 316129200 Screw,leveling ,plastic ,with stop 316067902 Rack,oven 316212908 Hinge,oven door ,RH 316212909 Hinge,oven door ,LH 3203540 Panel,oven bottom 316081900 Pan,broiler 316082000 Insert,broiler pan 14 # 316116400...
- Page 6 TOP/DRAWER 05/02...
- Page 7 TOP/DRAWER POS. NO PART NO DESCRIPTION 316011503 Drawer 316231500 Liner,drawer 316231305 Panel,drawer ,white 316021112 Screw,8-18 x 0.500 ,white 3051163 Glide,drawer ,rear 15 # 5308011964 Element,surface ,large/8 inch ,(2) ,medallion incl 15A# 316115400 Element,surface ,small 6" 316020907 Main Top,white 316057601 Rod,support ,main top 5303273062 Hinge,main top ,RH 5303273063...
- Page 8 DOOR 05/02...
- Page 9 DOOR POS. NO PART NO DESCRIPTION 5303935191 Trim kit-door,3 sided ,black ,w/tape and foil 5303935203 Glass,door kit ,black ,outer ,w/foil tape 316222709 Shield,oven door ,wool 316236801 Insulation,oven door 316088600 Glass,oven door ,inner 316230604 Liner,oven door 316001014 Screw,waf hd sq ,10-24 x 1.6 ,handle ,(2) 316008401 Washer,3/4 OD x 1/4 ID ,steel 316239700...
